8. Additional information

8.2 Specifications

Tuner & Demodulator
Frequency Range
Input Connector
Signal Level
RF Impedance
IF Band width
LNB Power & Polarization
LNB Tone Switch
DiSEqC Control
Unicable 1 and 2 / JESS certified
Demodulation
Symbol Rate
FEC Decode
MPEG
Transport Stream
Profile Level
Input Rate
Aspect Ratio
Video Resolution
Audio Decoding
Audio Mode
Sampling
Data In/Out Connector
LNB IF Input
LNB IF Output
Power supply
Input Voltage
Power in use
Power in standby
Protection
Physical Specifications
Weight (net)
Operating Temp
Storage Temp
Note:
Weight and dimensions are not absolutely exact values .
Technical details can be changed at any time without prior notice.
950 MHz to 2150 MHz
F-Type, IEC 169-24, female
-25 bis -65 dBm
75 Ω¸unbalanced
55 MHz / 8 Hz (per 5 Msps)
Vertical : +13 V, 14 V +/-5 %
Horizontal : +18 V, 19 V +/-5 %:
max. 500 mA Overload Protection
22 KHz +/- 2 KHz, 0.6 V +/- 0.2 V
Version 1.0/1.2 compatibel, Tone Burst A/B
EN 50494 / EN 50607
QPSK / 8PSK
1~45 Ms/s / SCPC, MCPC
1/2, 2/3, 3/4, 5/6 and 7/8 with constraint Length K=7
MPEG-4/H.264, MPEG-2 ISO/IEC 13818
MPEG-4/AVC, MPEG-2 MP@ML, MP@HL
max. 15 Mbit/s
4:3, 16:9
720 x 576, 720 x 480, 1280 x 720, 1920 x 1080
MPEG / MusiCam Layer I & II
Single channel / Dual channel / Joint stereo / Stereo
32, 44.1 and 48 KHz
F type, IEC 169-24 female
F type, IEC 169-24 female
100 - 240 V AC, 50/60 Hz,
max. 12 W
< 0,5 W
Separate internal fuse. Input shall have lightening Protection
ca. 1220 g
0° C - bis +40° C
-40° C - bis +65° C
