- Page 1 UK ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS SIGNATURE II Bench Floor Roof Left Wall Back Wall Right Wall Front Wall with Glass door sunlighten.com.au sunlighten.com/gb-en...
- Page 2 Place the back wall on the back of the floor panel Be sure you have two people assisting with this step. This is the side with the sauna information label on the bottom edge. sunlighten.com.au sunlighten.com/gb-en...
- Page 3 As you insert each wall segment, you will insert the U-clips in the pre-drilled holes in the corner. This will keep the walls sealed together. The front wall will be inserted next. Be careful of the glass door and panel as you insert the wall. sunlighten.com.au sunlighten.com/gb-en...
- Page 4 STEP 6 Once all the U-clips have been inserted in the corners, the next step will be to place the roof on top. Make sure the side the main power cord receptacle faces the back. sunlighten.au sunlighten.com/gb-en...
- Page 5 (see illustration 7.2). Back Right NOTE: Before the bench is placed, make sure the heater frames are taken out to allow the bench to be placed on its support. Then install the bench and then replace heater frames. Front Left sunlighten.com.au sunlighten.com/gb-en...
- Page 6 A second person should hold the handle while the other screws the bolts in with the Allen wrench. heater frame CONGRATULATIONS, your sauna is now ready to enjoy! If you have any queries, please call Sunlighten Customer Support at 0330.808.1203. sunlighten.com.au sunlighten.com/gb-en...
