PEX 8614AA Base Board RDK
Hardware Reference Manual
Website:
Technical Support:
Copyright © 2008 by PLX Technology, Inc. All Rights Reserved – Version 1.0
October 16, 2008
Version 1.0
October 2008
www.plxtech.com
www.plxtech.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PEX 8614AA and is the answer not in the manual?

Questions and answers

Related Manuals for PLX Technology PEX 8614AA

Summary of Contents for PLX Technology PEX 8614AA

  • Page 1 PEX 8614AA Base Board RDK Hardware Reference Manual Version 1.0 October 2008 Website: www.plxtech.com Technical Support: www.plxtech.com/support Copyright © 2008 by PLX Technology, Inc. All Rights Reserved – Version 1.0 October 16, 2008...
  • Page 2 © 2008 PLX Technology, Inc. All rights reserved. PLX Technology, Inc. retains the right to make changes to this product at any time, without notice. Products may have minor variations to this publication, known as errata. PLX assumes no liability whatsoever, including infringement of any patent or copyright, for sale and use of PLX products.
  • Page 3 This document contains PLX Confidential and Proprietary information. The contents of this document may not be copied nor duplicated in any form, in whole or in part, without prior written consent from PLX Technology, Inc. PLX provides the information and data included in this document for your benefit, but it is not possible to entirely verify and test all the information, in all circumstances, particularly information relating to non-PLX manufactured products.

  • Page 4: Table Of Contents

    Debug Input Header (JP10) ......................26 4.3.13 Reference Clock Header (JP100) ....................26 RDK Port Configurations ..........................27 Bill of Materials/ Schematics ..........................30 PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 5 IGURES Figure 1. PEX 8614AA Base Board RDK Front View ....................2 Figure 2. Connecting The RDK to a PC with x1 or x4 link ..................4 Figure 3. Lanes 0-3 Hardware Connections on the RDK ..................6 Figure 4. Lanes 4-7 Hardware Connections on the RDK ..................7 Figure 5.

  • Page 6: General Information

    1. General Information The PLX PEX 8614AA Base Board RDK is a Rapid Development Kit based on the PEX 8614, a 12-lane, 12-port PCI Express switch based in the PCI Express Specification rev 2.0 with SerDes capable of running at 5 GT/s. The PEX 8614AA Base Board RDK provides a complete hardware and software development platform that facilitates getting designs up and running quickly, lowering risk and reducing time-to-market.

  • Page 7: Figure 1. Pex 8614Aa Base Board Rdk Front View

    Figure 1. PEX 8614AA Base Board RDK Front View PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 8: Pex 8614Aa-Bb Rdk Features

    Up to 3-digit display for junction temperature of PEX 8614 • Voltage level monitoring circuit for 1.0V and 2.5V power to the PEX 8614 PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 9: System Architecture

    2. System Architecture The PEX 8614AA-Base Board RDK is a 21” x 10” bench top board for silicon evaluation and design reference for the PEX 8614 PCI Express Gen 2 switch. This RDK consists of three main hardware components: the base board, the PCI Express External Cable Adapter and PCI Express Cable assembly.

  • Page 10: Pci Express Interfaces

    RDK, it is used to connect x4 link of PCI Express signals from PEX 8614 to one particular hardware connections. Only three Configuration Modules may be used on the PEX 8614AA base board RDK. These modules are labeled on their PCB silk screen as: •...

  • Page 11: Pci Express Lane 4 To Lane 7

    SLOT 7 with x1 link each to form ports 2, 10, 12, and 14. When Configuration Module 0107 is plugged into U75 at Case (b), four lanes will be connected to SLOT 4 to form a x4 link (port 4). PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 12: Pci Express Lane 8 To Lane 11

    Case (b), four lanes will be connected to SLOT 8 to form a x4 link (port 1). Figure 5. Lanes 8-11 Hardware Connections on the RDK PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 13: Reference Clock Circuits

    MAX6420 reset controllers (U18 and U20), one Xilinx FPGA (U115), a Serial Hot-Plug controller, momentary switches (S1 and S3), resistors and capacitors. PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 14: Serial Hot-Plug (Shp) Controller Circuits

    SLOTs. The RDK implements a serial Hot-Plug controller circuitry to PCI Express SLOT 8 for the SHP function demonstration. By default, the serial Hot-Plug circuit is enabled. PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 15: Serial Eeprom

    PCI Express connector SLOT 82. Serial EEPROM The PEX 8614AA Base Board RDK contains a blank surface mount Atmel AT25256A 32-Kbit serial EEPROM (U19) which is directly interfaced to the PEX 8614. When programmed correctly, the serial EEPROM can be used to change the default configuration and internal register values of the PEX 8614.

  • Page 16: Power Distribution Circuits

    +12V supply. An Nvidia Geforce 8800GT high power graphic card can be plugged into one of PCI Express slots on the RDK in order to provide enough loading on the +12V supply. PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 17: Fpga Interface

    Communicates with the thermal sensor and displays the junction temperature of PEX 8614 in 4 digits • Connects to users defined Dipswitches • Fans out reset signals to PEX 8614 and PCI Express slots PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 18: Led And 7-Segment Displays

    On: 5V_A is applied to the RDK from the ATX power supply On: 3.3VCC is applied to the RDK from the ATX power supply PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 19: 7-Segment Displays

    Link Width of port 8, When it is on, it would be 1 DS12 For port 2 at SLOT4, When it is on, it would be 2 PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 20: Gpio Pins

    Connections on PEX 8614AA Base Board RDK STRAP_RESERVED16 Pull-down with a 1K ohm resistor STRAP_RESERVED17# Pull-up with a 4.7K ohm resistor PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 21: On-Board Connectors, Switches, And Jumpers

    4. On-Board Connectors, Switches, and Jumpers DIP Switches The PEX 8614AA Base Board RDK contains eleven DIP switches for various functions. Refer to Figure 14; they can be divided into three groups. The Group1 contains three dip switches and is located at the lower left corner of...

  • Page 22: Dip Switch Group 2

    2. DEBUG_SEL0 3: PROBE_MODE_n 4: SERDES_MODE_EN_n 1. NT_UPSTR_PSEL3 2. NT_UPSTR_PSEL2 3: NT_UPSTR_PSEL1 4: NT_UPSTR_PSEL0 Figure 14. Group 2 of Dipswitches PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 23: Table 6. Functional Description Of Group 2 Dip Switches

    2: TESTMODE2: for PLX use only 3. TESTMODE1: for PLX use only 4: TESTMODE0: for PLX use only Default: 1-4: off,off,off,off PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 24: Dip Switch Group 3

    Table 7. Port Configurations use Dipswitch SW2 Dipswitch Settings for Port Configurations STRAP_PORTCFG[3:0] ON,ON,ON,ON (0000) x1x1x1x1x1x1x1x1x1x1x1x1x1x1x1x1 ON,ON,ON,OFF (0001) x4x1x1x1x1x1x1x1x1x1x1x1x1 ON,ON,OFF,ON (0010) x4x4x1x1x1x1x1x1x1x1 PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 25: Push-Button Switches

    4.2.2 FPGA Manual Reset# (S2) This momentary switch (S2) provides manual reset to the FPGA (U115) on the RDK. PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 26: Serial Hot-Plug Controller Attention Button (S3)

    PETp1 PERn1 PETn1 PERp2 PETp2 PERn2 PETn2 PERp3 PETp3 PERn3 PETn3 CREFCLKp CREFCLKn PWR_RTN PWR_RTN SB_RTN CWAKE# CPWRON CPERST# PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 27: Atx Main Power Connector (J9)

    Table 13. Signal Names of J12 Pin # Signal Name Pin # Signal Name VREF to 2.5V SS_PROG_TMS SCLK_CCLK_TCK MISO_DONE_TDO MOSI_DIN_TDI NC_INIT_NC PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 28: Xilinx Mode Setting Header (J13)

    Pin # Signal Name Pin # Signal Name C0p-Upstream C0p-Downstream C0n-Upstream C0n-Downstream C1p-Upstream C1p-Downstream C1n-Upstream C1n-Downstream C2p-Upstream C2p-Downstream C2n-Upstream C2n-Downstream PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 29: Pex 8614 I C Port (Jp8)

    Signal Name at JP11 GPIO16 DEBUG_SEL0 GPIO17 STRAP_UPCFG_TIMER_EN# GPIO18 STRAP_SMBUS_EN# GPIO19 STRAP_SPARE0# GPIO20 UPSTRM_PSEL3 GPIO21 GPIO29 GPIO22 GPIO30 GPIO23 I2C_ADDR2 PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 30 I2C_ADDR0 LN_GOOD_07_n I2C_ADDR1 LN_GOOD_08_n STRAP_SPARE1# LN_GOOD_09_n GPIO9 LN_GOOD_10_n GPIO10 LN_GOOD_11_n GPIO11 LN_GOOD_12_n GPIO12 LN_GOOD_13_n GPIO13 LN_GOOD_14_n GPIO14 LN_GOOD_15_n GPIO15 PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 31: Debug Input Header (Jp10)

    DEBUG_SEL0 GPIO0 4.3.13 Reference Clock Header (JP100) Table 21. Pin assignment of JP100 Pin Number Signal Name LAI_Refclk_p LAI_Refclk_n PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 32: Rdk Port Configurations

    5. RDK Port Configurations Configuration Module 0108 Figure 16. x1 upstream and 11x1 downstream (PCFG=0000) PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 33: Figure 17. X4 Upstream 8X1 Downstream (Pcfg=0001)

    Configuration Module 0108 Figure 17. x4 upstream 8x1 downstream (PCFG=0001) PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 34: Figure 18. X4 Upstream, 1X4 And 4X1 Downstream (Pcfg=0010)

    Figure 18. x4 upstream, 1x4 and 4x1 downstream (PCFG=0010) PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 35: Bill Of Materials/ Schematics

    RN1, RN4, RN5, RN6, RN7, RN8, Resistor Network, 4.7K 742C083472JTR SMT, 8-pin RN9, RN10, RN11, RN13, RN54, ohm 4R isolated RN55, RN58, RN59, RN60 PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 36 RES 390 OHM 5% SMT, 0402 R229, R232, R233, R234, R235, R236, R237, R240, R241, R242, R243, R244, R245, PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 37 Res. 7.32K ohm, 1/10W Yageo SMT, 0603 R343 KHFT 9C06031A1001F Yageo Res. 1.0K ohm 1/10W 1% SMT, 0603 R345 KHFT PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 38 C471, C472, C473, C474, C475, C476, C477, C478, C479, C480, C481, C482, C483, C484, C485, C486, C487, C488, C489, C490, C491, PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 39 R527, R528, R529 ERJ- R477, R478, R479, R480, R481, Panasonic RES 10K OHM 1% SMT, 0603 3GEYJ103V R482, R483, R484, PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 40 C. 2"x1/4" label with wording "PEX8614AA-BB4U1D RDK", place it at the upper right hand corner in the box E. R343, R345, R360 and R361 are used for rework the board (see assembly instructions for details) PEX 8614AA Base Board RDK Hardware Reference Manual – Version 1.0 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 41 USER STATUS TEMPERATURE PORT ID XC3S200 POER WIDTH EPROM PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com...
  • Page 42 - Chnaged the Xilinx FPGA part from XCS40XL to XC3S200 and the associated prom - Added the Multioutput Voltage regulator for the new Xilin FPGA - Updated the JTAG interface to USB to conform to latest Xilinx Tools PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC.
  • Page 43 RELEASE NOTES: PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com Title Title Title 8614 Base Board RDK...
  • Page 44 1.0VCC_A out of range GREEN GREEN Prototyping Pad Prototyping Pad TV52 TV52 1.0VCC GREEN GREEN PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. Prototyping Pad Prototyping Pad TV33 TV33 3.3VCC_SLT_12_13 POWER INDICATOR LEDS 3.3VCC_SLT_2_3 3.3VCC_SLT_6_7 3.3VCC_SLT_9...
  • Page 45 49.9 49.9 49.9 49.9 49.9 49.9 No Load Components. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com...
  • Page 46 R542 R542 R543 R543 R544 R544 R545 R545 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
  • Page 47 TMS-103-02-S-S TMS-103-02-S-S LAI_RefClk_p REFCLK+ LAI_RefClk_n REFCLK- JP100 JP100 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
  • Page 48 R287 HEADER 2X2 HEADER 2X2 0 Shunt 0 Shunt PROBE_MODE_n DEBUG_SEL0 [25] PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. UPSTRM_PSEL3 [25] SSC_ISO_EN_n [6] 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 49 GND67 x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 50 GND67 x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 51 GND67 x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 52 GND67 x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 53 GND67 x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 54 GND67 x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 55 GND67 x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr x16 PCI Express Contr PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 56 GND67 x16 PCI Express Contr x16 PCI Express Contr cage cage PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 57 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
  • Page 58 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF 0.01uF PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
  • Page 59 0.01uF 0.01uF The above FOUR 7Segs should Be placed in accordance with their Name. TEMPERATURE.01 is the LSD and PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. TEMPERATURE100 is the MSD. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 60 [19] PEX_LN11_2p5G [19] PEX_LN3_5p0G [19] PEX_LN7_5p0G [19] PEX_LN11_5p0G PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
  • Page 61 SW DIP-2 SW DIP-2 Default Settings 1: off (disable MRL#_S) 2: off (disable Serial HP) PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 62 4R 4.7K 4R 4.7K 4R 4.7K 3.3VCC1 3.3VCC1 3.3VCC1 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com...
  • Page 63 R352 R352 R357 R357 R356 R356 PWRGD1 PWRGD2 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
  • Page 64 Receptacle 10 x 20 Receptacle 10 x 20 Receptacle 10 x 20 Receptacle 10 x 20 Receptacle 10 x 20 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 65 GND4 GND5 MICTOR 38 RECEPT MICTOR 38 RECEPT MICTOR CONNECTOR C PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 66 IO_L39P_7 SMBDATA_16 [23] UMODE1 IO_L17P_7 IO_L39N_7 SMBCLK_16 [23] UMODE2 IO_L19N_7_VREF_7 IO_L24P_7 EN_NVM_VDDQ [23] UMODE3 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. IO_L19P_7 IO_L24N_7 CPRSNTN [16] IO_L20N_7 IO_L23P_7 SHPC_INT_n [8,21] TP38 TP38 870 W Maude Ave, Sunnyvale, CA 94085...
