- Page 1 Model CV385-PRO Operating and Assembly Manual Midwest Equipment Mfg. 5225 Serum Plant Road Thorntown, IN 46071 2-09-16...
-
Page 2: Safety Rules
SAFETY RULES Remember, any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when using power equipment. This symbol means Attention!!!!! It is used to point out safety precautions. ▪... - Page 3 Model CV385-PRO Trac-Vac Parts List Part No. Description Qty. 38010 Engine Frame, RH 38012 Container Frame, 380 38015 Vertical Upright, 380 56018 *Engine, 6.5HP Intek Pro 38030 Turbine Housing, Chipper 56055 Turbine, Chipper Pro Series 56107 Turbine Washer 38050 Inlet, Chipper 6"...
- Page 4 Trac-Vac Model CV385-PRO Accessories: 2-09-16...
- Page 5 Model CV385 Trac-Vac Assembly Instruction 1. Slip wheel (9) over container frame (2) axle pin, trapping 3/4" flatwasher on both sides of wheel. Secure with 1/8" x 1" cotter key. Repeat procedure with opposite wheel. Fig 1 2. Place frame (2) on blocks and level the frame with axles towards the bottom and frame channels facing upwards.
- Page 7 CHIPPER VAC INSTRUCTIONS The chipper components on your chipper vac have been fully assembled at the factory. The chipper operates most efficiently at 20% of normal vacuuming air flow. To reduce air flow, you may want to remove the chute from the mower deck and face its opening to the ground. Your chipper vac is designed to accommodate limbs up to 2 ½”...
-
Page 8: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Engine fails to start 1. Spark plug wire disconnected 1. Connect wire to spark plug 2. Fuel tank empty 2. Fill tank with clean fuel 3. Faulty spark plug 3. Clean, adjust gap or replace Loss of power or 1. - Page 9 4. Clean tires and check pressure. Raising and supporting unit with weight off tires is recommended. 5. When storing a unit with Rubbermaid containers, leave containers latched to top. TRAC VAC WARRANTY POLICY Midwest Equipment Mfg. will repair or replace, free of charge, any part, or parts that are defective in material or workmanship or both for a period of one year residential use, and 90 days for commercial and rental use.
