- Page 1 User reference guide Daikin room air conditioner FTXP20N5V1B9 FTXP25N5V1B9 FTXP35N5V1B9 ATXP20N5V1B9 ATXP25N5V1B9 ATXP35N5V1B9...
-
Page 2: Table Of Contents
8.1.1 Symptom: A sound like water flowing is heard ..................... 38 8.1.2 Symptom: A blowing sound is heard......................38 8.1.3 Symptom: A ticking sound is heard........................ 38 User reference guide FTXP20~35N5V1B9 + ATXP20~35N5V1B9 Daikin room air conditioner 4D520466-17M – 2023.08... - Page 3 Symptom: The outdoor fan rotates while the air conditioner is not in operation ........39 Solving problems based on error codes ......................... 39 Troubleshooting for wireless LAN connection ....................... 40 9 Disposal 10 Glossary FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
-
Page 4: About The Documentation
User reference guide: Detailed step-by-step instructions and background information for basic and advanced usage Format: Digital files on https://www.daikin.eu. Use the search function find your model. Latest revisions of the supplied documentation may be available on the regional Daikin website or via your installer. - Page 5 Example: " 1–3 Figure title" means "Figure 3 in chapter 1". Indicates a table title or a reference to it. Example: " 1–3 Table title" means "Table 3 in chapter 1". FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
-
Page 6: User Safety Instructions
Do NOT place any objects containing water on the unit. CAUTION ▪ Do NOT place any objects or equipment on top of the unit. ▪ Do NOT sit, climb or stand on the unit. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 7: Instructions For Safe Operation
Always have qualified service personnel confirm that the point of leakage has been repaired or corrected before resuming operation. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... - Page 8 Do NOT use cleaning materials or means to accelerate the defrosting process other than those recommended by the manufacturer. ▪ Be aware that the refrigerant inside the system is odourless. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
- Page 9 Leaving the unit running under such circumstances may cause breakage, electrical shock or fire. Contact your dealer. WARNING: MILDLY FLAMMABLE MATERIAL The refrigerant inside this unit is mildly flammable. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
-
Page 10: About The System
INFORMATION The following figures are just examples and may NOT completely match your system layout. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 11: Indoor Unit Display
▪ Curtains. Make sure that curtains or other objects do NOT block the signal between the unit and the wireless remote control. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 12: Components: Wireless Remote Control
LCD display 3.2.2 Status: Wireless remote control LCD Icon Description Operation mode = Automatic Operation mode = Drying Operation mode = Heating Operation mode = Cooling FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 13: To Operate The Wireless Remote Control
Result: When the indoor unit receives a signal from the wireless remote control, you will hear a sound: Sound Description Beep-beep Operation starts. Beep Setting changes. Long beep Operation stops. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 14: Before Operation
1 Choose a place where the signals reach the unit. 2 Attach the holder with screws to the wall or a similar location. 3 Hang the wireless remote control on the holder. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 15: To Turn On The Power Supply
4.4 To turn on the power supply 1 Turn the circuit breaker on. Result: The flap of the indoor unit will open and close to set the reference position. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 16: Operation
To adjust the amount of air blown into the Airflow rate room. To run more quietly. Advanced features To use the system when you are also using Econo other power-consuming appliances. To save energy. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 17: Operation Mode And Temperature Setpoint
In that case, the system automatically switches to defrosting operation to remove the frost. During defrosting operation, hot air is NOT blown from the indoor unit. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 18: To Start/Stop Operation Mode And To Set The Temperature
When using drying operation mode, you CANNOT adjust the airflow rate setting. 5.4.1 To adjust the airflow rate 1 Press to change the airflow setting as follows: FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 19: Airflow Direction
LCD. The flaps (horizontal blades) will begin to swing. 2 To use fixed position, press when the flaps reach the desired position. Result: disappears from the LCD. The flaps will stop moving. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 20: To Adjust Horizontal Airflow Direction
Result: The flap position will change, is displayed on the LCD, and the airflow rate is set to automatic. Mode Position of flap… Cooling/Drying Heating Down FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 21: Powerful Operation
This function is useful for cases in which attention should be paid to ensure a circuit breaker will not trip when the product runs alongside other appliances. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 22: To Start/Stop Econo Operation
Program the timer again in case of: ▪ A breaker has turned the unit off. ▪ A power failure. ▪ After replacing batteries in the wireless remote control. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 23: To Start/Stop Off Timer Operation
NOT operating, operation will start after 2 hours. 3 To cancel the setting, press Result: and the time setting disappear from the LCD and the timer lamp goes off. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 24: To Combine Off Timer And On Timer
1 Go to Google Play (for Android devices) or the App Store (for iOS devices) and search for "ONECTA". 2 Follow the directions on the screen to install the ONECTA app. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 25: To Set The Wireless Connection
2 Press to confirm the selection. Result: is blinking. 3 Check the operation and timer LEDs on the indoor unit display. ON/OFF a Operation LED b Timer LED FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... - Page 26 5 seconds while the unit is not operating. Result: The SP menu appears. is blinking. 2 Change to the SP menu by pressing once or repeatedly. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
- Page 27 The operation and timer LEDs are blinking alternately in 1 s interval. Communication is OFF. 4 Press to exit the menu. Result: The display will return to the default screen. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
-
Page 28: Energy Saving And Optimum Operation
Adjust the air flow direction to avoid cool air from gathering on the floor or warm air against the ceiling. (Up during cooling or dry operation to the ceiling and down during heating operation.) ▪ Avoid direct air flow to room inhabitants. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... - Page 29 Energy saving and optimum operation ▪ Operate the system within the recommended temperature range (26~28°C for cooling and 20~24°C for heating) to save energy. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
-
Page 30: Maintenance And Service
To clean the air conditioner or air filter, be sure to stop operation and turn all power supplies OFF. Otherwise, an electrical shock and injury may result. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 31: To Clean The Indoor Unit And Wireless Remote Control
7.3 To clean the front panel 1 Clean the front panel with a soft cloth. If it is difficult to remove stains, use water or a neutral detergent. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 32: About The Air Filters
3 Remove the titanium apatite deodorising filter and silver particle filter from the tabs. a Tab 4 Wash the air filters with water or clean them with a vacuum cleaner. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 33: To Clean The Titanium Apatite Deodorising Filter And The Silver Particle Filter (Ag-Ion Filter)
(Ag-ion filter) INFORMATION Clean the filter with water every 6 months. 1 Remove the titanium apatite deodorising and silver particle filters from the tabs. a Tabs FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 34: To Replace The Titanium Apatite Deodorising Filter And The Silver Particle Filter (Ag-Ion Filter)
7.10 To take following items into account before a long idle period 1 Set the mode to fan only by pressing button to dry the inside of the unit. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... - Page 35 Maintenance costs shall be borne by the customer. In certain operating conditions the inside of the unit may get dirty after several seasons of use. This results in poor performance. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
-
Page 36: Troubleshooting
▪ The air conditioner may stop operating after sudden large voltage fluctuations to protect the system. It automatically resumes operation after about 3 minutes. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... - Page 37 (with manufacturing number if possible) and the installation date (possibly listed on the warranty card). FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
-
Page 38: Symptoms That Are Not System Malfunctions
Moisture generated by defrost becomes steam and exits. 8.1.8 Symptom: The units can give off odours The unit can absorb the smell of rooms, furniture, cigarettes, etc., and then emit it again. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 39: Symptom: The Outdoor Fan Rotates While The Air Conditioner Is Not In Operation
Signal transmission error (between indoor and outdoor unit) Indoor/outdoor unit combination fault Indoor unit Error code Description Indoor unit PCB abnormality Freeze-up protection or high-pressure control Fan motor (DC motor) abnormality FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... -
Page 40: Troubleshooting For Wireless Lan Connection
(none of the LEDs on the interface. indoor unit display are blinking). ▪ Check if the power is on. ▪ Turn the unit off and back on again. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... - Page 41 Measured temperature for other appliances may differ due to different condition around the unit (e.g. direct sunlight, frost accumulation…) ▪ Temperature displayed in ONECTA is only referential. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08...
-
Page 42: Disposal
Do NOT try to dismantle the system yourself: dismantling of the system, treatment of the refrigerant, oil and other parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. FTXP20~35N5V1B9 + ATXP20~35N5V1B9 User reference guide Daikin room air conditioner 4D520466-17M – 2023.08... - Page 43 Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with the product according to the instructions in the accompanying documentation.
- Page 44 DAIKIN ISITMA VE SOĞUTMA SİSTEMLERİ SAN.TİC. A.Ş. Gülsuyu Mahallesi, Fevzi Çakmak Caddesi, Burçak Sokak, No:20, 34848 Maltepe İSTANBUL / TÜRKİYE Tel: 0216 453 27 00 Faks: 0216 671 06 00 Çağrı Merkezi: 444 999 0 4D520466-17M Web: www.daikin.com.tr 2023.08 Verantwortung für Energie und Umwelt...
