- Page 1 Doc. no.IZ*-OMK0023-B PRODUCT NAME Electrostatic Sensor MODEL / Series / Product Number IZD10-*10...
-
Page 2: Table Of Contents
Contents Safety Instruction ..........................2 Outline ..............................7 How to Order ............................8 Specification ............................8 Mounting .............................. 8 5-1. Electrostatic sensor installation ....................8 5-1-1. Sensor head installation ....................... 8 5-1-2. Installation of the sensor amplifier ..................9 5-2. Circuitry and wiring chart ...................... -
Page 3: Safety Instruction
1.Safety Instruction These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 1.Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
- Page 5 Selection Warning (1) This product is intended to be used for general FA equipment. (2) Keep specified voltage and temperature range to avoid malfunction, damage, electric shock and fire. (3) This product is not explosion proof. Don’t use environment where explosion by particle is possible or containing flammable/explosive gas. Caution (1) This product is not cleaned.
- Page 6 (7) Do not apply tape/seal to the body to avoid electrification which disables correct detection of electrified potential. (8) Stop supplying the power to the electrostatic sensor during installation and adjustment. (9) Keep the distance for installation so that the sensor head is not charged. (See Effective inspection distance : “4.
- Page 7 Operating / Storage environment Warning (1) Keep operating ambient temp. range Operating ambient temp. range is 0 to 50 Even if ambient temp. is within spec. range, environment with sharp temp. change will can form dew. Don’t use it there. (2) Environment to avoid Do not operate nor store the product under following environment to avoid failure.
-
Page 8: Outline
2. Outline Electrostatic sensor consists of the sensor head and sensor amplifier. 1500mm 3500mm Sensor Sensor head Part A amplifier Electrostatic sensor has two types of sensors below. # Model : IZD10-110 The purpose is to confirm electricity elimination effect of the ionizer. The sensor is set so that Inspected charged potential is output in relatively small range of potential. -
Page 9: How To Order
3.How to Order IZD10 - * 10 Measuring range +/- 0.4kV +/- 20kV 4.Specification Electrostatic sensor IZD10-110 IZD10-510 model no. +/- 0.4kV +/- 20kV Measuring range ＊１ ＊１ (when detection distance 25mm) (when detection distance 50mm) Output voltage 1 to 5V (Output impedance Approx. 100ohms) Effective detection 10 to 50mm 25 to 75mm... -
Page 10: Installation Of The Sensor Amplifier
Bolt mount surface Detection hole Sensor head M3 screws Sensor head Mate M3 bolt to the bolt mount surface. Mounting from the opposite side leads to cause the breakage of the sensor head. The sensor head body is common with GND due to the sensor structure. Attention should be taken not to short circuit +24V power source during installation and power supply. -
Page 11: Circuitry And Wiring Chart
5-2. Circuitry and wiring chart Wire leads according to circuitry and wiring chart. (1) Circuitry Color in ( ) indicates lead wire cover color of specified cable. Electrostatic sensor Sensor head Sensor amplifier DC[+] (Brown) Power source DC24V+/-10% DC[-] (Blue) 100 Ohms Sensor output (White) -
Page 12: Performance
6. Performance 6-1. Output signal When measuring the potential of charged object with electrostatic sensor, the relation between measured charged potential and output voltage depends on the sensor installation distance. See the chart below for the relation. (Installation distance in the chart indicates the distance between measured object and the electrostatic sensor.) Relation between sensor output and charged potential on installation distance... -
Page 13: Detection Range
6-2. Detection range Electrostatic sensor installation distance and detection range are shown below. IZD10-110 Sensor head Installation Detection range distance mm Detection hole IZD10-510 Detection range Installation Detection range distance mm Detection hole Sensor head 6-3. Cautions on installation When an object other than measured object is installed close to the electrostatic sensor, the sensor output can be different from actual value due to the effect of charged potential of installed object. -
Page 14: Timing Chart
6-4. Timing chart Chart below shows the timing chart when installation distance of IZD10-110(distance from measured subject) is 25mm. (50mm for IZD10-510) Time until operation stabilized :Note1 Power source(DC24V) 100ms or less (Output delay) 100ms or less (Output delay) Sensor output 1kV[25kV] 0.4kV[20kV] Charged... - Page 15 Revision history Revision A (October.30.2006) Addition of IZD10-510. Revision B (March.27.2024) The Safety Instructions. (p2, p3) The words deleted. (Please consult SMC for other application (esp. application described on (4) on previous page.) (p4) The back cover. (p14) Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
