Summary of Contents for AsReader ASR-A24D
- Page 1 ASR-A24D AsReader DOCK-Type Barcode Reader for Android User’s Manual...
- Page 2 AsReader ASR-A24D User’s Manual Copyright © Asterisk Inc. All Rights Reserved. AsReader® is a registered trademark of Asterisk Inc. Other company and product names are generally trademarks or registered trademarks of their respective companies. The contents of this manual are subject to change without notice.
-
Page 3: Table Of Contents
Safety Instructions ....................2 How to Care for the Device ................... 3 1. Assembly of Products and Accessories ............4 ２. Name of Each Part of the AsReader ............7 ３. Functions and Operations ................7 ４. Preparation before Use ..................10 ５... -
Page 4: Preface
Thank you for purchasing the AsReader ASR-A24D. This manual describes precautions for handling the AsReader ASR-A24D correctly. Please read the manual carefully before use. ※ In some sections of this manual, we may refer to the “AsReader ASR-A24D” as “the device”, “this product”, “the product”, or “the AsReader”. -
Page 5: Safety Instructions
Do not throw the product into fire or heat. It may burst or cause a fire. Do not look into the light emitted from the AsReader or point it at other people’s eyes . This is a Class 2 Laser product. Do not look into the laser light or point it at anyone else. Looking directly into the laser may cause injury to the eyes. -
Page 6: How To Care For The Device
AsReader ASR-A24D User’s Manual How to Care for the Device Please keep the device clean. If the device gets dirty, wipe it with a soft, dry cloth. Using strong solvents or cleaners may cause deterioration or color changes. -
Page 7: Assembly Of Products And Accessories
Android phone, which supports USB HID mode and USB CDC mode. In order to use an AsReader, you need an AsReader, an Android device, and a joint connector cable. To use it in USB CDC mode, a corresponding application will also need to be installed in the Android device. - Page 8 AsReader ASR-A24D User’s Manual 1.2 Inside the Box A default box of AsReader ASR-A24D contains only the AsReader. Please purchase optional parts separately, such as a Magconn(PIN2) cable or gender adapter for charging, a USB-C cable, and a joint connector. Please make sure that everything is ready before use.
- Page 9 AsReader ASR-A24D User’s Manual 1.3 Application development In order to use AsReader in the USB CDC mode, you will need to install a corresponding application to your Android device. Our “A24D Demo App” on the Google Play Store is one such example.
-
Page 10: Name Of Each Part Of The Asreader
10%, making the AsReader unusable. ※In USB HID mode, settings are kept in the AsReader until the next time they are changed. In USB CDC mode, users can either keep settings in the application temporarily or keep settings in the AsReader until the next setting change. - Page 11 5 seconds of scanning, the barcode engine will turn off the white light and laser. ② Trigger button ・When one or both trigger buttons are pressed with the AsReader’s power on, the device starts scanning. Scanning can also be triggered by applications, using USB CDC mode.
- Page 12 Please do not attempt to charge the AsReader from this USB-C port. ⑦ USB-C charging port ・Charge the AsReader using a USB-C cable with this port. This port supports fast charging of Android devices. For details on charging, please see Chapter 6.
-
Page 13: Preparation Before Use
AsReader ASR-A24D User’s Manual 3. Preparation before Use Connect your AsReader and the Android device using a joint connector. If you have a case for your AsReader and Android device, please attach it to your AsReader and the Android device. -
Page 14: ５ How To Scan
① After getting ready as described in Chapter 4 above, make sure the battery is fully charged. ② Start the application and check the connection status between the AsReader and the application. In some cases, popup messages may ask you for permission to connect to the application. -
Page 15: ６ How To Charge
20W can cause fire, smoking, and malfunction of the AsReader. When connected to an Android device, the AsReader and the Android device are charged at the same time. While the battery of an AsReader is being charged, the leftmost LED of the battery... - Page 16 The USB-OTG path only allows either charging, or data, not both simultaneously. ※When using the AsReader for the first time or if it has been left idle for a long period of time, please charge the AsReader sufficiently before use.
-
Page 17: ７ Troubleshooting
AsReader ASR-A24D User’s Manual 7. Troubleshooting If you think that there is a malfunction in the AsReader, please check the following before contacting your distributor. ・When the AsReader cannot connect to Android devices (in either USB HID mode or USB CDC mode) ①... - Page 18 ④ Please restart the application or try using our “A24D Demo App” (in USB CDC mode). ・When the Trigger button of the AsReader is pressed, a red light is emitted but no barcode data is displayed in the application ① Please restart the application or try using our “A24D Demo App” (in USB CDC mode) ②...
-
Page 19: Appedix Specifications
FCC / CE / RoHS ※1 We recommend using an adapter that has an output of 5V3A when charging an AsReader using a magnetic charging port. When you use an adapter that supports USB PD, the output power needs to be 20W or lower. - Page 20 AsReader ASR-A24D User’s Manual ※3 Excluding protrusion.
- Page 21 AsReader ASR-A24D User’s Manual ASR-A24D DOCK-Type Barcode Reader for Android User’s Manual 2023/08 Version 1.0 release Asterisk Inc. AsTech Osaka Building 6F, 2-2-1 Kikawanishi, Yodogawa-ku, Osaka, 532-0013 JAPAN...
