Installa on & Control Guide for Panel Convector Heaters with
Electronic Controls and Open Window Detec on
Models
PLE050
PLE075
PLE100
PLE125
PLE150
PLE200/SS
Please note:
'SS' suffix added to model number denotes Stainless Steel deriva ve
All electrical appliances produced by the Company are guaranteed for one year against faulty
materials or workmanship.
This applies only if the appliance has been used for purposes in
accordance with the instructions provided and has not been connected to an unsuitable
electricity supply, or subject to misuse, neglect, damage or modified or repaired by any person
not authorised by us. This guarantee is offered to you as an extra benefit and does not affect your
legal rights.
The correct electricity supply voltage is shown on the rating label attached to the appliance.
Reasonable care has been taken to ensure that this guide is accurate at the time of printing.
In the interest of progress the Company reserve the right to vary specifications from time to time
without notice.
66001077 Iss 06
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Consort PLE050
Summary of Contents for Consort PLE050
- Page 1 Installa on & Control Guide for Panel Convector Heaters with Electronic Controls and Open Window Detec on Models PLE050 PLE075 PLE100 PLE125 PLE150 PLE200/SS Please note: ‘SS’ suffix added to model number denotes Stainless Steel deriva ve All electrical appliances produced by the Company are guaranteed for one year against faulty materials or workmanship.
-
Page 2: Safety And Care
Overview switches the heater off if, for any reason, the appliance overheats. The TOC can only be re-set Please read this guide carefully and retain after the appliance has cooled down. In order to for future use and maintenance. re-set the TOC, proceed as follows: This appliance has been designed and ·... -
Page 3: Installation
Installation Fig. 1 195mm ILLIMETRES ATTS PLE050 PLE075 PLE100 1000 PLE125 1250 PLE150 1500 PLE200/SS 2000 Note: The heater MUST be fully secured in the vertical position before being switched on. It must be ‘clicked’ into the locking tabs. See section 15 for more mounting information. - Page 4 MODE/MENU INCREASE VALUE STANDBY DECREASE VALUE 1. Basic Operation When the room temperature reaches the set temperature, the heating is disabled. The PLE has 4 standard operating modes: BOOST, MANUAL, SETB and PROG. Each mode can be selected by pressing the MENU button to cycle through the options.
- Page 5 6. Heat symbol The system has been factory set to default time and temperature values. If necessary, all Every time there is a demand for heat, the dis- values can be adjusted. When the heating is play will show the heat icon. on, open window detection sensor will auto- matically switch the heater off when it detects a fall in temperature of 2°C in less than 10...
- Page 6 12. Setting the automatic program schedule An example of one day program on PLE PROGRAM 1 PROGRAM 2 PROGRAM 5 PROGRAM 6 ºC PROGRAM PROGRAM 19ºC 22ºC 22ºC 16ºC 10ºC 4ºC 06:00 08:00 12:00 14:00 16:00 22:00 Step 4: Press the MENU button. The temperature should flash.
- Page 7 13. Overview of program mode Alternatively, it is possible to copy a program from one day to another. The PLE has a 7-day, 5-day + 2-day and a 24 To do this, follow the steps below; hour timer available. This can be chosen in the setup menu.
- Page 8 1 - Temperature calibration 7 - Temperature drop in open window detection time The temperature reading is factory calibrated but if for any reason it needs adjusting (better accuracy required, to suit different position in the room etc.), the reading can be recalibrat- ed in 0.5 degree steps.
-
Page 9: Declaration Of Conformity
BSEN301 489.1 & .3 · BSEN300 220.1 & .2 · BSEN60 730.2.9 · BSEN 60335.1 (2012 ) · BS EN 60335.2.30 (2009) · PLE050, PLE075, PLE100, PLE125, UMBER ESCRIPTION PPLIANCE PLE150 and PLE200/SS Panel heaters ESPONSIBLE ERSON RIFFITHS OSITION RODUCTION AND...
