AsReader Finger-Type
ASR-023B
Finger-Type 1D/2D Barcode Reader
User's Manual
Copyright © Asterisk Inc. All Rights Reserved.
AsReader ® is registered trademarks of Asterisk Inc.
Other company and product names are generally trademarks or registered trademarks of their respective companies.
The contents of this manual are subject to change without notice.
Advertisement
Table of Contents
Related Manuals for AsReader ASR-023B
Summary of Contents for AsReader ASR-023B
- Page 1 User’s Manual Copyright © Asterisk Inc. All Rights Reserved. AsReader ® is registered trademarks of Asterisk Inc. Other company and product names are generally trademarks or registered trademarks of their respective companies. The contents of this manual are subject to change without notice.
-
Page 2: Table Of Contents
Finger-Type ASR-023B User’s Manual Contents Preface ..........................1-1 Safety Instructions ........................ 2 How to Care for the Device ....................3 1 Assembly of Products and Accessories ................4 1.1 Inside the Box ........................ 4 1.2 Application Developments ..................... 4 2 Name of Each Part and Operations .................. 5 3 Bluetooth Connect ...................... -
Page 3: Preface
This manual describes precautions for handling AsReader Finger-Type ASR-023B correctly. Please read the manual carefully and keep it as long as you have the device. ※In some sections of this manual, we may refer to " AsReader Finger-Type ASR-023B " as "the device", "this device",or “AsReader” except for accessories. - Page 4 Finger-Type ASR-023B User’s Manual ★In order not to damage your life and property safety, please read this manual carefully before using this device. We will not be responsible for any loss caused by non-compliance with this manual. ★We are not responsible for any damage caused by natural disasters, such as earthquake, lightning, wind, flood, fire outside our responsibility, third party behavior, other accidents, intentional or negligent, abuse or other improper use.
-
Page 5: Safety Instructions
Finger-Type ASR-023B User’s Manual Safety Instructions Please read the following instructions carefully to prevent injury, malfunction, fire, etc. Warning Do not attempt to disassemble, modify or repair the device yourself, otherwise it may cause malfunction, fire or electric shock. We are not responsible for any malfunction of the device, the smart device or the PC. -
Page 6: How To Care For The Device
Finger-Type ASR-023B User’s Manual How to Care for the Device Please use this device in a clean environment. Adhesive chemicals or oils may cause the resin shell to break. × chemicals include cosmetics, detergents, pesticides, thinners, gasoline, etc. × oils include tallow and other animal oils, hand creams, etc. -
Page 7: Assembly Of Products And Accessories
Finger-Type ASR-023B User’s Manual Assembly of Products and Accessories 1.1 Inside the Box The following items are contained in the box. Please first make sure you have all of these items. In case that any items are missing, please contact the company from whom you purchased the device. -
Page 8: Name Of Each Part And Operations
Finger-Type ASR-023B User’s Manual 2 Name of Each Part and Operations ③ Action Indicator ⑤ Scan Window ① Power Button ⑥ Charging Port ② Trigger ④ Bluetooth Indicator Power Button ① ・Power on/ off Press the power button, the buzzer emits two short beeps and the device starts. - Page 9 Finger-Type ASR-023B User’s Manual Scan Window ⑤ ・When the trigger is pressed, the scan window will emit a red beam, aim it at the 1D and 2D barcodes, and then scan it. ・Beeping occurs during barcode scanning and can be set by scanning the specific setting barcode.
-
Page 10: Bluetooth Connect
3.1 Connect to Smart devices Turn on the device then the Bluetooth Indicator blinks. Turn on Bluetooth of your smart device, search for “ASR-023B-Serial No.” and then click it to connect. Once pairing successfully, the Bluetooth indicator will stop blinking and remain on. -
Page 11: Setting Barcodes
Finger-Type ASR-023B User’s Manual Setting Barcodes 4.1 Bluetooth Communication Mode HID mode SPP mode BLE serial port mode 4.2 Data Upload Mode 4.2.1 Real-time Upload Mode Once the device scans any barcode data, it will immediately send the data to the smartphone or... -
Page 12: Buffer Mode
Finger-Type ASR-023B User’s Manual 4.2.2 Buffer Mode The scanned barcode data is temporarily stored in the device's built-in flash memory and then sent uniformly. Buffer Mode Total number of data Upload all data Clear all data Buffer mode upload buzzer on... -
Page 13: User Id Setting
Finger-Type ASR-023B User’s Manual Buffer mode upload buzzer off 4.3 User ID Setting Steps to set user ID number : Scan the barcode "Set ID" first. Scan the following (0~9) digital barcode. (The number in the first scan represents the tens place of the user ID;... - Page 14 Finger-Type ASR-023B User’s Manual...
-
Page 15: Pair With Pc
Finger-Type ASR-023B User’s Manual 4.4 Pair with PC Pair with PC... -
Page 16: Power Off
Finger-Type ASR-023B User’s Manual 4.5 Power off Power off 4.6 Get Information of Device Get firmware version Get hardware version Show battery 4.7 Revert to Factory Settings Revert to factory settings... -
Page 17: Ios Keyboard Access/Exit
Finger-Type ASR-023B User’s Manual 4.8 iOS Keyboard Access/Exit iOS keyboard access/exit 4.9 Successful Scan Beep Turn on/off the buzzer sound when barcode scanning. Successful scan beep on Successful scan beep off... -
Page 18: Sleep Time Settings
Finger-Type ASR-023B User’s Manual 4.10 Sleep Time Settings Operation steps: Scan the barcode “Sleep time set enable”. Scan the time barcode you wish to set as sleep time. Note: This setting does not take effect until the device is restarted. - Page 19 Finger-Type ASR-023B User’s Manual 20 mins Never sleep...
-
Page 20: How To Charge It
Finger-Type ASR-023B User’s Manual How to Charge It The battery of this device is charged using the included USB charging cable and magnetic detachable connector. Attach the magnetic detachable connector to the micro USB charging port of this device. Connect the USB charging cable to charge it. -
Page 21: Troubleshooting
It may be difficult to connect when changing a paired phone. Because within about 2 minutes of AsReader being turned on, AsReader will ask to be paired with the phone it was paired with last time. In this case, try the following steps：... - Page 22 Finger-Type ASR-023B User’s Manual keyboard to output the barcode data , some character or symbol data of the barcode may not display correctly. It is recommended to using the half-width alphanumeric mode or English keyboard to output/ input the barcode data.
-
Page 23: Appendix-Specifications
Finger-Type ASR-023B User’s Manual Appendix-Specifications Model ASR-023B Scanning method CMOS 1280 x 1280 pixels Reading distance Distance to the front of the device (Barcode resolution) EAN-13：50mm～200mm (13mils) Code39：40mm～90mm (5mils 10bytes) QR Code：25mm～240mm (20mils 16bytes) Data Matrix：50mm～90mm (10mils 20bytes) PDF 417：30mm～130mm (6.67mils 7bytes) Reading angle Pitch: ±55°;... - Page 24 Finger-Type ASR-023B User’s Manual Operation environment Temperature: -10℃～45℃ Humidity: 10～90 %RH Charging environment Temperature: 0℃～45℃ Humidity: 10～90 %RH Environment Storage temperature Temperature: -20℃～45℃ Humidity: 10～90 %RH Anti-drop (Six-sided, 4 edge, once each) 1m Certificates TELEC/ FCC/ CE Supporting OS Android, iOS, Windows...
- Page 25 Finger-Type ASR-023B User’s Manual AsReader Finger-Type ASR-023B User Manual 2020/6/19 The initial release Asterisk Inc. Osaka Office Tel: +81 (0) 50 5536 1185 Shin-Osaka Dainichi Bldg. 201, 5-6-16 Nishinakajima, Yodogawa-ku, Osaka-city, Osaka, 532-0011 JAPAN...
