Mayline Medina Series Assembly Instructions
Bookcase, quarter rnd 2-shelf
Hide thumbs
Also See for Medina Series:
- Assembly instructions manual (10 pages) ,
- Assembly instructions (5 pages) ,
- Manual (3 pages)
Advertisement
Table of Contents
Medina Series
Bookcase, Quarter Rnd 2-Shelf
Model No. MVBQ2
ASSEMBLY INSTRUCTIONS
CALL 1-800-822-8037 FOR ASSISTANCE
P/N
MVBQ2 REV 2
02/27/15
TM
www.mayline.com
PARTS LIST
Spare
Name
Part
Qty.
Qty
HB
A
8
1
REALS004
Wood Dowel
HB
B
14
1
REALS003
Cam Post
HB
C
14
1
REALS001
Cam Lock
HB
D
14
1
REALS102**
Cam Sticker
HB
E
3
REALBY018
Leveler
Items with HB are in hardware box.
**Denotes Color Code
Spare
Name
Part
Qty.
Qty
HB
F
14
REALS238
4x14mm
HB
G
4
REALS065
Shelf Cam
HB
H
4
REALS066
Shelf Cam Post
MVBQ2HB
1
2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mayline Medina Series
Summary of Contents for Mayline Medina Series
- Page 1 PARTS LIST Spare Spare Name Part Name Part Qty. Qty. Medina Series Bookcase, Quarter Rnd 2-Shelf Model No. MVBQ2 REALS004 REALS238 Wood Dowel 4x14mm REALS003 REALS065 Cam Post Shelf Cam REALS001 REALS066 Cam Lock Shelf Cam Post REALS102** MVBQ2HB Cam Sticker...
- Page 2 These instructions are provided to avoid problems that may occur from improper assembly or installation. Mayline and/or its distributor are not responsible for failure resulting from improper assembly or installation of this product. Moreover, all warranties are void for failure...
- Page 3 Attach Levelers (E) to the Bottom Shelf (O) using Screws (F). Insert Shelf Cam (G) into Adjustable Shelf (N) with open slot in cam to edge of shelf. Screw Shelf Cam Posts (H) into Side Panels (L & M). Press Shelves onto Shelf Posts. Turn Shelf Cam (G) screw to lock in place.
