Daikin FTXP20-71L Service Manual page 166

6 | Technical data
Service manual
166
R3T
SA1
S20-S90
V2, V3
X1M
Y1S
PTC1
Y1E
Z*C
Z*F
ARXP20~35N + RXP20~35N
(1) Wiring diagram
English
Wiring diagram
Indoor
Outdoor
Condenser
Discharge
(2) Notes
English
Note:
X1M
NOTES:
BLK : Black
WHT : White
BRN : Brown
RED : Red
GRN : Green
YLW : Yellow
ORG : Orange
BLU : Blue
Thermistor (discharge)
Surge arrestor
Connector
Varistor
Terminal strip
Reversing solenoid valve coil
Thermistor
Electronic expansion valve
Noise filter (ferrite core)
Noise filter
Translation
Wiring diagram
Indoor
Outdoor
Condenser
Discharge
Translation
Note
Connection
Main terminal
Field supply
PCB
Protective earth
Earth
Field wire
ATXP20~35 + FTXP20~71 + ARXP20~35 + RXP20~71
Split Comfora R32
