- Page 1 Model 682-IC/PRO/H/R Operating and Assembly Manual Midwest Equipment Manufacturing, Inc. 5225 Serum Plant Road Thorntown, IN 46071 06-28-16...
-
Page 2: Safety Rules
SAFETY RULES Remember, any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when using power equipment. This symbol means Attention!!!!! It is used to point out safety precautions. ▪... - Page 3 Trac-Vac Model 682 Key Qty P/N Desc. Desc. 1 68210 Frame, 682 29 2 56102 Hose Clamp, 6" 1 68211 Support Brkt. 30 1 58104 Hitch Pin 1 68017 Axle Holder Brace 31 1 58071 Jack Stand 2 68014 Axle Support 32 1 32108 Spring 1 68018...
- Page 4 Model 682 Assembly Instructions 1.) Position axle support (4) into main frame (1). Secure axle support, in the front mounting hole with 3/8" x 3/4" bolts and whizlock nuts. (Note: Axle tube should be closest to the rear of the frame.) Position the support bracket (2) onto the rear of the frame and line up the two holes with the two mounting holes for the axle support.
- Page 5 5.) Spin 5/16" whizlock nuts onto eyebolts (35). Fit (2) eyebolts through eyebolt brackets on vertical uprights and secure with 5/16" whizlocks. Open up the eye on the 3rd eyebolt enough to slip the pull start rope thru. Secure it thru lower hole in the upright with whizlock nut as illustrated. 6.) Set container holders (12) onto container holder frames (11).
- Page 6 9.) Slide exhaust boot through opening on molded top with lip on the outside. Secure with 1/4" x 3/4" truss head screws and 1/4" whizlock nuts. 10.) Slide one hose clamp (29) onto one end of 6" x 42" hose (28) and slip the hose onto the neck of the exhaust boot and tighten hose clamp.
- Page 7 14.) Install chute on mower deck of tractor. Attach the Model 682 to tractor. Turn tractor until rear wheel opposite discharge contacts frame. If rear wheel is to close to inlet, extend the adjustable drawbar (10). Install hose support arm (24) into frame and support arm extension (25) into support arm. Slip hose clamp over end of intake hose and attach hose to intake on blower housing and tighten hose clamp.
-
Page 8: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Engine fails to start 1. Spark plug wire disconnected 1. Connect wire to spark plug 2. Fuel tank empty 2. Fill tank with clean fuel 3. Faulty spark plug 3. Clean, adjust gap or replace Loss of power or 1. -
Page 9: Engine Maintenance
DANGER: The Trac-Vac was built to be operated according to the rules for safe operation in this manual. Carelessness or error on the part of the operator can result in serious injury. This unit is capable of amputating fingers or hands and throwing objects. Failure to comply with the safety instructions could result in serious injury or death. - Page 10 NOTES...
-
Page 11: Operating Procedure
4. Clean tires and check pressure. Raising and supporting unit with weight off tires is recommended. 5. When storing a unit with Rubbermaid containers, leave containers latched to top. TRAC VAC WARRANTY POLICY Midwest Equipment Manufacturing, Inc. will repair or replace, free of charge, any part, or parts that are defective in material or workmanship or both for a period of one year residential use, and 90 day’s for commercial and rental use.
