- Page 1 SIMP HOME L I F E B Y D E S I G N CONNAUGHT / HAMPSHIRE / SOMERSET END/SIDE TABLE WITH TRAY MODEL # 3AXCCON-03 1/15...
- Page 2 SIMP HOME L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts. -
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. - Page 5 MODEL # 3AXCCON-03 PRE-ASSEMBLY INFORMATION PARTS DESCRIPTION SIDE (L&R Same) QTY 2 QTY 1 FRONT BACK QTY 1 QTY 1 TRAY BOTTOM PANEL QTY 1 QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.
- Page 6 PRE-ASSEMBLY INFORMATION MODEL # 3AXCCON-03 HARDWARE DESCRIPTION ALLEN KEY SCREW WOOD DOWEL CAM LOCK PIN M6 X 30 mm Ø8 X 30 mm CAM LOCK QTY 8 QTY 8 QTY 8 SETS PHILLIPS SCREW ROUND HEAD PHILLIPS SCREW M4 X 15 mm M3.5 X 15 mm ALLEN KEY QTY 8...
- Page 7 COMPONENTS – KEY DIAGRAM MODEL # 3AXCCON-03 7/15...
- Page 8 ASSEMBLY MODEL # 3AXCCON-03 STEP 1 1. Insert 4 Dowels 3 into pre-drilled holes on each Side B . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of Dowels should be exposed. 3. Attach 4 Cam Lock Pins 2 to Side B into guide holes. 4.
- Page 9 ASSEMBLY MODEL # 3AXCCON-03 STEP 2 1. Attach Bottom Panel E to Front C & Back D by sliding on the gap on the long rail on Front C & Back D . 9/15...
- Page 10 ASSEMBLY MODEL # 3AXCCON-03 STEP 3 1. Repeat Step-1 for the second Side B . 10/15...
- Page 11 ASSEMBLY MODEL # 3AXCCON-03 STEP 4 NOTE: The screwdriver is not included in the hardware pack. 1. Attach Top A to 2 hinges on Back D using Phillips Screws 6 ( using guide holes underneath of top ). 2. Use phillips screwdriver to tighten Screws. Do not over-tighten. 11/15...
- Page 12 ASSEMBLY MODEL # 3AXCCON-03 STEP 5 Lid Support-Left NOTE: The screwdriver is not included in the hardware pack. Lid Support-Right 1. Attach ( left and right ) Lid Supports 9 into pre-drilled holes on Sides B and Top A using Phillips Screws Round Heads 5 . 2.
- Page 13 ASSEMBLY MODEL # 3AXCCON-03 STEP 6 NOTE: The screwdriver is not included in the hardware pack. 1. Attach Magnet Plates 8 to bottom corner of Top A using Phillips Screws 7 into guide holes on Top A . 2. Attach Magnets 8 to Sides B using Phillips Screws 7 into guide holes on Sides B . 3.
- Page 14 ASSEMBLY MODEL # 3AXCCON-03 STEP 7 1. Insert Tray F into slots on the bar of Front C & Back D . 14/15...
-
Page 15: Warranty
SIMP HOME L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
