Instruction Manual
• Fan Body
Powder coated .0035" thick steel body housing.
• Motor
Permanently lubricated, powerful 3-speed motor.
120 volt, 60 hz, 0.68 amp, 80 watt.
• Unit Mounting
Downrod. All mounting hardware including a 16" downrod is
included in box.
• Finish
All white body.
• Paddles
3 white powder coated steel paddles.
• Controls
3 speed wall control included with unit. Wall control in rated to
operate one fan.
• Shipping Information
9848: UPC: 0-8316237289-5
Shipping Weight: 14.5 lbs.
9856: UPC: 0-8316237189-8
Shipping Weight: 15.3 lbs.
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
Specifications subject to change without notice.
Builder's Choice Industrial Ceiling Fan Series
120 Volts, 0.68 amps, 60 hz.
IN
RPM
WATTS
W.C.
9848 / 9856
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
INDUSTRIAL
CEILING FAN
CEILING FANS
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
New 4-05
