NTP (N T P
ETWORK IME ROTOCOL
This section is used to define the parameters of NTP protocol. The means of the fields
are:
In the field "Server URL" the URL or the IP Address of the NTP Server is
defined;
In the field "Poll Time
synchronization is defined.
W -F :
I I
This section is used to define the general parameters of Wi-Fi. It is possible to defined the type of Wi-Fi communication:
Access Point;
Station.
The means of the fields for Access Point configuration are:
In the field "IP Address" the IP address of the converter is defined;
In the field "Subnet Mask" the SubNet Mask of the converter is defined;
In the field "GATEWAY" the default gateway of the net is defined. This feature
can be enabled or disabled pressing the Check Box field. This feature is used for
going out of the net;
In the field "SSID" the name of the Wi-Fi network to create is defined;
In the field "Secure Type" the type of security protocol used by the Wi-Fi
network is defined;
In the field "Password" the password used for Wi-Fi connection is defined;
If the field "Enable DHCP" is checked, the converter acts as DHCP Server for
the Clients connected. If the option is enabled, in the fields
Address" and "DHCP SUBNET
defined. In the field
renewing of the IP Address assigned to the Client is defined;
In the field "Max Client" the maximum number of Wi-Fi Clients accepted is
defined;
In the field "Channel" the channel for Wi-Fi communication is defined.
ADFweb.com S.r.l.
):
(seconds)" the polling time for the time
Mask" the IP Addresses range used for DHCP is
"Lease Time (seconds)" the required time for the
User Manual EtherCAT Master / MQTT
Document code: MN67E67_ENG
Figure 3g: "Set Communication
"DHCP First IP
Figure 3h: "Set Communication
Point)" window
Revision 1.000 Page 19 of 31
 NTP" window
 Wi-Fi (Access
