Bullet & Turret Camera
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type I Camera
Type II Camera
Type III Camera
This manual may contain several technical mistakes or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or update
the products or procedures described in the manual.
Type
3K ColorVu
User Manual
Model
DS-2CE12KF3T-LE
DS-2CE12KF3T-L
DS-2CE10KF3T-LE
DS-2CE10KF3T-L
DS-2CE72KF3T-LE
DS-2CE72KF3T-L
02010020221227

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2CE12KF3T-LE and is the answer not in the manual?

Questions and answers

Summary of Contents for HIKVISION DS-2CE12KF3T-LE

  • Page 1 Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model DS-2CE12KF3T-LE Type I Camera DS-2CE12KF3T-L DS-2CE10KF3T-LE Type II Camera DS-2CE10KF3T-L DS-2CE72KF3T-LE...
  • Page 2 With the philosophy of “Technology for the Good”, Hikvision requests that every end user of video technology and video products shall comply with all the applicable laws and regulations, as well as ethical customs, aiming to jointly create a better community.
  • Page 3 believe that these products will also play an active role in more aspects of social life. Any abuse of video products in violation of human rights or leading to criminal activities are contrary to the original intent of technological innovation and product development. Therefore, each user shall establish an evaluation and tracking mechanism of their product application to ensure that every product is used in a proper and reasonable manner and with good...
  • Page 4 SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS,...
  • Page 5: Regulatory Information

    IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER PREVAILS. Regulatory Information EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the General Product Safety Directive 2001/95/EC, the EMC Directive 2014/30/EU, the RoHS...
  • Page 6 In the use of the product, you must be in strict  compliance with the electrical safety regulations of the nation and region. Input voltage should meet both the SELV (Safety Extra  Low Voltage) and the Limited Power Source with 12 VDC according to the IEC60950-1 and IEC62368-1 standard.
  • Page 7 While in delivery, the camera shall be packed in its  original packing, or packing of the same texture. Use Hikvision DVR that supports the power over coaxial  (PoC) technology if you power the device over coaxial cable.
  • Page 8: Installation

    1 Introduction 1.1 Product Features The main features are as follows: High quality imaging with 3K resolution  High performance CMOS sensor  OSD menu with configurable parameters  24-hour color image  Smart light  3-axis adjustment  3D Digital Noise Reduction ...
  • Page 9 Installation of Type I and Type II Camera 2.1.1 Ceiling/Wall Mounting of Type I Camera Before you start: Ceiling mounting and wall mounting are similar. Following steps take ceiling mounting as an example. Steps: 1. Paste the drill template (supplied) to the place where you want to install the camera.
  • Page 10 Ceiling mounting and wall mounting are similar. Following steps take ceiling mounting as an example. Steps: 1. Paste the drill template (supplied) to the place where you want to install the camera. 2. (Optional) For cement ceiling, drill the screw holes with a 5.5 mm drill and insert the supplied wall plugs.
  • Page 11 Figure 2-7 Drill Template for Junction Box 3. (Optional) Drill the cable hole, when the cables are routed through the wall. 4. Take apart the junction box. 5. Align the screw holes of the camera with those on the junction box cover. Attach the camera to the junction box cover with three PM4 ×...
  • Page 12 1. Take apart the wall mount. Figure 2-11 Take Apart Wall Mount 2. Paste the drill template (supplied) to the place where you want to install the camera. 3. Drill the screw holes with a 5.5 mm drill and insert the supplied wall plugs.
  • Page 13 Main Body Step 2 Cover Step 1 Figure 2-15 Secure Cover to Body 9. Lock the cover to the body with one PA3 × 13 screw. Figure 2-16 Lock Cover to Body 10. Refer to steps 6 to 7 of 2.1.1 Ceiling/Wall Mounting of Type I Camera to finish installation and adjust the viewing angle.
  • Page 14 5. Turn the camera clockwise until it snaps into the installation plate. Figure 2-20 Snap Camera into Installation Plate 6. Connect the power cord and video cable. 7. Power on the camera to check whether the image on the live view is captured from the optimum angle. If not, adjust the camera according to the figure below.
  • Page 15 Figure 2-23 Install Installation Plate to Junction Box Cover 6. Fit the camera onto the installation plate. Figure 2-24 Fit Camera 7. Turn the camera clockwise until it snaps into the installation plate. Figure 2-25 Snap Camera into Installation Plate 8.
  • Page 16 11. Refer to step 7 of 2.2.1 Ceiling/Wall Mounting to adjust the viewing angle. 2.2.3 Wall Mounting with Wall Mount Before you start: You need to purchase a wall mount in advance. Type I Wall Mount Steps: 1. Drill Ø10 mm screw holes in the wall where you want to install the wall mount.
  • Page 17 Figure 2-31 Take Apart Wall Mount 2. Paste the drill template (supplied) to the place where you want to install the camera. 3. Drill the screw holes with a 5.5 mm drill and insert the supplied wall plugs. Figure 2-32 Drill Template for Wall Mount 4.
  • Page 18: Menu Description

    Figure 2-36 Lock cover to Body 错误 未找到引用源。 10. Repeat steps 6 to 7 of 2.2.1 to adjust the angle and finish the installation. 3 Menu Description Please follow the steps below to call the menu. Note: The actual display may vary with your camera model. Steps: 1.
  • Page 19: Video Format

    VIDEO FORMAT EXPOSURE MODE SLOW SHUTTER EXPOSURE ANTI -BANDING BACK EXIT SAVE & EXIT LIGHTING MODE IR/WHITE LIGHT SMART IR LIGHTING SETTINGS THRESHOLD LEVEL MODE BACK EXIT SAVE & EXIT IMAGE MODE WHITE BALANCE MAIN MENU BRIGHTNESS CONTRAST VIDEO SHARPNESS SETTINGS SATURATION 3 DNR...
  • Page 20 3.2 EXPOSURE EXPOSURE MODE You can set the EXPOSURE MODE to GLOBAL, BLC, HLC, WDR, or HLS. GLOBAL  GLOBAL refers to the normal exposure mode that adjusts lighting distribution, variations, and non-standard processing. BLC (Backlight Compensation)  BLC (Backlight Compensation) compensates light to the object in the front to make it clear, but this may cause over-exposure of the background where the light is strong.
  • Page 21: White Light

    Day to Night Threshold is used to control the sensitivity of switching the day mode to the night mode. You can set the value from 1 to 9. The larger the value is, the more sensitive the camera is. N D Threshold (Night to Day Threshold) ...
  • Page 22: Factory Default

    the image. You can set WHITE BALANCE mode to AUTO, OUTDOOR, and GLOBAL. AUTO  The white balance can automatically adjust according to the environment. OUTDOOR  You can choose this mode for outdoor environment. GLOBAL  You can choose this mode in complicated scene, such as public square.
  • Page 23: Save And Exit

    3.8 SAVE & EXIT Move the cursor to SAVE & EXIT and click Iris+ to save the settings and exit the menu. UD31263B...
