USB 1.1 Rover® 2850
Quick
Start
Guide
Product Contents:
▪ USB 1.1 Rover 2850 LEX
▪ USB 1.1 Rover 2850 REX
▪ USB Cable
▪ Quick Start Guide
Refer to the complete user guide online at:
www.icron.com/2850
For technical support visit:
www.icron.com/support
www.icron.com
Before you get started, ensure that all the drivers
required for your USB device(s) are installed.
1
Place units where desired, and connect the
CAT 5e/6/7 (solid core) extension link cabling
into the Link ports (RJ45) on the Local Extender
(LEX) and Remote Extender (REX).
LEX
(CAT 5e/6/7 cable not included)
Maximum Cable Range:
Full-Speed and Low-Speed: up to 40m (131 ft)
Low-Speed HID Devices: up to 85m (279 ft)
2
Connect the LEX to your computer using the
included USB cable.
Computer
3
Attach your USB device(s) to REX.
REX
