- Page 1 US ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS SIGNATURE III Bench Floor Roof Left Wall Back Wall Right Wall Front Wall with Glass door sunlighten.com sunlighten.com...
- Page 2 Place the back wall on the back of the floor panel Be sure you have two people assisting with this step. This is the side with the sauna information label on the bottom edge. sunlighten.com sunlighten.com...
- Page 3 As you insert each wall segment, you will insert the U-clips in the pre-drilled holes in the corner. This will keep the walls sealed together. The front wall will be inserted next. Be careful of the glass door and panel as you insert the wall. sunlighten.com sunlighten.com...
- Page 4 STEP 6 Once all the U-clips have been inserted in the corners, the next step will be to place the roof on top. Make sure the side the main power cord receptacle faces the back. sunlighten.com sunlighten.com...
- Page 5 The floor heaters will need to be connected to the right wall wires. The diagram to the left shows where the Connect floor connection is made. You will need to remove the floor heaters grate and a small hatch covering the harness. sunlighten.com sunlighten.com...
- Page 6 Allen wrench. The dust cover should also be replaced. heater frame CONGRATULATIONS, your sauna is now ready to enjoy! If you have any questions, please call Sunlighten Customer Support at 877.292.0020. sunlighten.com sunlighten.com...
