Medina Series
Curved Desk
Model No. MND63/72
ASSEMBLY INSTRUCTIONS
CALL 1-800-822-8037 FOR ASSISTANCE
P/N
MNDT REV 3
02/27/15
TM
www.mayline.com
PARTS LIST
Spare
Name
Part
Qty.
Qty
HB
A
9
1
REALS001
Cam Lock
HB
B
4
1
REALS102**
Cam Sticker
HB
C
9
1
REALS003
Cam Post
NOTE:
. 1 Top and 1 Modesty Panel packed in one carton - MNDT63/MNDT72.
. 2 Legs with Hardware packed in one carton - MNDB.
Items with HB are in hardware box.
**Denotes Color Code
Spare
Name
Part
Qty.
Qty
HB
D
5
1
REALS102SLV
Cam Sticker/Silver
HB
E
5
REALS414
Base Stand-off
MNCNZHB
1
Advertisement
Table of Contents
Related Manuals for Mayline Medina MND63
Summary of Contents for Mayline Medina MND63
- Page 1 . 1 Top and 1 Modesty Panel packed in one carton - MNDT63/MNDT72. . 2 Legs with Hardware packed in one carton - MNDB. ASSEMBLY INSTRUCTIONS CALL 1-800-822-8037 FOR ASSISTANCE Items with HB are in hardware box. **Denotes Color Code MNDT REV 3 02/27/15 www.mayline.com...
- Page 2 Part Name Part Qty. Qty. improper assembly or installation. Mayline and/or its distributor are not responsible for failure resulting from improper assembly or installation of this product. Moreover, all warranties are void for failure to follow these assembly instructions. MNDB** MNDT~~** Insert Cams (A) into the Modesty Panel (K) and Base Legs (H1 &...
- Page 3 Install Base Stand-off (E) into threaded inserts in underside of Top (G). H1 & H2 NOTE: The arrow on the face of the Cam (A) should point towards the Base Stand-off (E) for proper alignment. ATTENTION: Due to the floating design of the Medina desk, Place Top (G) onto base and lock in place by turning Cams (A).
