• Fan Body
Powder coated .0035'' thick steel body housing.
• Motor
Permanently lubricated, powerful 3-speed reversible motor.
120 volt, 60 hz, 0.5 amp, 60 watt.
• Unit Mounting
Dual mounting. Close to ceiling mounting or Downrod. All
mounting hardware including a 4'' downrod is included in box.
• Finish
All white body
• Paddles
5 reversible White/Bleached Oak paddles
• Lighting
Center mounted 100 watt maximum schoolhouse light kit. Light
kit and fan are shipped in one carton. (bulb not included)
• Shipping Information
Box Dimension: 21" x9 13/16" x10 1/8"
UPC: 0-8316237888-0
Shipping Weight: 15.4 lbs.
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
Specifications subject to change without notice.
52" Builder's Choice Ceiling Fans with Light
120 Volts, 0.5 Amps, 60 hz.
IN
RPM
WATTS
W.C.
www.airkinglimited.com
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS
SONES
QTY
SPECIFICATIONS
9810L
CEILING FANS
DATE
OPTIONAL EQUIPMENT
& REMARKS
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
New 3-08
