Fits:2007 - 2014
2007 - 2014
2007 - 2014
2007 - 2014
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT.
READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
DO NOT OVER TORQUE. STANDARD OPERATING LOAD FOR TIGHTEN
BODY MOUNT NUTS & BOLTS VARIES FROM 45 TO 65 FOOT POUND.
Qty
1
Tail Light Guard for Driver Side
2
Mounting Bracket
4
ST4.2 x 25.4 Screw
2
M6 Plastic piece
Driver/Left Taillight Guard
Page 1 of 3
Tail Light Guard
Part No. T0002B
Chevrolet Tahoe
Chevrolet Suburban
Cadillac Escalade
GMC Yukon / Yukon XL/Yukon Denali
Part Description
PARTS LIST:
Qty
1
Tail Light Guard for Passenger Side
2
M6 x 12 Nylon nut
2
M4 x 12 Phillips Screw
Passenger/Right Taillight Guard
Cutting Not
30-60 min
Required
support@trailfx.com
1 866 638 4870
POLISHED STAINLESS STEEL – LIMITED LIFETIME
POWDER COATED BLACK – 3 YEARS
Part Description
www.TrailFX.com
Drilling Not
Required
Rev 010118
