AsReader Gun-Type Long Range BCR
ASR-R202G
User's Manual
Copyright © Asterisk Inc. All Rights Reserved.
AsReader ® is registered trademarks of Asterisk Inc.
Other company and product names are generally trademarks or registered trademarks of their respective companies.
The contents of this manual are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASR-R202G and is the answer not in the manual?

Questions and answers

Related Manuals for AsReader ASR-R202G

Summary of Contents for AsReader ASR-R202G

  • Page 1 User’s Manual Copyright © Asterisk Inc. All Rights Reserved. AsReader ® is registered trademarks of Asterisk Inc. Other company and product names are generally trademarks or registered trademarks of their respective companies. The contents of this manual are subject to change without notice.

  • Page 2: Table Of Contents

    1.1 Assembly of Products and Accessories ................. 6 1.2 Inside the Box ........................ 7 1.3 Application Development ....................8 2 Name of Each Part of the AsReader ................. 9 3 Functions and Operations ....................10 4 Before Use ........................12 5 How to Scan ........................

  • Page 3: Preface

    Please read the manual carefully and keep it as long as you have the device. ※ In some sections of this manual, we may refer to " AsReader GUN-Type Long Range BCR ASR-R202G " as "the device", "this device", “this product”, or “the product”.
  • Page 4 AsReader ASR-R202G User’s Manual ★In order not to damage your life and property safety, please read this manual carefully before using this product. We will not be responsible for any loss caused by non-compliance with this manual. ★We are not responsible for any damage caused by natural disasters, such as earthquake, lightning, winds, floods, fire outside our responsibility, third party behavior, other accidents, intentional or negligent abuse or other improper use.

  • Page 5: Safety Instructions

    For charging, please use the dedicated USB charging cable with the magnetic detachable connector that is provided with this product. Please use this cable with your own wall-adapter that provides an output of 5V/2A (not included with the ASR-R202G). Using different cables or different output chargers may result in failed charges.

  • Page 6: How To Care For The Device

    AsReader ASR-R202G User’s Manual How to Care for the Device Please use this device in a clean environment. Adhesive chemicals or oils may cause the resin shell to break. × chemicals include cosmetics, detergents, pesticides, thinners, gasoline, etc. × oils include tallow and other animal oils, hand creams, etc.

  • Page 7: Assembly Of Products And Accessories

    AsReader ASR-R202G User’s Manual Assembly of Products and Accessories 1.1 Assembly of Products and Accessories × In order to use this device with an iOS device connected, you need to purchase the following parts. iOS device AsRing Plus AsLock Spacer Case AｓLock Header...

  • Page 8: Inside The Box

    AsReader ASR-R202G User’s Manual recommend that you do a verification before purchasing. Please contact the distributor for details such as verification before purchase and the existence of compatible cases. 1.2 Inside the Box The following items are contained in the box. Please first make sure you have all of these items.

  • Page 9: Application Development

    AsReader ASR-R202G User’s Manual 1.3 Application Development To use this device, you need to install related applications on iOS devices. You can download SDK from our official website for iOS application development (please refer to the SDK development manual and sample code) The official website link (SDK for iOS only): https://asreader.com/downloads/asr-r202g/...

  • Page 10: Name Of Each Part Of The Asreader

    AsReader ASR-R202G User’s Manual 2 Name of Each Part of the AsReader Installation port of AsLock Header (Sold separately) Barcode engine Power button Action indicator Battery indicator Reset button Micro USB charging port Trigger Battery...

  • Page 11: Functions And Operations

    When this device is connected to the application and does not perform any operation, the mobile device may go to sleep before the AsReader. In this case, the mobile device will repeatedly connect and disconnect at certain intervals, and there will be some beeps for connection and disconnection.
  • Page 12 Vibration occurs during barcode scanning and can be set in the application. The default is “on”. ・ You can set the barcode scanning module, refer to the barcode setting manual. ※ Settings will be saved in the AsReader until you reset it. Barcode setting manual download link: https://asreader.com/downloads/asr-r202g/ Reset button ・...

  • Page 13: Before Use

    AsReader ASR-R202G User’s Manual Before Use In order to use the device, the components and mobile devices shown in section 1.1 must be assembled and then connected to the device. The assembly method is as follows: Attach AsRing Plus to AsLock Spacer. Insert it firmly so that it fits into the four claws of AsLock Spacer.
  • Page 14 Attach AsLock Header to this product. Make sure to insert it all the way in. AsLock Header Combine ③ and ④. Align the AsLock Header on the AsReader with the groove on the AsLock Spacer on the set of iOS device, and rotate the set of iOS device clockwise until it fits.

  • Page 15: How To Scan

    AsReader ASR-R202G User’s Manual How to Scan When ready as described in Chapter 4 above, make sure the battery is fully charged. Next, start the application, boot the product and check the connection status between the app and the product.

  • Page 16: Setting Items Of The Demo App

    Buzzer Set the buzzer on/off and volume. When it is turned on, AsReader will beep at the set volume at the following cases: When AsReader is turned on or off. When the phone and AsReader connect successfully.
  • Page 17 Default as 300. The device will never go to sleep if the sleep time is set to 0. Auto Off Time You can set the automatic shutdown time for AsReader. It is the period between when AsReader goes to sleep and when the power is turned off.
  • Page 18 AsReader ASR-R202G User’s Manual Timeout You can set the scan timeout. It can be set from Settings à Scanner Time Out in the demo APP. Unit: second. Range: 4~30. Default as 30. ※ If you click Start Scan in the application or pull the trigger and the 1D / 2D barcode is not read within a certain period of time, the Scan will automatically stop after the set time (timeout).

  • Page 19: How To Charge It

    When using the device for the first time or if it has been left unused for a long period of time, please fully charge the battery of this device before use. If an iOS device is connected, both the AsReader battery and the iOS device battery are charged at the same time.

  • Page 20: Troubleshooting

    AsReader ASR-R202G User’s Manual Troubleshooting Please check the following before contacting your distributor: Cannot connect to smart device The mobile device may not recognize the device due to problems with the connection or an app. Please check the following: Please check that the AsLock Header is correctly attached. (Firmly push it in to its slot.)
  • Page 21 AsReader ASR-R202G User’s Manual If the action indicator is lit blue, this indicates a successful connection between the AsReader and mobile device. In this case, there is a high possibility that the problem is on the application side. Please restart the application. If you still cannot solve the problem, contact the application development company.
  • Page 22 AsReader ASR-R202G User’s Manual Cannot scan If the device does not scan, please try the following: Please confirm the device’s battery is sufficiently charged. If the application is not responding, please try restarting the application. Please confirm that the settings for barcode scanning are correct. Please refer to the Barcode Setting Manual at the following link.

  • Page 23: Appendix-Specifications

    AsReader ASR-R202G User’s Manual Appendix-Specifications Items Specifications Product name AsReader GUN-Type Long Range BCR Model ASR-R202G Scanning method Autofocus 2D imager 1280 x 800 pixels Barcode resolution Distance to the front of the device Code39 - 10mil/0.25mm 15 ～ 135cm Code39 - 20mil/0.5mm...
  • Page 24 AsReader ASR-R202G User’s Manual Repeat of 4 times of red blinks and 6 seconds of red off (Battery level ≤ 20%) Red continuously blinks (Battery level ≤ 5%) Communication Interface AsRing Plus （USB） ※6 Dimensions(D)x(W)x(H) 130 × 59 × 145 mm ※7...
  • Page 25 AsReader ASR-R202G User’s Manual AsReader Gun-Type Long Range BCR ASR-R202G User’s Manual 2020/7/10 Version 1.0 release Asterisk Inc. Osaka Office Tel: +81 (0) 50 5536 1185 Shin-Osaka Dainichi Bldg. 201, 5-6-16 Nishinakajima, Yodogawa-ku, Osaka-city, Osaka, 532-0011 JAPAN...
