  • Page 1 PEX 8647-AA RDK Hardware Reference Manual Version 1.2 November 2008 Website: www.plxtech.com Technical Support: www.plxtech.com/support Copyright © 2008 by PLX Technology, Inc. All Rights Reserved – Version 1.2 November 10, 2008...
  • Page 2 © 2008 PLX Technology, Inc. All rights reserved. PLX Technology, Inc. retains the right to make changes to this product at any time, without notice. Products may have minor variations to this publication, known as errata. PLX assumes no liability whatsoever, including infringement of any patent or copyright, for sale and use of PLX products.
  • Page 3 This document contains PLX confidential and proprietary information. The contents of this document may not be copied nor duplicated in any form, in whole or in part, without prior written consent from PLX Technology, Inc. PLX provides the information and data included in this document for your benefit, but it is not possible to entirely verify and test all the information, in all circumstances, particularly information relating to non-PLX manufactured products.

  • Page 4: Table Of Contents

    C Port (JP9 – JP10) ....................14 Reference Clock Header (J1) ..................15 ATX HD Power Connector (J2 – J3) ................15 Bill of Materials/ Schematics ....................16 PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 5 IGURES Figure 1-1. PEX 8647-AA RDK Component Side View ............. 1 Figure 2-1. PEX 8647-AA RDK Hardware Architecture ............. 4 Figure 2-2. PCI Express Gen 2 Connections ................5 Figure 2-3. PEX 8647-AA RDK Reference Clock Circuit ............7 Figure 2-4. PEX 8647-AA RDK Reset Circuit ................8 Figure 2-5.

  • Page 6: General Information

    1. General Information The PLX PEX 8647-AA RDK is a Rapid Development Kit (RDK) based on the PEX 8647, a 48-lane, 3-port PCI Express Gen 2 (5.0 GT/s) switch. The PEX 8647-AA RDK provides a complete hardware and software development platform in order to facilitate and accelerate the evaluation of the PEX 8647 while lowering the design risk and reducing time-to-market.

  • Page 7: Pex 8647-Aa Rdk Features

    IEEE Standard 1149.6-2003, IEEE Standard Test Access Port and Boundary-Scan Architecture Extensions (IEEE Standard 1149.6-2003) C-Bus Specification, Version 2.1 (I C Bus v2.1) The I PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 8: Pex 8647-Aa Rdk Hardware Architecture

    Two ATX Hard disk Power connectors supply a maximum of 150 watts to the downstream slots • Voltage level monitoring circuit for 1.0V and 2.5V power to the PEX 8647 PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 9: Figure 2-1. Pex 8647-Aa Rdk Hardware Architecture

    2. PEX 8647-AA RDK Hardware Architecture Figure 2-1. PEX 8647-AA RDK Hardware Architecture PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 10: Pci Express Gen 2 Connections

    PCI Express Gen 2 Connections The PEX 8647-AA RDK is designed around the PEX 8647 and is based on the form factor defined in the PCI Express CEM 2.0 specification. The RDK contains one upstream port, two downstream ports, and six midbus footprints to allow access to test equipment, such as protocol analyzers, to all PCI Express differential signals.

  • Page 11: Pci Express Card Edge P1

    PCI Express Card Edge P1 The PEX 8647-AA RDK can plug directly into a x16 PCI Express slot. Port 0, which consists of lane 0 to lane 15, is connected to the PCI Express Card Edge connector (P1) through two midbus probe footprints (JP5 and JP6).

  • Page 12: Reset Circuitry

    Power Distribution The PEX 8647-AA RDK has two sources for DC power. The first source is the card edge connector (P1). The x16 connector provides up to 5.5A at 12V and 3.0A at 3.3V. Card edge power is intended to power only RDK board components.

  • Page 13: Led Indicators

    Figure 2-5. PEX 8647-AA RDK Power Subsystem LED Indicators The PEX 8647-AA RDK provides a number of LED indicators including power-on indication, PEX 8647 port link status indication, fatal error indication, event/error indication, and voltage level monitoring indications. Table 2-1 provides a quick explanation of the various board indicators.

  • Page 14: Port Link Status Indication (D10 - D12)

    Port Link Status Indication (D10 – D12) The PEX 8647-AA RDK provides three green color link status LEDs (D10, D11 and D12) to indicate its port 0, port 4, and port 8 link states respectively. LED on, off, and three blinking patterns cover all five states of port link status.

  • Page 15: Reserved Pins

    STRAP_RESERVED17# Set DIP switch to OFF (logic ‘HIGH’) STRAP_RESERVED18# Pull-up with a 4.7K ohm resistor STRAP_RESERVED19# Pull-up with a 4.7K ohm resistor PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 16: On-Board Connectors, Switches, And Jumpers

    3. On-Board Connectors, Switches, and Jumpers DIP Switches The PEX 8647-AA RDK contains one user controllable DIP switch (SW2) for selecting the lower three bits of I address. Each DIP switch position can be either ON (logic ‘LOW) or OFF (logic ‘HIGH). The white squares Figure 3-1 indicate which way the switch is connected.

  • Page 17: Midbus Footprints (Jp1 - Jp6)

    MidBus Footprints (JP1 – JP6) PEX 8647-AA RDK provides six strategically placed midbus probe footprints. Each footprint provides 16 channels and each can support eight PCI Express lanes. The midbus footprints are based on Agilent’s Soft Touch Midbus Probe, as shown in...

  • Page 18: Header (Jp7)

    JTAG_TDO JTAG_TMS JTAG_TCK 2,4,6,8,10 Port (JP9 – JP10) Table 3-5. Pin assignment of JP9 and JP10 Pin # Signal name I2C_SCL I2C_SDA PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 19: Reference Clock Header (J1)

    ATX HD Power Connector (J2 – J3) Table 3-7. Pin assignment of J1 Pin # Signal name +12VDC COM (GND) COM (GND) +5VCC PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...

  • Page 20: Bill Of Materials/ Schematics

    Cap, Ceramic, 0.1uF, SMT, 0603 C108,C123, KAT2A X7R, 16V, 10% C110,C112,C1 0603YD105 Cap, Ceramic, 1uF, X5R, SMT, 0603 14,C116, KAT2A 16V, 10% C119-C120 PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 21 9C06031A5 Res. 1/10W, 5.76K ohm, SMT, 0603 5.769KHCT- America 761FKHFT Yageo 9C06031A7 Res. 1/10W, 7.32K ohm, 311- SMT, 0603 America 321FKHFT 7.32KHCT-ND PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 22 1x2 th Jumper shunts, for 0.1" AMP/Tyco 382811-6 2-pin hdr. Customer Name PLX Part # 91-0081-101-A Product Name PEX8647RDK Date May 23, 2008 PEX 8647-AA RDK Hardware Reference Manual, Version 1.2 Copyright © 2008 by PLX Technology, Inc. All rights reserved...
  • Page 23 Reset Express Slots Converters Circuit LEDs DIPSWITCHES INTERFACE PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
  • Page 24 TX30n AD25 RX39p TX39n RX47p TX47n RX22n RX30n RX39n RX47n TX23p TX31p PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. RX23p TX23n RX31p TX31n PEX8647AA_27X27 PEX8647AA_27X27 RX23n RX31n 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085...
  • Page 25 ITP7 ITP7 ITP8 ITP8 ITP9 ITP9 ITP10 ITP10 ITP11 ITP11 ITP12 ITP12 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. ITP13 ITP13 ITP14 ITP14 ITP15 ITP15 ITP16 ITP16 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 26 GREEN DR_3 5V_A GREEN GREEN CMD15-22SRUGC CMD15-22SRUGC DR_4 3.3VCC PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. DR_5 3.3V_A GREEN GREEN 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 27 STRAP_RESERVED16 SPARE0 R81 is not loaded PEX8647AA_27X27 PEX8647AA_27X27 as default PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com...
  • Page 28 0.1uF 0.1uF 10uF 10uF 10uF 10uF TP16 TP16 PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. PLX TECHNOLOGY, INC. 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 870 W Maude Ave, Sunnyvale, CA 94085 www.plxtech.com www.plxtech.com www.plxtech.com...
