NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
COMPONENTS
REF#
QTY.
1
1
2
1
3
2
HARDWARE BAG
REF#
QTY.
E1
16
E2
2
E3
2
E4
2
E5
4
E6
4
E7
2
E8
12
REV 04
11/01/12
P/N
ASSEMBLY INSTRUCTIONS
MEETING PLUS TABLES
When ordering components, specific color and/or size information may be required.
Contact a Mayline Customer Service Representative. 1-800-822-8037
DESCRIPTION
PART NO.
Top
Modesty Panel
Leg Assembly
(Part No. A7922**)
DESCRIPTION
PART NO.
Screw, 1/4-20
Caster Wheel
Caster Axle
Swivel Glide
End Cap
Screw, #10 x 3/4"
Grommet Edging
Washer, 9/32 x 1 x .06
CALL ~~**
** Denotes Color Code
~~Denotes Size
CALL ~~**
CALL ~~**
* Individual Items, Order by part number.
700124 *
700229 *
700230 *
700169 *
600109** *
X11 *
F682*
W83
(1)
Advertisement
Table of Contents
Related Manuals for Mayline MEETING PLUS
Summary of Contents for Mayline MEETING PLUS
- Page 1 MEETING PLUS TABLES NOTE: Please count and inspect all pieces before disposing of any carton or packing materials. When ordering components, specific color and/or size information may be required. COMPONENTS Contact a Mayline Customer Service Representative. 1-800-822-8037 REF# QTY. DESCRIPTION PART NO.
- Page 2 Assembly: 1. Assemble Glides (E4) into inner most threaded holes in Leg (3). Install End Caps (E5) into Leg (3). See Fig.#1 2. Slide the Axle (E3) into the Wheel (E2) and attach Axle (E3) to Leg Assembly (3) using Screws (E1). See Fig. 3.
- Page 3 Transition Table Assembly Only (Conference vs. Stadium) Note: Modesty Panel location has two options for assembly. 1. Begin Assembly by determining if the table will be used as Conference or Stadium position. See Fig. #6 2. Follow Instructions on page 2, Steps 1 - 7 Fig.
