Medina Series
Low Wall Cabinet Doors
Model No. MVLCD
ASSEMBLY INSTRUCTIONS
CALL 1-800-822-8037 FOR ASSISTANCE
P/N MVLCD REV 3
02/27/15
TM
www.mayline.com
Spare
Name
Part
Qty.
Qty
HB
K
8
1
REALS005
4x16mm
HB
L
8
1
REALS126
4X20mm
HB
M
2
REALS402
Lock w/Keys&Ring
HB
N
4
Handle-Silver
96mm Center
Handle Screw
M4x25mm White
O
8
1
REALS410
Items with HB are in hardware box.
Spare
Name
Part
Qty.
Qty
HB
R
2
REALS015
Latch
HB
S
4
REALS121
3x14mm
HB
T
2
REALS171
Bar Lock
HB
U
2
REALS106
Door Catch
MVLCDHB
1
1
