Builder's Choice Industrial Single Speed Fan Series
• Fan Body
Powder coated .0035" thick steel body housing.
• Motor
1-speed, 1/4 HP, 1 phase, totally enclosed ball bearing,
permanently lubricated, permanent split capacitor. 120 volt,
60 hz, 0.68 amp, 81 watt.
• Unit Mounting
Downrod. All mounting hardware including a 16" downrod
is included in box.
• Finish
All white body.
• Paddles
3 white powder coated steel paddles.
• Shipping Information
9848 M1:
UPC: 0-8316237091-4
Shipping Weight: 14.5 lbs.
9856M1:
UPC: 0-8316237191-1
Shipping Weight: 15.3 lbs
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
Specifications subject to change without notice.
120 Volts, 0.68 amps, 60 hz.
IN
RPM
WATTS
AMPS
W.C.
www.airkinglimited.com
SPECIFICATIONS
9848M1
9856M1
ARCHITECT
ENGINEER
SUBMITTED BY
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
CEILING FANS
DATE
OPTIONAL EQUIPMENT
& REMARKS
New 3-08
