Air King Builder’s Choice 9856UF Specifications

Builder's Choice Industrial Updraft Ceiling Fan Series

• Fan Body

Powder coated .0035" thick steel body housing.

• Motor

1-speed, 1/4 HP, 1 phase, totally enclosed ball bearing,
permanently lubricated, permanent split capacitor.
120 volt, 60 hz, 0.68 amp, 81 watt.

• Unit Mounting

Downrod. All mounting hardware including a 16" downrod is
included in box.

• Finish

All white body.

• Paddles

3 white powder coated steel paddles.

• Shipping Information

UPC: 0-8316237190-4
Shipping Weight: 17.3 lbs.
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
Specifications subject to change without notice.
120 Volts, 0.68 amps, 60 hz.
IN
RPM WATTS AMPS
W.C.
www.airkinglimited.com
9856UF
9856UF
Updraft ceiling fan designed for use in agricultural
settings including chicken houses, stables, and
other areas where air needs to be circulated from
the top of the building.
ARCHITECT
ENGINEER
SUBMITTED BY
SONES QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
CEILING FANS
DATE
OPTIONAL EQUIPMENT
& REMARKS
New 5-07
