  • Page 1 Connaught / Hampshire / Somerset Entryway Storage Bench Model # 3AXCCON-09...
  • Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Ac vate your 1-year warranty ü...
  • Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards. You may even receive store credit on your en re purchase! simpli-home.com/share-images...
  • Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order informa on and issue. Submit form.

  • Page 5: Safety Information

    IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all the parts and hardware required. Hardware package may have spare parts.

  • Page 6: Care And Maintenance

    Care & Maintenance This furniture is designed for indoor use. Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions.
  • Page 7 Pre-Assembly Information Model # 3AXCCON-09 Part Description SEAT LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 FRONT BACK DIVIDER QTY 1 QTY 1 QTY 1 BACKREST BOTTOM PANEL BOTTOM SUPPORT LEG QTY 1 QTY 1 QTY 1...

  • Page 8: Pre-Assembly Information

    Pre-Assembly Information Model # 3AXCCON-09 Hardware Description CAM LOCK PIN ALLEN KEY SCREW WOOD DOWEL CAM LOCK M6 x 30 mm 8 X 30 mm QTY 12 QTY 4 SET QTY 10 PHILLIPS SCREW ROUND HEAD PHILLIPS SCREW M4 X 15 mm M4 X 15 mm ALLEN KEY QTY 4...
  • Page 9 Components - Key Diagram Components - Key Diagram Model # 3AXCCON-09 Model # 3AXCCON-09...
  • Page 10 Assembly Model # 3AXCCON-09 Step 1 1. Attach 2 Cam Lock Pins 2 to Back D into guide holes. 2. Align and insert Cam Lock Pins on Back D into pre-drilled holes on Dividers E . ( Note: please pay close attention to the location of the 2 small guide holes which accommodate the lid support.
  • Page 11 Assembly Model # 3AXCCON-09 Step 2 1. Attach Bottom Panel G to Divider E & Back D by sliding on the gap between Divider E & the long rail on Back D .
  • Page 12 Assembly Model # 3AXCCON-09 Step 3 1. Attach 2 Cam Lock Pins 2 to Front C into guide holes. 2. Align and insert Cam Lock Pins on Front C into pre-drilled holes on Dividers E . 3. Place 2 Cam Locks 2 into pre-drilled holes on Dividers E . 4.
  • Page 13 Assembly Model # 3AXCCON-09 Step 4 1. Insert 5 Dowels 3 into each Side BL , BR at specified location. 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of Dowels should be exposed. 3.
  • Page 14 Assembly Model # 3AXCCON-09 Step 5 1. Attach Bottom Support Leg H into pre-drilled holes of Bottom Panel G using 4 Phillips Screws 7 . 2. Use Phillips screwdriver to tighten Screws. Do not over-tighten. Step 6 1. Attach Seat A to Back D using 6 Phillips Screws 6 (using guide holes on bar of Back). 2.
  • Page 15 Assembly Model # 3AXCCON-09 Step 7 1. Attach Lid Supports 9 into pre-drilled holes of Seat A and Divider E using Phillips Screws Round Head 5 . 2. Use phillips screwdriver to tighten Screws. Do not over-tighten. Step 8 1. Insert 4 Wood Bolt Caps 10 into exposed bolt holes on side of bench.
