PSE530-TF2Z041EN
4 Wiring (continued)
• The sensor connectors cannot be re-used once they have been
pressed fully closed. If connection failure or incorrect wiring occurs a
new sensor connector must be used.
• When connecting the sensor to a PSE200 / PSE300 series monitor,
use the connector for sensor lead wire (ZS-28-C) or an e-Con*
connector from the table below.
Maker
Model No.
Sumitomo 3M
37104-3101-000FL
Tyco Electronics
3-1473562-4
OMRON
XN2A-1430
* Refer to the manufacturers e-Con connector catalogue.
5 How to Order
Refer to the catalogue or operation manual on the SMC website (URL:
https://www.smcworld.com) for How to order information.
6 Outline Dimensions (mm)
Refer to the catalogue or operation manual on the SMC website (URL:
https://www.smcworld.com) for outline dimensions.
7 Maintenance
7.1 General Maintenance
Caution
• Not following proper maintenance procedures could cause the
product to malfunction and lead to equipment damage.
• If
handled
improperly,
compressed
air
can
be
dangerous.
Maintenance of pneumatic systems should be performed only by
qualified personnel.
• Before performing maintenance, turn off the power supply and be
sure to cut off the supply pressure. Confirm that the air is released to
atmosphere.
• After installation and maintenance, apply operating pressure and
power to the equipment and perform appropriate functional and
leakage tests to make sure the equipment is installed correctly.
• If any electrical connections are disturbed during maintenance,
ensure they are reconnected correctly and safety checks are carried
out as required to ensure continued compliance with applicable
national regulations.
• Do not make any modification to the product.
• Do not disassemble the product, unless required by installation or
maintenance instructions.
8 Limitations of Use
8.1 Limited warranty and Disclaimer/Compliance Requirements
Refer to Handling Precautions for SMC Products.
9 Product disposal
This product should not be disposed of as municipal waste. Check your
local regulations and guidelines to dispose of this product correctly, in
order to reduce the impact on human health and the environment.
10 Contacts
Refer to
www.smcworld.com
or
www.smc.eu
for your local distributor /
importer.
URL :
https://www.smcworld.com
(Global)
https://www.smc.eu
(Europe)
SMC Corporation, 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, Japan
Specifications are subject to change without prior notice from the manufacturer.
© 2021 SMC Corporation All Rights Reserved.
Template DKP50047-F-085M
Page 2 of 2
