- Page 1 Draper / Tierney / Baxter Mid Century Low Storage Cabinet Model # 3AXCDRP-05...
- Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Activate your 1-year warranty ü...
- Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards.
- Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order information and issue. Submit form.
-
Page 5: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 6: Care And Maintenance
Care & Maintenance This furniture is designed for indoor use. Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions. -
Page 7: Bottom Shelf
Pre-Assembly Information Model # 3AXCDRP-05 Part Description LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF DIVIDER CABINET SHELF QTY 1 QTY 1 QTY 2 Warning Label DOOR (L&R Same) LEFT BACK PANEL RIGHT BACK PANEL QTY 2 QTY 1 QTY 1 LEG (L&R Same) - Page 8 Pre-Assembly Information Model # 3AXCDRP-05 Hardware Description ALLEN KEY SCREW ALLEN KEY M6 X 30mm QTY 1 QTY 18 PHILLIPS SCREW ROUND HEAD PHILLIPS SCREW SHELF SUPPORT M4 X 15mm M3 X 12mm QTY 12 QTY 18 QTY 12 PHILLIPS SCREW M3 X 15mm MAGNET AND PLATE QTY 8...
- Page 9 Components - Key Diagram Model # 3AXCDRP-05 Warning Label...
- Page 10 Assembly Model # 3AXCDRP-05 Step 1 1. Attach 2 Sides AL , AR and Divider D to Bottom Shelf C using 9 Allen Key Screws 1 through guide holes (3 screws on each Divider and Side). 2. Use Allen Key 3 to tighten screws. Do not over-tighten.
- Page 11 Assembly Model # 3AXCDRP-05 Step 2 1. Attach Top B to 2 Sides AL , AR and Divider D using 9 Allen Key Screws 1 through guide holes (3 screws on each Divider and Side) . 2. Use Allen Key 3 to tighten screws. Do not over-tighten.
- Page 12 Assembly Model # 3AXCDRP-05 Step 3 1. Attach Legs H1 , H2 to Bottom Shelf C using 8 sets Allen Key Bolts, Lock Washers and Washers 2 through guide holes ( 2 sets on each Leg ). 2. Use Allen Key 3 to tighten Bolts. Do not over-tighten.
- Page 13 Assembly Model # 3AXCDRP-05 Step 4 NOTE: The screwdriver is not included in the hardware pack. Warning Label 1. Use Phillips Screws Round Head 5 to attach Back Panels FL , FR through guide holes from Back Panels to back of cabinet. 2.
- Page 14 Assembly Model # 3AXCDRP-05 First Step Last Step ( after adjust the door ) Step 5...
- Page 15 Assembly Model # 3AXCDRP-05 Step 6 shelf level 1 shelf support anti - tipping shelf level 2 shelf level 3 1. Attach 4 Shelf Supports 4 underneath of each Cabinet Shelf E in desired location. 2. 2 Shelf Supports 4 must be attached on back top of each Cabinet Shelf E as a tipping restraint.
- Page 16 Furniture Tip Over Restraint Assembly WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. Step 7 NOTE: The screwdriver is not...
- Page 17 Furniture Anti-Tipping Restraint Instructions Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
