Medina Series
Return Pedestal, P/B/F
Model No. MNBFP
ASSEMBLY INSTRUCTIONS
CALL 1-800-822-8037 FOR ASSISTANCE
P/N
MNBFP REV 3
02/27/15
TM
www.mayline.com
PARTS LIST
Name
Part
Qty.
HB
A
4
REALS032
Leveler
HB
B
16
REALS005
4x16mm
HB
C
2
REALS414
Stand-off
HB
D
2
REALS411
M6x30mm
Items with HB are in hardware box.
Name
Part
Qty.
HB
3
E
Handle-Silver
96mm Center
F
4
Handle Screw
M4x35mm White
Handle Screw
G
2
M4x25mm White
REALS410
HB
H
1
Keys
MNBFPHB
1
Advertisement
Table of Contents
Related Manuals for Mayline Medina Series
Summary of Contents for Mayline Medina Series
- Page 1 PARTS LIST Name Part Name Part Qty. Qty. Medina Series Return Pedestal, P/B/F Model No. MNBFP REALS032 Handle-Silver Leveler 96mm Center Handle Screw REALS005 M4x35mm White 4x16mm Handle Screw M4x25mm White REALS414 REALS410 Stand-off REALS411 Keys M6x30mm MNBFPHB ASSEMBLY INSTRUCTIONS CALL 1-800-822-8037 FOR ASSISTANCE Items with HB are in hardware box.
- Page 2 Review ALL instructions before beginning assembly. These instructions are provided to avoid problems that may occur from improper assembly or installation. Mayline and/or its distributor are not responsible for failure resulting from improper assembly or installation of this product. Moreover, all warranties are void for failure to follow these assembly instructions.
- Page 3 Pre-Installed Replacement Install the Top of MNRTNL / MNRTNR to the underside of MNBFP using Stand-off (C) and Screws (D). Attach Leviers (A) to underside of Pedestal using Screws (B). Parts List Included Included Part Part Qty. Qty. MNBFPDF** REALS422 Drawer Fronts, Set of 3 16"...
