- Page 1 CORSLESS IMPACT DRILL DRIVER 12V 8101K...
-
Page 2: Technical Specifications
TECHNICAL SPECIFICATIONS Model 8101K Battery Voltage Max Torque 28N.M Impact Rate 0-22000BPM No-load Speed 0-400RPM 0-1300RPM Chuck Size 10mm Torque Setting 21+1+1 Accessories 1 Pc Faster Charger, 2 Pcs 2.0 A.H Battery, BMC PART LIST Adjustable for Drilling / Adjustable torque clutch... -
Page 3: General Power Tool Safety Rules
GENERAL POWER TOOL SAFETY RULES WARNING! -Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. -Save all warnings and instructions for future reference. -The term «power tool» in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 4 or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. -Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
- Page 5 -Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. -Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation.
- Page 6 tool is maintained. -Follow instruction for lubricating and changing accessories. -Keep handles dry, clean and free from oil and grease. CORDLESS DRILL/SCREW DRIVER SAFETY WARNING! -Hold power tool by insulated gripping surfaces, when performing an operation where the fastener may contact hidden wiring or its own cord. Fasteners contacting a «live»...
-
Page 7: Tips For Maintaining Maximum Battery Life
-If operating time has become excessively shorter, stop operating immediately. It may result in a risk of overheating, possible burns and even an explosion. -If electrolyte gets into your eyes, rinse them out with clear water and seek medical attention right away. It may result in loss of your eyesight. DO NOT SHORT THE BATTERY CARTRIDGE 1.Do not touch the terminals with any conductive material. -
Page 8: Reversing Switch Action
the way until it locks in place with a little click. -Do not use force when inserting the battery cartridge. If the cartridge does not slide in easily, it is not being inserted correctly. Battery Latch Battery LIGHTING UP THE FRONT LAMP CAUTION: Do not look in the light or see the source of light directly. -
Page 9: Switch Action
CAUTION: Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. SWITCH ACTION CAUTION: -Before inserting the battery cartridge into the tool, always check to see that the switch trigger actuates properly and returns to the «OFF» position when released. -
Page 10: Adjusting The Fastening Torque
the «L» side and «H» side, the tool may be damaged. -Do not use the speed change lever while the tool is running. The tool may be damaged. 1 Speed change lever ADJUSTING THE FASTENING TORQUE The fastening torque can be adjusted in 21 steps by turning the adjusting ring so that its graduations are aligned with the pointer on the tool body. -
Page 11: Installing Or Removing Driver Bit Or Drill Bit
INSTALLING OR REMOVING DRIVER BIT OR DRILL BIT Turn the sleeve counter clockwise to open the chuck jaws. Place the bit in the chuck as far as it will go. Turn the sleeve clockwise to tighten the chuck. To remove the bit, turn the sleeve counterclockwise. Keyless chuck OPERATION CAUTION:... - Page 12 CAUTION: Pressing excessively on the tool will not speed up the drilling. In fact, this excessive pressure will only serve to damage the tip of your bit, decrease the tool performance and shorten the service life of the tool. SCREW DRIVING OPERATION CAUTION: Adjust the adjusting ring to the proper torque level for your work.
-
Page 13: Maintenance
-Never use gasoline, benzene, thinner, alcohol or the like. Discoloration, deformation or cracks may result. NOTE: To maintain product safety and reliability repairs, any other maintenance or adjustment should be performed by Authorized Service Ronix Service Centers, always using replacement parts. RONIX CORDLESS IMPACT DRILL DRIVER...
