Sim-Lab FREESTANDING VARIO SINGLE Instruction Manual page 14

BOX A - VARIO SINGLE MONITOR MOUNT
PROFILE KIT
# Part
A1 80X40 Length=1195mm
A2 80X40 3N Length=1195mm
A3 80X40 3N Length=1195mm
A4 40X40 Length=580mm
HARDWARE KIT
A5 Rubber foot
A6 Triple sandwich plate 80
A7 Corner bracket 40x40
A8 Corner bracket 40x40 cap
A9 Profile 80x40 end-cap
A10 Profile 40x40 end-cap
A11 Bolt M8 X 20 DIN 912
A12 Bolt M8 X 16 DIN 912
A13 Bolt M8 X 20 DIN 7380
A14 Washer M8 DIN 125-A
A15 Slot-Nut M8
BOX B - TRIPLE MONITOR MOUNT
PROFILE KIT
# Part
B1 80X40 3N Length=580mm
B2 80X40 3N Length=580mm
HARDWARE KIT
B3 Profile 80x40 end-cap
QTY Note
1
1 Left upright, engraved.
1 Right upright, engraved.
2
4
2
4
4
4
4
8
8
4 Buttonhead.
8
24
QTY Note
1 Left arm, engraved.
1 Right arm, engraved.
4
BOX C - Xero-Play triple pivot set
HARDWARE KIT
# Part
C1 Xero-Play triple pivot adapter
C2 Bolt M8 X 40 DIN 912
C3 Bolt M8 X 25 DIN 912
C4 Nut M8
C5 Slot-Nut M8
BOX D - Vario VESA adapter set
HARDWARE KIT
# Part
D1 Vario VESA holder
D2 Vario VESA plate
D3 Vario VESA pin holder
D4 Vario VESA pin
D5 Bolt M5 X 20 DIN 7991
D6 Screw M4 X 16 DIN 7985
D7 Screw M4 X 10 DIN 7985
D8 Bolt M8 X 16 DIN 912
D9 Set screw M8 X 40 DIN 916
D10 Set screw M5 X 20 DIN 916
D11 Washer M8 DIN 125-A
D12 Slot-Nut M8
D13 Standoff M4 x 10
Disclaimer: for some entries on this page, we supply more than required as spare
materials. Don't worry if you have some leftovers, this is intentional.
QTY Note
8
4
16
4
16
(x1 or x3 depending on purchase)
QTY Note
1
1
2
1
4
4 Philips head.
4 Philips head.
2
3
2
2
2
4
14
14 15 |
