Installation & Control Guide for Slimline Low Surface
Temperature Wall Mounted Fan Heater
with Intelligent Fan Control & Electronic 7-Day Timer
Models
PLSTi050E, PLSTi075E, PLSTi100E, PLSTi150E, PLSTi150SSE
Please note:
'SS' suffix added to model number denotes Stainless Steel derivative.
All electrical appliances produced for the Company are guaranteed for one year against
faulty material or workmanship.
This applies only if the appliance has been used for
purposes in accordance with the instructions provided and has not been connected to an
unsuitable electricity supply, or subject to misuse, neglect, damage or modified or repaired
by any person not authorised by us. This guarantee is offered to you as an extra benefit and
does not affect your legal rights.
The correct electricity supply voltage is shown on the rating label attached to the
appliance.
Reasonable care has been taken to ensure that this guide is accurate at the time of
printing. In the interest of progress the Company reserve the right to vary specifications from
time to time without notice.
66000940 Iss 07
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Consort PLSTi050E
Summary of Contents for Consort PLSTi050E
- Page 1 Temperature Wall Mounted Fan Heater with Intelligent Fan Control & Electronic 7-Day Timer Models PLSTi050E, PLSTi075E, PLSTi100E, PLSTi150E, PLSTi150SSE Please note: ‘SS’ suffix added to model number denotes Stainless Steel derivative. All electrical appliances produced for the Company are guaranteed for one year against faulty material or workmanship.
-
Page 2: General Safety
functioning correctly. If the TOC General Safety control operates again, the appliance should be checked by a Our Low Surface Temperature heaters have been designed and built to the qualified person. The heater carries a ‘Do Not Cover’ label to NHS requirement for safe surface warn the user that if the appliance is temperatures which is that no surface... -
Page 3: Installation
Installation ILLIMETRES ATTS PLSTi050E/PLSTi075E 500/750 PLSTi100E 1000 PLSTi150E/SSE 1500 See Note 16 for Mounting 66000940 Iss 07... -
Page 4: Temp Mode
Time Prog SET TIME SET PROGRAM PRESS AND HOLD PRESS AND HOLD FOR 5 SECONDS FOR 5 SECONDS MODE SELECTION EMPERATURE SET BOOST, MANUAL, Temp Mode WHEN DISPLAY SHOWS SETBACK AND ROOM TEMPERATURE, PROGRAM PRESS TO ADJUST 1. Basic Operation 5. - Page 5 9. Set 7-day programme An example of one day program on PLSTiE PROGRAM 1 PROGRAM 2 PROGRAM 5 PROGRAM 6 PROGRAM PROGRAM ºC 19ºC 22ºC 22ºC 16ºC 10ºC 4ºC 06:00 08:00 12:00 14:00 16:00 22:00 Logic diagram for setting program on PLSTiE The PLSTiE has a 7-day timer with up to 6 programming steps available for each day.
- Page 6 10. Keys locking 14. Status light on the heater Light colour Heater status Press and hold TIME and TEMP together for 5 seconds. The display will show symbol. Repeat the step to unlock. STAND-BY No heat output Reduced heat output 12.
- Page 7 Locking tab USTOMER ELPLINE Should you need any advice on the use of your new Consort product please contact our Helpline: Consort Equipment Products Limited Thornton Industrial Estate, Milford Haven, Pembrokeshire, SA73 2RT Tel: 01646 692172 Fax: 01646 695195 Email: technical@consortepl.com Web: www.consortepl.com Operation hours: Mon to Thu 8.30am to 4.30pm | Fri 8.30am to 3.30pm...
