Air King Builder’s Choice 9810 Specifications

Air king 52" builder's choice ceiling fan specifications sheet
Hide thumbs Also See for Builder’s Choice 9810:

Advertisement

• Fan Body

Powder coated .0035'' thick steel body housing.

• Motor

Permanently lubricated, powerful 3-speed reversible motor.
120 volt, 60 hz, 0.5 amp, 60 watt.

• Unit Mounting

Dual mounting. Close to ceiling mounting or Downrod. All
mounting hardware including a 4'' downrod is included in box.

• Finish

All white body

• Paddles

5 reversible White/Bleached Oak paddles

• Shipping Information

Box Dimension: 21" x9 13/16" x10 1/8"
UPC: 0-46013-37288-8
Shipping Weight: 14.1 lbs.
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
Specifications subject to change without notice.
52" Builder's Choice Ceiling Fans
120 Volts, 0.5 Amps, 60 hz.
IN
RPM
WATTS
AMPS
W.C.
www.airkinglimited.com
SPECIFICATIONS
9810
ARCHITECT
ENGINEER
SUBMITTED BY
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
CEILING FANS
DATE
OPTIONAL EQUIPMENT
& REMARKS
New 3-08
