Quick Links
• Fan Body
Powder coated .0035" thick steel body housing.
• Motor
Permanently lubricated, powerful 3-speed reversible motor.
120 volt, 60 hz, 0.5 amp, 60 watt.
• Unit Mounting
Dual mounting. Close to ceiling mounting or Downrod. All
mounting hardware including a 4" downrod is included in box.
• Finish
All white body.
• Paddles
5 all white molded ABS plastic paddles.
• Lighting
(model 9898L only)
Center mounted 100 watt maximum schoolhouse light kit. Light
kit and fan are shipped in one carton.
• Shipping Information
9898: UPC: 0-8316237389-2
Shipping Weight: 14.1 lbs.
9898L: UPC: 0-8316237189-8
Shipping Weight: 17.2 lbs.
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
Specifications subject to change without notice.
Builder's Choice 52" Porch Fan Series
120 Volts, 0.5 amps, 60 hz.
(bulb not included).
IN
RPM
WATTS
AMPS
W.C.
PORCH FAN
UL Listed for damp location
9898L
UL Listed for damp location
ARCHITECT
ENGINEER
SUBMITTED BY
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
CEILING FANS
9898
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
New 4-05
