AsReader GUN-Type
ASR-L251G Series
Barcode/ RFID Reader
User's Manual
Copyright © Asterisk Inc. All Rights Reserved.
AsReader ® is registered trademarks of Asterisk Inc.
The iOS trademark is used under license from Cisco in the United States.
Android is a registered trademark of Google LLC.
Other company and product names are generally trademarks or registered trademarks of their respective companies.
The contents of this manual are subject to change without notice.
Advertisement
Table of Contents
Related Manuals for AsReader ASR-L251G Series
Summary of Contents for AsReader ASR-L251G Series
- Page 1 Barcode/ RFID Reader User’s Manual Copyright © Asterisk Inc. All Rights Reserved. AsReader ® is registered trademarks of Asterisk Inc. The iOS trademark is used under license from Cisco in the United States. Android is a registered trademark of Google LLC.
-
Page 2: Table Of Contents
1.1.1 Working with iOS Devices ..................4 1.1.2 Working with Android devices ................. 5 1.2 Inside the Box ........................ 6 ２ Name of each part of the AsReader ..............7 ３ Functions and Operations ..................8 ４ Before use ......................11 ５... - Page 3 This Manual describes the considerations for using AsReader GUN Type ASR-L251G. Please read the manual carefully and keep it as long as you have the device. ※In some sections of this manual, we may refer to " AsReader ASR-L251G " as "the device" or "this device" except for accessories.
-
Page 4: Safety Instructions
AsReader ASR-L251G User’s Manual Safety Instructions × Please read the following instructions carefully to prevent injury, malfunction, fire, etc. Warnings Do not attempt to disassemble, modify or repair the device yourself, otherwise it may cause malfunction, fire or electric shock. We are not responsible for any malfunction of this product or intelligent device caused by modification. -
Page 5: How To Care For The Device
AsReader ASR-L251G User’s Manual Interference from external radio waves or surrounding electronic equipment may cause the device to not function properly. Please use the device with caution in this type of environment. The AsLock connection terminal of this product, the magnetice suction of the USB-C charging cable, and the AsLock Gender, all have built-in magnets, which may erase the data on magnetic cards such as credit cards. -
Page 6: Assembly Of Products And Accessories
AsReader ASR-L251G User’s Manual 1 Assembly of Products and Accessories 1.1 Assembly of Products and Accessories × In order to use this product with intelligent devices, the following parts are required. 1.1.1 Working with iOS Devices iOS device AsLock (for iOS) -
Page 7: Working With Android Devices
AsReader ASR-L251G User’s Manual 1.1.2 Working with Android devices Android device AsLock (for Android) Case AsReader GUN Note: If you are using an Android device, we do not guarantee that all models can be used because there are various models. Although most models that support OTG connection can be used, we strongly recommend that you do a verification before purchasing. -
Page 8: Inside The Box
In case that any items are missing please contact the company from whom you purchased the device. ●AsReader ●USB-C cable and the magnetic suction ※Optional accessories (included in the same package as AsReader if purchased at the same time) ●AsLock (for iOS) ●AsLock (for Android) ●AsLock Gender... -
Page 9: ２ Name Of Each Part Of The Asreader
AsReader ASR-L251G User’s Manual https://asreader.com/downloads/asr-l251g/ Please contact your distributor to obtain the Android SDK. ２ Name of each part of the AsReader AsLock terminal Barcode module Antenna Trigger Mode indicator Mode change Power button Mode button Power indicator USB-C charging port... -
Page 10: ３ Functions And Operations
※ Vibration is turned on by default. If the vibration setting is turned off, it will not vibrate. The settings are saved in the application. When AsReader is on, press and hold the power button for more than 3 seconds to shut down. - Page 11 × You can set the barcode scanning module, refer to the barcode setting manual. ※ You also can set the Barcode module in the application, and these settings will be permanently saved in the AsReader. Barcode setting manual download link: https://asreader.jp/downloads/asr-l251g/...
- Page 12 × Vibration occurs during tag reading/writing and can be set in the application. Default as being on. ※ You also can change these settings in the application, and these settings will be permanently saved in the AsReader. ⑦ USB-C charging interface ×...
-
Page 13: ４ Before Use
AsReader ASR-L251G User’s Manual ４ Before use In order to use the product, the components and mobile devices shown in section 1.1 must be assembled and then connected to the product. The assembly method is as follows: ① Connect the mobile device and AsLock. - Page 14 Put the mobile device in the rubber part of the case. ②-3 Install the outer plastic part of the case to the upper ②-2. ③Connect the ② above to the AsReader. To use this product, you need to install a companion app on the mobile device. Please download...
-
Page 15: ５ How To Scan
AsReader ASR-L251G User’s Manual ５ How to scan When ready as described in chapter 4, make sure the battery is fully charged. Next, start the application, boot the product, and then check the connection status between the app and the product. -
Page 16: ６ How To Charge
100% charged, the power indicator LED turns green. Depending on the state of connection to the mobile device, the LED indicator may blink or keep on. ※ when AsReader is off, once the type-c charging cable is connected, it will automatically start up and enter the charging state. - Page 17 AsReader ASR-L251G User’s Manual Warnings Do not charge the device with a power adapter other than 5V, since this may cause a malfunction and is not covered by the warranty. ※ Supplementary Information Mobile devices (iOS and Android devices) can be charged separately by AsLock Gender.
-
Page 18: ７ Troubleshooting
AsReader ASR-L251G User’s Manual ７ Troubleshooting If you think the device is broken Please check the following before contacting your distributor. ★ Cannot connect to Mobile device The mobile device may not recognize the device due to problems with the connection or an app. -
Page 19: Appendix-Specifications
AsReader ASR-L251G User’s Manual Appendix-Specifications Model Name Bandwidth Region Japan ASR-L251G-21 916-921MHz Europe ASR-L251G-22 865-868MHz North America ASR-L251G-23 902-928MHz China ASR-L251G-24 920.5-924.5MHz Brazil ASR-L251G-26 902-908MHz, 915-928MHz Spec ISO 18000-63 (That is, the previous 18000-6C) / EPC global Class 1 Gen 2 Output power 1W (5～30dBm: adjustable in units of 1dBm) - Page 20 AsReader ASR-L251G User’s Manual Continuous operation ■RFID time About 11 hours (scan every 5 s; 30 s standby time) About 8 hours (scan every 10 s; 30 s standby time) ■Barcode About 32 hours or 20,000 times (scan every 5 s) Power source USB-C cable &...
- Page 21 AsReader ASR-L251G User’s Manual AsReader GUN-Type ASR-L251G Series Barcode/ RFID Reader User’s Manual 2020.3 V1.0 Asterisk Inc. Shin-Osaka Dainichi Bldg. 201, 5-6-16 Nishinakajima, Yodogawa-ku, 〒532-0011 Osaka-city, Osaka...
