- Page 1 OPTISOUND 3020 Quick setup guide Ultrasonic Level Transmitter Foundation Fieldbus...
-
Page 2: Table Of Contents
Contents Contents For your safety ......................... 3 Authorised personnel ....................... 3 Appropriate use ........................ 3 Warning about incorrect use ..................... 3 General safety instructions ....................3 Safety label on the instrument ..................3 EU conformity ........................4 NAMUR recommendations ....................4 Product description ......................... -
Page 3: For Your Safety
1 For your safety For your safety Authorised personnel All operations described in this documentation must be carried out only by trained, qualified personnel authorised by the plant operator. During work on and with the device, the required personal protective equipment must always be worn. Appropriate use OPTISOUND 3020 C is a sensor for continuous level measurement. You can find detailed information about the area of application in chapter " Product description". Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions. -
Page 4: Eu Conformity
1 For your safety EU conformity The device fulfils the legal requirements of the applicable EU direc- tives. By affixing the CE marking, we confirm the conformity of the instrument with these directives. The EU conformity declaration can be found on our homepage. NAMUR recommendations NAMUR is the automation technology user association in the process industry in Germany. The published NAMUR recommendations are accepted as the standard in field instrumentation. The device fulfils the requirements of the following NAMUR recom- mendations: •... -
Page 5: Product Description
2 Product description Product description 2.1 Configuration Type label The type label contains the most important data for identification and use of the instrument: • Instrument type • Article and serial number device • Article number, documentation • Technical data: Approvals, process temperature, process fitting/ material, signal output, voltage supply, protection OPTISOUND 3020 • Foundation Fieldbus... -
Page 6: Mounting
3 Mounting Mounting Mounting instructions Reference plane for The reference plane for the measuring range is the lower edge of the measuring range transducer. Make sure that a minimum distance from the reference plane - the so-called dead zone, in which measurement is not possible - is maintained. The exact value of the dead zone is stated in chapter " Technical data". Fig. -
Page 7: Connecting To Power Supply
4 Connecting to power supply Connecting to power supply Connection procedure Proceed as follows: 1. Unscrew the housing lid 2. If a display and adjustment module is installed, remove it by turn- ing it to the left 3. Loosen compression nut of the cable gland and remove blind plug 4. Remove approx. 10 cm (4 in) of the cable mantle, strip approx. 1 cm (0.4 in) of insulation from the ends of the individual wires 5. Insert the cable into the sensor through the cable entry 6. Lift the opening levers of the terminals with a screwdriver (see following illustration) 7. -
Page 8: Wiring Plan, Single Chamber Housing
4 Connecting to power supply Wiring plan, single chamber housing Wiring plan Display I 2 C Fig. 4: Wiring plan - single chamber housing Voltage supply, signal output Wiring plan, double chamber housing Wiring plan I 2 C Fig. 5: Wiring plan - double chamber housing Voltage supply, signal output OPTISOUND 3020 •... -
Page 9: Set Up With The Display And Adjustment Module Plicscom
5 Set up with the display and adjustment module PLICSCOM Set up with the display and adjustment module PLICSCOM Insert display and adjustment module Mount/dismount display The display and adjustment module can be inserted into the sensor and adjustment module and removed again at any time. It is not necessary to interrupt the voltage supply. - Page 10 5 Set up with the display and adjustment module PLICSCOM ▶ Basic adjustment Display Diagnostics Service Info 2. Carry out the adjustment in the menu items " Min. adjustment" and " Max. adjustment". Max. adjustment 100.00 % 1.000 m(d) 2.000 m(d) Min. adjustment 0.00 % 5.000 m(d) 4.000 m(d)
- Page 11 5 Set up with the display and adjustment module PLICSCOM 100% Fig. 7: Parameterisation example, Min./max. adjustment Min. level = max. distance (depending on the sensor) 2 Max. level = min. distance (final value of the dead zone, depending on the sensor) Reference plane The actual product level during this adjustment is not important, because the min./max. adjustment is always carried out without changing the product level. These settings can be made ahead of time without the instrument having to be installed. High nozzles or vessel installations, such as e. g. struts or agitators as Service - False signal suppression well as buildup and weld joints on the vessel walls, cause interfering reflections which can impair the measurement. A false echo storage...
-
Page 12: Menu Schematic
5 Set up with the display and adjustment module PLICSCOM Note: Check the distance to the medium surface, because if an incorrect (too large) value is entered, the existing level will be saved as a false signal. The level would then no longer be detectable in this area. Menu schematic Information: Depending on the version and application, the highlighted menu windows may not always be available. Basic adjustment ▶ Basic adjustment Display Diagnostics Service Info Min. adjustment Max. adjustment Medium Vessel shape 000.0 %... - Page 13 5 Set up with the display and adjustment module PLICSCOM Diagnostics Basic adjustment Display ▶ Diagnostics Service Info Peak value indicator Measurement reliability Curve selection Echo curve Distance min.: 0.580 m(d) 36 dB Dist. max.: 16.785 m(d) Device status Echo curve Presentation of the echo curve T-max.: 30.6 °C T-min.: 4.5 °C Service Basic adjustment Display...
-
Page 14: Supplement
6 Supplement Supplement Technical data Note for approved instruments The technical data in the respective safety instructions which are included in delivery are valid for approved instruments (e.g. with Ex approval). These data can differ from the data listed herein, for example regarding the process conditions or the voltage supply. All approval documents can be downloaded from our homepage. Input variable Measured variable distance between lower edge of the transducer and medium surface Measuring range Ʋ Liquids up to 8 m (26.25 ft) Ʋ Bulk solids up to 3.5 m (11.48 ft) Dead zone 0.4 m (1.312 ft) Electromechanical data... - Page 15 Notes OPTISOUND 3020 • Foundation Fieldbus...
- Page 16 • Engineering, commissioning, calibration, maintenance and train- ing services Head Office KROHNE Messtechnick GmbH Ludwig-Krohne-Straße 5 47058 Duisburg (Germany) Tel.: +49 (0) 203 301 0 Tel.: +49 (0) 203 301 10389 info@krohne.de The current list of all KROHNE contacts and addresses can be found at: www.krohne.com...
