HDCVI Eyeball Camera
User's Manual
V1.0.1

Advertisement

Table of Contents
loading

Summary of Contents for Dahua Pro DHHAC-HDW2501T-A

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua Pro DH- HAC-HDW2501T-A o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza HDCVI Eyeball Camera User’s Manual V1.0.1...
  • Page 2: Foreword

    Foreword General This user’s manual (hereinafter referred to be "the Manual") introduces the functions, installation and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the Manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury.
  • Page 3 official website. If there is inconsistency between paper User's Manual and the electronic version, the electronic version shall prevail.  All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the Manual. Please contact the customer service for the latest program and supplementary documentation.
  • Page 4 Important Safeguards and Warnings Electrical Safety  All installation and operation should conform to your local electrical safety codes.  The power source shall conform to the requirement of the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1.
  • Page 5 device is installed and maintained by professional engineers.  The surface of the image sensor should not be exposed to laser beam radiation in an environment where a laser beam device is used.  Do not provide two or more power supply sources for the device; otherwise it might damage the device.
  • Page 6: Table Of Contents

    Table of Contents Foreword ..............................I 1 Introduction ............................1 1.1 General............................1 1.2 Features ............................1 2 Design ..............................2 2.1 Dimension ............................. 2 2.2 Cable ............................. 3 3 Installation .............................. 5 4 Configuration ............................8 4.1 Opening Main Menu ........................8 4.2 Setting Audio Input ........................
  • Page 7: Introduction

    Introduction General This series of products comply with the HDCVI standard and support the transmission of video and control signal over coaxial cable. They produce video signal with megapixel resolution and require XVR device that comply with the HDCVI standard to achieve high speed, long distance and zero lag transmission of the signal.
  • Page 8: Design

    Design Dimension Figure 2-1 Model A (mm [in]) Figure 2-2 Model B (mm [in]) Figure 2-3 Model C (mm [in]) Design 2...
  • Page 9: Cable

    Cable Figure 2-4 Figure 2-5 Figure 2-6 Figure 2-7 Figure 2-8 Figure 2-9 For more information about cable ports, see Table 2-1; for the operation method of ⑥(DIP switch), see Table 2-2. Port Name Function ① DC 12V Inputs DC 12V power. Please be sure to supply power as instructed in the Power Input Manual.
  • Page 10 Port Name Function ② DC 12V or AC Inputs DC 12V or AC 24V power. Please be sure to supply power as 24V Power instructed in the Manual. Input Device abnormity or damage could occur if power is not supplied correctly. ③...
  • Page 11: Installation

    Installation Make sure the mounting surface is strong enough to hold at least three times of the  camera weight.  The following figure is for reference only, and the actual product shall prevail. For the installation diagram and item list of model A, see Figure 3-1 and Table 3-1, for those of model B and model C, see Figure 3-2 and Table 3-2.
  • Page 12 Figure 3-2 Item Item Item Item ① ② ③ ④ Mounting surface Expansion bolt Pedestal Self-tapping screw ⑤ ⑥ ⑧ ⑨ Device Enclosure Wrench Locking screw Table 3-2 Step 1 Find the mounting template sticker from the accessory pack and stick it to the mounting surface①...
  • Page 13 Figure 3-3 For model B and model C, put the enclosure⑥ back on and adjust the locking  screw⑨ to hold it, leave some spaces enough for you to adjust the device⑤. Aim the lens to the ideal angle and adjust the focus until you get clear image (see Figure 3-4) and fasten the locking screw⑨.
  • Page 14: Configuration

    Configuration Power up the camera and connect it to XVR device with coaxial cable, then the live view screen is displayed. The following instructions will guide you to configure your camera. The number of the coaxial port on XVR will display at the lower left corner of the live view window to indicate the corresponding camera.
  • Page 15: Setting Audio Input

    Figure 4-2 Right-click anywhere on the screen to return to the previous menu until you goes back to the live view screen interface. Setting Audio Input Audio signal acquisition is available on select models. Step 1 In the Main Menu interface (Figure 4-2), select CAMERA > ENCODE > Encode. The Encode setting interface is displayed.
  • Page 16 Figure 4-3 Step 2 In the Channel list, select the camera that you want to configure according to the coaxial port number. Step 3 In the Main Stream column, click More Setting. The More Setting interface is displayed. See Figure 4-4. Figure 4-4 Step 4 In the More Setting interface, you can configure the audio settings.
  • Page 17: Operating Osd Menu

    Operating OSD Menu Step 1 In the live view screen interface, right-click within the live view window of the camera that you want to configure. The shortcut menu (Figure 4-1) is displayed. Step 2 Click PTZ. The PTZ setting interface is displayed. See Figure 4-5. Figure 4-5 Step 3 Click...
  • Page 18 Table 4-1 If there is " " as the value of an OSD item, click Enter to go to the next level of this item. Click Return to go back to the previous level. Clicking Cancel is to exit OSD menu without saving the modifications.
  • Page 19: Maintenance

    Maintenance In order to maintain the image quality and proper functioning of the device, please read the following maintenance instructions carefully and hold rigid adherence. Disassembly and Desiccant Replacement Carefully follow the instructions in the manual when performing any disassembly operation ...
