User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I Camera
Type II Camera
This manual may contain several technical incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to
the new version of this manual. We will readily improve
or update the products or procedures described in the
manual.
D0T PIR Series Bullet
TURBO HD
Camera
User Manual
Model
DS-2CE11D0T-PIRL
DS-2CE12D0T-PIRL
0200001080504
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION DS-2CE11D0T-PIRL
Summary of Contents for HIKVISION DS-2CE11D0T-PIRL
-
Page 1: User Manual
This manual applies to the models below: Type Model Type I Camera DS-2CE11D0T-PIRL Type II Camera DS-2CE12D0T-PIRL This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. -
Page 2: Regulatory Information
Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 4 Keep the camera away from liquid while in use for non-water-proof device. While in delivery, the camera shall be packed in its original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark Description DC Voltage...
-
Page 5: Product Features
1 Introduction 1.1 Product Features The main features are as follows: High performance CMOS sensor IR cut filter with auto switch OSD menu with configurable parameters Auto white balance internal synchronization SMART IR mode Visible alarm ... -
Page 6: Installation Environment
2 Installation Before you start Make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is power-off during the installation. Check the specification of the products for the ... - Page 7 For cement wall/ceiling, expansion bolts are required to fix the camera. For wooden wall/ceiling, self-tapping screws are required. 4. Route the cables through the cable hole, or the side opening. 5. Connect the corresponding power cord, and video cable. 6.
- Page 8 Figure 2-5 Fix the Camera on the Junction Box’s Cover 5. Attach the junction box body to the ceiling/wall by aligning the screw holes of the junction box. 6. Secure the junction box’s body with supplied screws on the ceiling/wall. Figure 2-6 Fix the Junction Box to the Wall/Ceiling 7.
-
Page 9: Ceiling/Wall Mounting With Junction Box
Figure 2-8 Drill Template Note: Drill the cable hole in the center of the drill template, when adopting ceiling outlet to route the cable. 3. Route the cables through the cable hole (optional) or the side opening. 4. Fix the camera to the ceiling with supplied screws. Figure 2-9 Fix the Camera to the Ceiling Note: The supplied screw package contains self-tapping... - Page 10 2. Drill screw holes and the cable hole (optional) in the ceiling/wall according to the holes of the drill template. Figure 2-11 Drill Template Note: Drill the cable hole, when adopting ceiling outlet to route the cable. 3. Take apart the junction box, and align the screw holes of the bullet camera with those on the Junction box’s cover.
-
Page 11: Menu Description
3 Menu Description Purpose: Call the menu by clicking button on the PTZ Control interface, or call the preset No.95. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. Figure 3-1 Connection 2. -
Page 12: Video Format
1). Click up/down direction button to select the item. 2). Click Iris + to confirm the selection. 3). Click left/right direction button to adjust the value of the selected item. 3.1 VIDEO FORMAT You can select the video format as 2MP@25fps , or 2MP@30fps. -
Page 13: Video Settings
Figure 3-3 DAY NIGHT IR LIGHT You can turn on/off the infrared to meet the requirements of different circumstances. SMART IR The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure. - Page 14 You can set the R GAIN/B GAIN value from 1 to 255 to adjust the shades of red/blue color of the image. Figure 3-5 MWB MODE BRIGHTNESS Brightness refers to the brightness of the image. You can set the brightness value from 1 to 9 to darken or brighten the image.
- Page 15 ALARM In the ALARM mode, you can select the ALARM MODE as SOLID, or FLASHING. Figure 3-6 ALARM MODE SOLID Select the ALARM MODE as SOLID. In this way, the white light source turns on, when the PIR module received the alarm signal.
-
Page 16: Factory Default
alarm type only supported by the DVR can also triggers the visible alarm in the camera. CAMERA Select the TRIGGER MODE as CAMERA, the embedded PIR module sends the alarm signal to the visible alarm in the camera, when PIR module detected the alarm source.
