AsReader ASX-520R Parameter Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AsReader（ASX-520R & ASR-020D）
Barcode Parameter Manual
Asterisk, Inc.
Version 1.1
※The data will be changed without a notice.
This document describes the programmable parameters, provides bar codes for programming, AsReader is
shipped with the factory default settings. These factory default values are stored in non-volatile memory
and are preserved even when the scan engine is powered down. Changes to the factory default values are
also stored in non-volatile memory and are preserved even when the scan engine is powered down. Scan the
appropriate bar codes included in this document. The new values replace the existing memory values. The
factory default parameter values can be recalled by scanning Set Factory Defaults.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASX-520R and is the answer not in the manual?

Questions and answers

Related Manuals for AsReader ASX-520R

Summary of Contents for AsReader ASX-520R

  • Page 1 Version 1.1 ※The data will be changed without a notice. This document describes the programmable parameters, provides bar codes for programming, AsReader is shipped with the factory default settings. These factory default values are stored in non-volatile memory and are preserved even when the scan engine is powered down. Changes to the factory default values are also stored in non-volatile memory and are preserved even when the scan engine is powered down.
  • Page 2 Revision History Version Date Item 16 March 2015 First Rivision 16 June 2016 A-1 Fix tipographical error at Parameter Defaults B-13 Delete Decode LED Behavior B-16 Delete “Host” from Trigger Mode B-11 Add Decode Aiming Pattern B-13 Add Decoding Illumination...
  • Page 3 To set the parameter Charge the battery of AsReader, before setting the parameters. Changing Default Values The decoder ships with the settings shown in the Table on page . If the default values suit requirements, programming is not necessary. Scan the appropriate barcodes in this guide to change a parameter value.

  • Page 4: Table Of Contents

    Parameter Default setting (factory default) Parameter Value Page User Preferences Default parameter Restore Defaults Parameter Scanning Enable Disable Lock Parameter Scanning Disable Unlock Parameter Scanning Disable User Parameter Pass Through Enable Beep After good Decode Beeper Tone Medium Beeper Volume High Beeper Duration Medium...
  • Page 5 B-31 Disable Validate Concatenated Parameter Bar Codes B-32 Disable PDF Prioritization B-33 200 ms PDF Prioritization Timeout Miscellaneous Scanning Parameters B-34 Transmit Code ID Character None B-35 Prefix Values <CR> B-35 <CR> Suffix Value 1 <CR> Suffix Value 2 B-36 Data as is Scan Data Transmission Format B-38...
  • Page 6 Barcode Parameter Default Parameter Value Page Disable All Code Types JAN (UPC/EAN) UPC-A Enable Enable UPC-E Disable UPC-E1 Enable EAN-8/JAN8 Enable EAN-13/JAN13 Bookland EAN Disable Bookland ISBN Format ISBN-10 Decode UPC/EAN/JAN Supplementals Ignore C-10 User-Programmable Supplementals F1h 43h Supplemental 1 F1h 44h Supplemental 2 C-11...
  • Page 7 C-26 Disable ISBT Concatenation C-27 Enable Check ISBT Table C-27 ISBT Concatenation Redundancy Code 39 C-28 Enable/Disable Code39 Enable C-28 Enable/Disable Trioptic Code39 Disable C-29 Disable Convert Code39 to Code32 C-29 Disable Code32 Prefix C-30 Length Within Set Length(s) for Code39 Range: 2 to 55 C-32 Code39 Check Digit Verification...
  • Page 8 Codabar (NW-7) C-53 Disable Enable/Disable Codabar C-54 Length Within Set Lengths for Codabar Range: 5 to 55 C-56 CLSI Editing Disable C-56 Disable NOTIS Editing C-57 Upper Case Codabar Upper or Lower Case Start/Stop Characters Detection C-58 Disable Enable/Disable MSI C-59 Set Lengths for MSI 6-55...
  • Page 9 C-75 Disable Netherlands KIX Code C-75 Disable USPS 4CB/One Code/Intelligent Mail C-76 Disable UPU FICS Postal GS1 DataBar C-77 GS1Databar Enable (Omnidirectional/Truncated/Stacked /Stacked Omnidirectional) C-78 Disable GS1 Databar Limited C-79 GS1 Databar Limited Security Level C-80 Enable GS1 Databar Expanded (Expanded/Expanded Stacked) C-80 Disable...
  • Page 10 C-92 Regular Han Xin Inverse Redundancy Level C-93 Redundancy Level C-95 Security Level (UPC/EAN and Code 39) C-97 Intercharacter Gap Size Normal Macro PDF C-98 Passthrough Mode Macro PDF Transmit/Decode Mode Symbols C-98 Enable Transmit Macro PDF Control Header C-99 None Escape Characters C-99...
  • Page 11 Set Default Parameter You can reset the AsReader to two types of defaults: factory defaults or custom defaults. Scan the appropriate bar code below to reset the decoder to its default settings and/or set its current settings as custom defaults.

  • Page 12: Parameter Scanning

    Parameter Scanning To disable the decoding of parameter bar codes, including the Set Defaults parameter bar codes, scan the Disable Parameter Scanning bar code below. To enable decoding of parameter bar codes, scan Enable Parameter Scanning.
  • Page 13 Lock/Unlock Parameter Scanning This feature locks parameter settings with a 4-digit code to prevent the user from changing parameter values by scanning parameter bar codes. This provides an added level of security not offered via Disable Parameter Scanning. After locking parameter settings, the only parameter bar code that is accepted is Unlock with the correct code.

  • Page 14: User Parameter Pass Through

    User Parameter Pass Through Enable this to send user-defined parameter bar codes (see User-Defined Parameter Bar Code Format) as normal decode data in decode data packets for SSI and SNAPI hosts (see Decode Data Format). User-Defined Parameter Bar Code Format Code 128 bar codes with: <FNC3><L><data>...

  • Page 15: Beep After Good Decode

    Beep After Good Decode Scan a bar code below to select whether or not the decoder issues a beep signal after a good decode. If selecting Do Not Beep After Good Decode, beeper signals still occur during parameter menu scanning and to indicate error conditions. NOTE This feature is invalid in ASR-020D.

  • Page 16: Beeper Tone

    Beeper Tone To select a decode beep frequency (tone), scan the Low Frequency, Medium Frequency, or High Frequency bar code. NOTE This feature is invalid in ASR-020D.

  • Page 17: Beeper Volume

    Beeper Volume To select a beeper volume, scan the Low Volume, Medium Volume, or High Volume bar code. NOTE This feature is invalid in ASR-020D.

  • Page 18: Beeper Duration

    Beeper Duration To select the duration for the beeper, scan one of the following bar codes. NOTE This feature is invalid in ASR-020D.

  • Page 19: Suppress Power-Up Beeps

    Suppress Power-up Beeps Select whether or not to suppress the decoder’s power-up beeps. NOTE This feature is invalid in ASR-020D.

  • Page 20: Aim Brightness (Aiming Led)

    Aim Brightness This feature sets the brightness, or power of the aim pattern for AsReader. AsReader has three settings: low (0), medium (1), and high (2). The default is high. To program the Aim Brightness for the AsReader, scan one of the following bar codes.

  • Page 21: Decode Aiming Pattern

    Decode Aiming Pattern Select Enable Decode Aiming Pattern to project the aiming pattern during barcode capture, Disable Decode Aiming Pattern to turn the aiming pattern off, or Enable Decode Aiming Pattern on PDF to project the aiming pattern when the decoder detects a 2D bar code. NOTE Picklist Mode on page B-20 With...

  • Page 22: Illumination Brightness (Illumination Led)

    Illumination Brightness This feature sets the brightness of the illumination by altering LED power. The default is 10, which is maximum LED brightness. For values from 1 to 10, LED brightness varies from lowest to highest level of brightness. To program Illumination Brightness, scan this bar code followed by two numeric bar codes Appendix Numeric Bar Codes that correspond to the value of desired illumination brightness.

  • Page 23: Decoding Illumination

    Decoding Illumination Selecting Enable Decoding Illumination causes the decoder to turn on illumination every image capture to aid decoding. Select Disable Decoding Illumination to prevent the decoder from using decoding illumination. Enabling illumination usually results in superior images. The effectiveness of illumination decreases as the distance to the target increases.

  • Page 24: Decode Blinks

    Decode Blinks In Presentation Mode, this feature specifies how many times to blink the illumination to indicate a successful decode. This feature is disabled by default (no blink). Decode Blink Duration to set the duration of the decode blinks. B-14...

  • Page 25: Decode Blink Duration

    Decode Blink Duration To set the duration of the decode blinks, scan the bar code below, then scan two numeric bar Appendix Numeric Bar Codes codes from that correspond to the desired duration in 100 msec increments. Timeout Between Decodes, To return the Decode Blink Duration to the value specified by Different Symbols on page B-23 , scan Set Decode Blink Duration to Timeout Between...

  • Page 26: Trigger Modes

    Trigger Modes • Level - A trigger event activates decode processing, which continues until the trigger Decode Session Timeout on page B-21 event ends, a valid decode, or the occurs. • Presentation Mode - When the decoder detects an object in its field of view, it triggers and attempt to decode.
  • Page 27 B-17...

  • Page 28: Power Mode

    Power Mode Select whether or not the decoder enters Low Power consumption mode after a decode attempt. In Continuous On mode, the decoder does not enter this low power state. B-18...

  • Page 29: Time Delay To Low Power Mode

    Time Delay to Low Power Mode This parameter sets the time the decoder remains active after decoding. After a scan session, the decoder waits this amount of time before entering Low Power Mode. NOTE This parameter only applies when Power Mode is set to Low. B-19...

  • Page 30: Picklist Mode

    Picklist Mode Picklist mode enables the decoder to decode only bar codes aligned under the center of the aiming pattern. Select one of the following picklist modes: • Disabled Always - Picklist mode is always disabled. • Enabled Always - Picklist mode is always enabled. NOTE With Picklist Mode enabled, the decode aiming pattern turns on even when the Decode Aiming Pattern is disabled.

  • Page 31: Decode Session Timeout

    Decode Session Timeout This parameter sets the maximum time decode processing continues during a scan attempt. It is programmable in 0.1 second increments from 0.5 to 9.9 seconds. The default timeout is 9.9 seconds. To set a Decode Session Timeout, scan the bar code below. Next, scan two numeric bar codes Appendix Numeric Bar Codes from that correspond to the desired on time.

  • Page 32: Timeout Between Decodes, Same Symbol

    Timeout Between Decodes, Same Symbol Use this option in Presentation Mode to prevent multiple reads of a symbol left in the decoder’s field of view. The timeout begins when you remove the symbol from the field of view. To select the timeout between decodes for the same symbol, available in 0.1 second increments from 0.0 to 9.9 seconds, scan the bar code below, then scan two numeric bar codes Appendix Numeric Bar Codes from...

  • Page 33: Timeout Between Decodes Different Symbol

    Timeout Between Decodes, Different Symbols Use this option in Presentation Mode or Continuous Bar Code Read to control the time the decoder is inactive between decoding different symbols. It is programmable in 0.1 second increments from 0.1 to 9.9 seconds. The default is 0.2 seconds. To select the timeout between decodes for different symbols, scan the bar code below, then Appendix Numeric Bar Codes scan two numeric bar codes from...

  • Page 34: Continuous Barcode Read

    Continuous Bar Code Read Select Enable to allow decode processing to continue until the trigger event ends or the Decode Session Timeout on page B-21 occurs. User indications occur upon decoding each bar code. Select Disable to end decode processing upon a valid decode as well. This mode does not apply to Presentation Mode.

  • Page 35: Unique Barcode Reporting

    Unique Barcode Reporting Enable this to report only unique bar codes while the trigger is pressed. This option only applies when Continuous Bar Code Read is enabled. B-25...

  • Page 36: Low Light Motion Detection Assist

    Low Light Motion Detection Assist In Presentation Mode, this feature allows motion detection in dim to dark illumination environments by using the aiming dot or dim illumination to assist in the detection of motion. NOTE Decoding Illumination on page B-13 If this parameter is enabled and is disabled, this parameter takes precedence.

  • Page 37: Presentation Mode Field Of View

    Presentation Mode Field of View In Presentation Mode, by default the decoder searches for a bar code in a smaller region around the aiming pattern’s center to speed search time. To use a full field of view, scan Presentation Mode Full Field of View. This allows the decoder to search the larger area of the aiming pattern.

  • Page 38: Fuzzy 1D Processing

    Fuzzy 1D Processing This option is enabled by default to optimize decode performance on 1D bar codes, including damaged and poor quality symbols. Disable this only if you experience time delays when decoding 2D bar codes, or in detecting a no decode. B-28...

  • Page 39: Mirrored Image

    Mirrored Image Enable this to scan images in reverse, or mirrored, as if seen through a mirror. This mode is useful in applications requiring scanning through a mirror and using symbologies that do not decode in reverse. B-29...
  • Page 40 Mobile Phone/Display Mode This mode improves bar code reading performance with target bar codes displayed on mobile phones and electronic displays. B-30...

  • Page 41: Validate Concatenated Parameter Bar Codes

    Validate Concatenated Parameter Bar Codes The decoder can encounter invalid parameters when using concatenated parameter bar codes intended for different scanner models or different versions of a scanner. This parameter determines how to process concatenated parameter bar codes when the decoder encounters an invalid parameter setting in the bar code.

  • Page 42: Pdf Prioritization

    PDF Prioritization Enable this feature to delay decoding a 1D bar code (Code 128 of 8 to 25 characters length) PDF Prioritization Timeout by the value specified in . During that time the decoder attempts to decode a PDF417 symbol (e.g., on a US driver's license), and if successful reports this only. If it does not decode (can not find) a PDF417 symbol, it reports the 1D symbol after the timeout.

  • Page 43: Pdf Prioritization Timeout

    PDF Prioritization Timeout PDF Prioritization When is enabled, this timeout specifies how long the decoder attempts to decode a PDF417 symbol before reporting the 1D bar code in the field of view. Appendix Numeric Bar Codes Scan the following bar code, then scan four digits from that specify the timeout in milliseconds.

  • Page 44: Miscellaneous Scanning Parameters

    Miscellaneous Scanning Parameters Transmit Code ID Character A Code ID character identifies the code type of a scanned bar code. This is useful when decoding more than one code type. In addition to any single character prefix already selected, the Code ID character is inserted between the prefix and the decoded symbol. Select no Code ID character, a Symbol Code ID character, or an AIM Code ID character.

  • Page 45: Prefix Values

    Prefix/Suffix Values You can append a prefix and/or one or two suffixes to scan data for use in data editing. To set a value for a prefix or suffix, scan the prefix or suffix bar code below, then scan a four-digit Appendix Numeric Bar Codes number (i.e., four bar codes from ) that corresponds to that...

  • Page 46: Scan Data Transmission Format

    Scan Data Transmission Format To change the scan data format, scan one of the following eight bar codes corresponding to the desired format. NOTE If using this parameter do not use ADF rules to set the prefix/suffix. To set values for the prefix and/or suffix, see Prefix/Suffix Values. B-36...
  • Page 47 Scan Data Transmission Format (continued) B-37...

  • Page 48: Transmit "No Read" Message

    Transmit “No Read” Message Scan a bar code below to select whether or not to transmit a No Read message. Enable this to transmit the characters NR when a successful decode does not occur before trigger release Decode Session Timeout on page B-21 or the expires.

  • Page 49: Report Version

    Report Version Scan the bar code below to report the version of software currently installed in the decoder. Report Decoder Manufacturing Information Scan the bar code below to report the part number, serial number, and manufacture date of the decoder. Report Scan Engine Manufacturing Information Scan the bar code below to report the part number, serial number, and manufacture date of the scan engine.

  • Page 50: Disable All Code Types

    Disable All Code Types To disable all symbologies, scan the bar code below. This is useful when enabling only a few code types.
  • Page 51 UPC/EAN Enable/Disable UPC-A To enable or disable UPC-A, scan the appropriate bar code below. Enable/Disable UPC-E To enable or disable UPC-E, scan the appropriate bar code below.

  • Page 52: Upc-E1

    Enable/Disable UPC-E1 UPC-E1 is disabled by default.
 To enable or disable UPC-E1, scan the appropriate bar code below. NOTE UPC-E1 is not a UCC (Uniform Code Council) approved symbology. Enable/Disable EAN-8/JAN-8 To enable or disable EAN-8/JAN-8, scan the appropriate bar code below.
  • Page 53 Enable/Disable EAN-13/JAN-13 To enable or disable EAN-13/JAN-13, scan the appropriate bar code below. Enable/Disable Bookland EAN To enable or disable Bookland EAN, scan the appropriate bar code below. NOTE If Bookland EAN is enabled, select a Bookland ISBN Format. Also select either Decode UPC/EAN Supplementals, Autodiscriminate UPC/EAN Supplementals, or Enable 978/979 Decode UPC/EAN/JAN Supplementals Supplemental Mode in...

  • Page 54: Bookland Isbn Format

    Bookland ISBN Format If Bookland EAN is enabled, select one of the following formats for Bookland data: • Bookland ISBN-10 - The decoder reports Bookland data starting with 978 in traditional 10-digit format with the special Bookland check digit for backward-compatibility.

  • Page 55: Decode Upc/Ean/Jan Supplementals

    Decode UPC/EAN/JAN Supplementals Supplementals are bar codes appended according to specific format conventions (e.g., UPC A+2, UPC E+2, EAN 13+2). The following options are available: • If you select Ignore UPC/EAN with Supplementals, and the decoder is presented with a UPC/EAN plus supplemental symbol, the decoder decodes UPC/EAN and ignores the supplemental characters.
  • Page 56 • Supplemental User-Programmable Type 1 and 2 - applies to EAN-13 bar codes starting with either of two 3-digit user-defined prefixes. Set the 3-digit prefixes User-Programmable Supplementals on page C-10 using .
 • Smart Supplemental Plus User-Programmable 1 - applies to EAN-13 bar codes starting with any prefix listed previously or the user-defined prefix set using User-Programmable Supplementals on page C-10 .
  • Page 57 Decode UPC/EAN/JAN Supplementals (continued)
  • Page 58 Decode UPC/EAN/JAN Supplementals (continued)

  • Page 59: User-Programmable Supplementals

    User-Programmable Supplementals Decode UPC/EAN/JAN If you selected a Supplemental User-Programmable option from Supplementals on page C-6 , select User-Programmable Supplemental 1 to set the 3-digit prefix. Then select the 3 digits using the numeric bar codes beginning on the appendix. Select User-Programmable Supplemental 2 to set a second 3-digit prefix.

  • Page 60: Upc/Ean Supplemental Redundancy

    UPC/EAN/JAN Supplemental Redundancy If you selected Autodiscriminate UPC/EAN/JAN Supplementals, this option adjusts the number of times to decode a symbol without supplementals before transmission. The range is from two to thirty times. Five or above is recommended when decoding a mix of UPC/EAN/JAN symbols with and without supplementals.

  • Page 61: Upc/Ean/Jan Supplemental Aim Id Format

    UPC/EAN/JAN Supplemental AIM ID Format Select an output format when reporting UPC/EAN/JAN bar codes with Supplementals with Transmit Code ID Character set to AIM Code ID Character: • Separate - transmit UPC/EAN with supplementals with separate AIM IDs but one transmission, i.e.: ]E<0 or 4><data>]E<1 or 2>[supplemental data]
...

  • Page 62: Transmit Upc-A Check Digit

    Transmit UPC-A Check Digit The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-A check digit. It is always verified to guarantee the integrity of the data. Transmit UPC-E Check Digit The check digit is the last character of the symbol used to verify the integrity of the data.

  • Page 63: Transmit Upc-E1 Check Digit

    Transmit UPC-E1 Check Digit The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-E1 check digit. It is always verified to guarantee the integrity of the data. C-14...

  • Page 64: Upc-A Preamble

    UPC-A Preamble Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-A preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble.

  • Page 65: Upc-E Preamble

    UPC-E Preamble Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-E preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble.

  • Page 66: Upc-E1 Preamble

    UPC-E1 Preamble Preamble characters are part of the UPC symbol, and include Country Code and System Character. There are three options for transmitting a UPC-E1 preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and transmit no preamble.

  • Page 67: Convert Upc-E To Upc-A

    Convert UPC-E to UPC-A Enable this to convert UPC-E (zero suppressed) decoded data to UPC-A format before transmission. After conversion, the data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit). Disable this to transmit UPC-E decoded data as UPC-E data, without conversion. Convert UPC-E1 to UPC-A Enable this to convert UPC-E1 decoded data to UPC-A format before transmission.

  • Page 68: Ean-8/Jan-8 Extend

    EAN-8/JAN-8 Extend Enable this parameter to add five leading zeros to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. Disable this to transmit EAN-8 symbols as is. UCC Coupon Extended Code Enable this parameter to decode UPC-A bar codes starting with digit ‘5’, EAN-13 bar codes starting with digit ‘99’, and UPC-A/GS1-128 Coupon Codes.

  • Page 69: Coupon Report

    Coupon Report Traditional coupon symbols (old coupon symbols) are composed of two bar codes: UPC/EAN and Code128. A new coupon symbol is composed of a single Databar Expanded bar code. The new coupon format offers more options for purchase values (up to $999.99) and supports complex discount offers such as a second purchase requirement.

  • Page 70: Issn Ean

    ISSN EAN To enable or disable ISSN EAN, scan the appropriate bar code below. C-21...

  • Page 71: Code 128

    Code 128 Enable/Disable Code 128 To enable or disable Code 128, scan the appropriate bar code below. Set Lengths for Code 128 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for Code 128 to any length, one or two discrete lengths, or lengths within a specific range.
  • Page 72 • Length Within Range - Select this option to decode a Code 128 symbol with a specific length range. Select lengths using numeric bar codes in Appendix Numeric Bar Codes. For example, to decode Code 128 symbols containing between 4 and 12 characters, first scan Code 128 - Length Within Range.

  • Page 73: Enable/Disable Gs1-128

    Enable/Disable GS1-128 (formerly UCC/EAN-128) To enable or disable GS1-128, scan the appropriate bar code below. C-24...
  • Page 74 Enable/Disable ISBT 128 ISBT 128 is a variant of Code 128 used in the blood bank industry. Scan a bar code below to enable or disable ISBT 128. If necessary, the host must perform concatenation of the ISBT data. C-25...

  • Page 75: Isbt Concatenation

    ISBT Concatenation Select an option for concatenating pairs of ISBT code types: • If you select Disable ISBT Concatenation, the decoder does not concatenate pairs of ISBT codes it encounters. • If you select Enable ISBT Concatenation, there must be two ISBT codes in order for the decoder to decode and perform concatenation.

  • Page 76: Check Isbt Table

    Check ISBT Table The ISBT specification includes a table that lists several types of ISBT bar codes that are commonly used in pairs. If you set ISBT Concatenation to Enable, enable Check ISBT Table to concatenate only those pairs found in this table. Other types of ISBT codes are not concatenated.

  • Page 77: Code 39

    Code 39 Enable/Disable Code 39 To enable or disable Code 39, scan the appropriate bar code below. Enable/Disable Trioptic Code 39 Trioptic Code 39 is a variant of Code 39 used in the marking of computer tape cartridges. Trioptic Code 39 symbols always contain six characters. To enable or disable Trioptic Code 39, scan the appropriate bar code below.

  • Page 78: Convert Code39 To Code32

    Convert Code 39 to Code 32 Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable converting Code 39 to Code 32. NOTE Code 39 must be enabled for this parameter to function. Code 32 Prefix Scan the appropriate bar code below to enable or disable adding the prefix character “A”...

  • Page 79: Set Length(S) For Code39

    Set Lengths for Code 39 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for Code 39 to any length, one or two discrete lengths, or lengths within a specific range. If Code 39 Full ASCII is enabled, Length Within a Range or Any Length are the preferred options.
  • Page 80 • Length Within Range - Select this option to decode a Code 39 symbol with a specific Appendix Numeric Bar Codes length range. Select lengths using numeric bar codes in For example, to decode Code 39 symbols containing between 4 and 12 characters, first scan Code 39 - Length Within Range.

  • Page 81: Code39 Check Digit Verification

    Code 39 Check Digit Verification Enable this feature to check the integrity of all Code 39 symbols to verify that the data complies with specified check digit algorithm. Only Code 39 symbols which include a modulo 43 check digit are decoded. Enable this feature if the Code 39 symbols contain a Modulo 43 check digit.

  • Page 82: Code39 Full Ascii Conversion

    Code 39 Full ASCII Conversion Code 39 Full ASCII is a variant of Code 39 which pairs characters to encode the full ASCII character set. To enable or disable Code 39 Full ASCII, scan the appropriate bar code below. NOTE You cannot enable Trioptic Code 39 and Code 39 Full ASCII simultaneously.

  • Page 83: Code 93

    Code 93 Enable/Disable Code 93 To enable or disable Code 93, scan the appropriate bar code below. C-34...

  • Page 84: Set Length(S) For Code93

    Set Lengths for Code 93 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for Code 93 to any length, one or two discrete lengths, or lengths within a specific range. •...
  • Page 85 • Any Length - Scan this option to decode Code 93 symbols containing any number of characters within the decoder’s capability.
 C-36...

  • Page 86: Code 11

    Code 11 Enable/Disable Code 11 To enable or disable Code 11, scan the appropriate bar code below. C-37...

  • Page 87: Set Length(S) For Code11

    Set Lengths for Code 11 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for Code 11 to any length, one or two discrete lengths, or lengths within a specific range. •...
  • Page 88 • Any Length - Scan this option to decode Code 11 symbols containing any number of characters within the decoder’s capability.
 C-39...

  • Page 89: Code11 Check Digit Verification

    Code 11 Check Digit Verification This feature allows the decoder to check the integrity of all Code 11 symbols to verify that the data complies with the specified check digit algorithm. This selects the check digit mechanism for the decoded Code 11 bar code. The options are to check for one check digit, check for two check digits, or disable the feature.

  • Page 90: Transmit Code 11 Check Digits

    Transmit Code 11 Check Digits This feature selects whether or not to transmit the Code 11 check digit(s). NOTE Code 11 Check Digit Verification must be enabled for this parameter to function. C-41...

  • Page 91: Interleaved 2 Of 5 (Itf)

    Interleaved 2 of 5 (ITF) Enable/Disable Interleaved 2 of 5 To enable or disable Interleaved 2 of 5, scan the appropriate bar code below, and select an Interleaved 2 of 5 length from the following pages. C-42...

  • Page 92: Set Lengths For Interleaved 2 Of 5

    Set Lengths for Interleaved 2 of 5 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for I 2 of 5 to any length, one or two discrete lengths, or lengths within a specific range.
  • Page 93 • Any Length - Scan this option to decode I 2 of 5 symbols containing any number of characters within the decoder’s capability. NOTE Due to the construction of the I 2 of 5 symbology, it is possible for a scan line covering only a portion of the code to transmit as a complete scan, yielding less data than is encoded in the bar code.
  • Page 94 Interleaved 2 of 5 Check Digit Verification Enable this feature to check the integrity of all I 2 of 5 symbols to verify the data complies with either the specified Uniform Symbology Specification (USS), or the Optical Product Code Council (OPCC) check digit algorithm. C-45...

  • Page 95: Transmit I 2 Of 5 Check Digit

    Transmit I 2 of 5 Check Digit Scan the appropriate bar code below to transmit I 2 of 5 data with or without the check digit. C-46...

  • Page 96: Convert I 2 Of 5 To Ean-13

    Convert I 2 of 5 to EAN-13 Enable this parameter to convert 14-character I 2 of 5 codes to EAN-13, and transmit to the host as EAN-13. To accomplish this, the I 2 of 5 code must be enabled, and the code must have a leading zero and a valid EAN-13 check digit.

  • Page 97: I 2 Of 5 Security Level

    Interleaved 2 of 5 Security Level Interleaved 2 of 5 bar codes are vulnerable to misdecodes by the nature of the symbol, especially when Any Length is set for Interleaved 2 of 5 bar codes. The decoder offers four levels of decode security for Interleaved 2 of 5 bar codes. There is an inverse relationship between security and decoder aggressiveness.
  • Page 98 I 2 of 5 Security Level 3: If you selected Security Level 2, and misdecodes still occur,  select this security level. The highest safety requirements are applied. A bar code must be successfully read three times before being decoded. NOTE Selecting this option is an extreme measure against mis-decoding severely out-of-spec bar codes.

  • Page 99: Discrete 2 Of 5 (Dtf)

    Discrete 2 of 5 (DTF) Enable/Disable Discrete 2 of 5 To enable or disable Discrete 2 of 5, scan the appropriate bar code below. C-50...

  • Page 100: Set Lengths For Discrete 2 Of 5

    Set Lengths for Discrete 2 of 5 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for D 2 of 5 to any length, one or two discrete lengths, or lengths within a specific range.
  • Page 101 Any Length - Scan this option to decode D 2 of 5 symbols containing any number of  characters within the decoder’s capability. NOTE Due to the construction of the D 2 of 5 symbology, it is possible for a scan line covering only a portion of the code to transmit as a complete scan, yielding less data than is encoded in the bar code.
  • Page 102 Codabar (NW - 7) Enable/Disable Codabar To enable or disable Codabar, scan the appropriate bar code below. C-53...
  • Page 103 Set Lengths for Codabar The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for Codabar to any length, one or two discrete lengths, or lengths within a specific range. One Discrete Length - Select this option to decode only Codabar symbols containing a ...
  • Page 104 Any Length - Scan this option to decode Codabar symbols containing any number of  characters within the decoder’s capability. C-55...
  • Page 105 CLSI Editing Enable this parameter to strip the start and stop characters and insert a space after the first, fifth, and tenth characters of a 14-character Codabar symbol. Enable this feature if the host system requires this data format. NOTE Symbol length does not include start and stop characters.
  • Page 106 Codabar Upper or Lower Case Start/Stop Characters Detection Select whether to detect upper case or lower case Codabar start/stop characters. C-57...

  • Page 107: Msi

    Enable/Disable MSI To enable or disable MSI, scan the appropriate bar code below. C-58...

  • Page 108: Set Lengths For Msi

    Set Lengths for MSI The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for MSI to any length, one or two discrete lengths, or lengths within a specific range. One Discrete Length - Select this option to decode only MSI symbols containing a ...
  • Page 109 Any Length - Scan this option to decode MSI symbols containing any number of  characters within the decoder’s capability. NOTE Due to the construction of the MSI symbology, it is possible for a scan line covering only a portion of the code to transmit as a complete scan, yielding less data than is encoded in the bar code.

  • Page 110: Msi Check Digit

    MSI Check Digits With MSI symbols, one check digit is mandatory and always verified by the reader. The second check digit is optional. If the MSI codes include two check digits, scan the Two MSI Check Digits bar code to enable verification of the second check digit. MSI Check Digit Algorithm on next page for the selection of second digit algorithms.

  • Page 111: Msi Check Digit Algorithm

    MSI Check Digit Algorithm Two algorithms are possible for the verification of the second MSI check digit. Select the bar code below corresponding to the algorithm used to encode the check digit. C-62...

  • Page 112: Chinese 2 Of 5

    Chinese 2 of 5 Enable/Disable Chinese 2 of 5 To enable or disable Chinese 2 of 5, scan the appropriate bar code below. C-63...

  • Page 113: Matrix 2 Of 5

    Matrix 2 of 5 Enable/Disable Matrix 2 of 5 To enable or disable Matrix 2 of 5, scan the appropriate bar code below. C-64...

  • Page 114: Set Lengths For Matrix 2 Of 5

    Set Lengths for Matrix 2 of 5 The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Set lengths for Matrix 2 of 5 to any length, one or two discrete lengths, or lengths within a specific range.
  • Page 115 Any Length - Scan this option to decode Matrix 2 of 5 symbols containing any number  of characters within the decoder’s capability. C-66...

  • Page 116: Matrix 2 Of 5 Check Digit

    Matrix 2 of 5 Check Digit The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the Matrix 2 of 5 check digit.

  • Page 117: Korean 3 Of 5

    Korean 3 of 5 Enable/Disable Korean 3 of 5 To enable or disable Korean 3 of 5, scan the appropriate bar code below. NOTE The length for Korean 3 of 5 is fixed at 6. C-68...

  • Page 118: Inverse 1D

    Inverse 1D This parameter sets the 1D inverse decoder setting. Options are: Regular Only - the decoder decodes regular 1D bar codes only.  Inverse Only - the decoder decodes inverse 1D bar codes only.  Inverse Autodetect - the decoder decodes both regular and inverse 1D bar codes. ...

  • Page 119: Postal Code

    Postal Codes US Postnet To enable or disable US Postnet, scan the appropriate bar code below. US Planet To enable or disable US Planet, scan the appropriate bar code below. C-70...

  • Page 120: Transmit Us Postal Check Digit

    Transmit US Postal Check Digit Select whether to transmit US Postal data, which includes both US Postnet and US Planet, with or without the check digit. C-71...

  • Page 121: Uk Postal

    UK Postal To enable or disable UK Postal, scan the appropriate bar code below. Transmit UK Postal Check Digit Select whether to transmit UK Postal data with or without the check digit. C-72...

  • Page 122: Japan Postal

    Japan Postal To enable or disable Japan Postal, scan the appropriate bar code below. Australia Post To enable or disable Australia Post, scan the appropriate bar code below. C-73...

  • Page 123: Australia Post Format

    Australia Post Format To select one of the following formats for Australia Post, scan the appropriate bar code below: Autodiscriminate (or Smart mode) - Attempt to decode the Customer Information Field  using the N and C Encoding Tables. NOTE This option increases the risk of misdecodes because the encoded data format does not specify the Encoding Table used for encoding.

  • Page 124: Netherlands Kix Code

    Netherlands KIX Code To enable or disable Netherlands KIX Code, scan the appropriate bar code below. USPS 4CB/One Code/Intelligent Mail To enable or disable USPS 4CB/One Code/Intelligent Mail, scan the appropriate bar code below. C-75...

  • Page 125: Upu Fics Postal

    UPU FICS Postal To enable or disable UPU FICS Postal, scan the appropriate bar code below. C-76...

  • Page 126: Gs1 Databar

    GS1 DataBar GS1 DataBar types are: GS1 DataBar Omnidirectional  GS1 DataBar Truncated  GS1 DataBar Stacked  GS1 DataBar Stacked Omnidirectional  GS1 DataBar Limited  GS1 DataBar Expanded  GS1 DataBar Expanded Stacked  Scan the appropriate bar codes to enable or disable each type of GS1 DataBar. GS1 DataBar Scan the appropriate bar code below to enable or disable the following code types: GS1 DataBar Omnidirectional...

  • Page 127: Gs1 Databar Limited

    GS1 DataBar Limited C-78...

  • Page 128: Gs1 Databar Limited Security Level

    GS1 DataBar Limited Security Level The decoder offers four levels of decode security for GS1 DataBar Limited bar codes. There is an inverse relationship between security and decoder aggressiveness. Increasing the level of security may result in reduced aggressiveness in scanning, so only choose the level of security necessary.

  • Page 129: Gs1 Databar Expanded

    GS1 DataBar Expanded Scan the appropriate bar code below to enable or disable the following code types: GS1 DataBar Expanded  GS1 DataBar Expanded Stacked.  Convert GS1 DataBar to UPC/EAN This parameter only applies to GS1 DataBar and GS1 DataBar Limited symbols not decoded as part of a Composite symbol.

  • Page 130: Composite Cc-C

    Composite Composite CC-C Scan a bar code below to enable or disable Composite bar codes of type CC-C. Composite CC-A/B Scan a bar code below to enable or disable Composite bar codes of type CC-A/B. NOTE If you enable this code type, also see UPC Composite Mode on next page. C-81...

  • Page 131: Composite Tlc-39

    Composite TLC-39 Scan a bar code below to enable or disable Composite bar codes of type TLC-39. C-82...

  • Page 132: Upc Composite Mode

    UPC Composite Mode Composite CC-A/B If you enable on previous page, select an option for linking UPC symbols with a 2D symbol during transmission as if they were one symbol: Select UPC Never Linked to transmit UPC bar codes regardless of whether a 2D ...

  • Page 133: Composite Beep Mode

    Composite Beep Mode To select the number of decode beeps when a composite bar code is decoded, scan the appropriate bar code. GS1-128 Emulation Mode for UCC/EAN Composite Codes Select whether to enable or disable this mode. C-84...

  • Page 134: Enable/Disable Pdf417

    2D Symbologies Enable/Disable PDF417 To enable or disable PDF417, scan the appropriate bar code below. Enable/Disable MicroPDF417 To enable or disable MicroPDF417, scan the appropriate bar code below. C-85...

  • Page 135: Code 128 Emulation

    Code 128 Emulation Enable this parameter to transmit data from certain MicroPDF417 symbols as Code 128. AIM Code ID Character must be enabled for this parameter to work. Enable Code 128 Emulation to transmit these MicroPDF417 symbols with one of the following prefixes: ]C1 if the first codeword is 903-905 ]C2 if the first codeword is 908 or 909...

  • Page 136: Data Matrix

    Data Matrix To enable or disable Data Matrix, scan the appropriate bar code below. Data Matrix Inverse This parameter sets the Data Matrix inverse decoder setting. Options are: Regular Only - the decoder decodes regular Data Matrix bar codes only. ...

  • Page 137: Decode Mirror Images (Data Matrix Only)

    Decode Mirror Images (Data Matrix Only) Select an option for decoding mirror image Data Matrix bar codes: Always - decode only Data Matrix bar codes that are mirror images  Never - do not decode Data Matrix bar codes that are mirror images ...

  • Page 138: Qr Code

    Maxicode To enable or disable Maxicode, scan the appropriate bar code below. QR Code To enable or disable QR Code, scan the appropriate bar code below. C-89...

  • Page 139: Qr Inverse

    QR Inverse This parameter sets the QR inverse decoder setting. Options are: Regular Only - the decoder decodes regular QR bar codes only.  Inverse Only - the decoder decodes inverse QR bar codes only.  Inverse Autodetect - the decoder decodes both regular and inverse QR bar codes. ...

  • Page 140: Aztec Inverse

    Aztec To enable or disable Aztec, scan the appropriate bar code below. Aztec Inverse This parameter sets the Aztec inverse decoder setting. Options are: Regular Only - the decoder decodes regular Aztec bar codes only.  Inverse Only - the decoder decodes inverse Aztec bar codes only. ...

  • Page 141: Han Xin

    Han Xin To enable or disable Han Xin, scan the appropriate bar code below. Han Xin Inverse Select a Han Xin inverse decoder setting: Regular Only - the decoder decodes Han Xin bar codes with normal reflectance only.
  Inverse Only - the decoder decodes Han Xin bar codes with inverse reflectance only.

  • Page 142: Redundancy Level

    Redundancy Level The decoder offers four levels of decode redundancy. Select higher redundancy levels for decreasing levels of bar code quality. As redundancy levels increase, the decoder’s aggressiveness decreases. Select the redundancy level appropriate for the bar code quality. Redundancy Level 1 The following code types must be successfully read twice before being decoded: Code Type Code Length...
  • Page 143 Redundancy Level 4 The following code types must be successfully read three times before being decoded: Code Type Code Length C-94...

  • Page 144: Security Level (Upc/Ean And Code 39)

    Security Level The decoder offers four levels of decode security for delta bar codes, which include UPC/EAN and Code 93. Select increasing levels of security for decreasing levels of bar code quality. There is an inverse relationship between security and decoder aggressiveness, so choose only that level of security necessary for any given application.
  • Page 145 Security Level 3: If you selected Security Level 2 and misdecodes still occur, select this  security level. Be advised, selecting this option is an extreme measure against mis-decoding severely out of spec bar codes. Selecting this level of security significantly impairs the decoding ability of the decoder.

  • Page 146: Intercharacter Gap Size

    Intercharacter Gap Size The Code 39 and Codabar symbologies have an intercharacter gap that is typically quite small. Due to various bar code-printing technologies, this gap can grow larger than the maximum size allowed, preventing the decoder from decoding the symbol. If this problem occurs, scan the Large Intercharacter Gaps parameter to tolerate these out-of-specification bar codes.

  • Page 147: Macro Pdf

    Macro PDF Features Macro PDF Transmit / Decode Mode Symbols Transmit Macro PDF Control Header C-98...

  • Page 148: Escape Characters

    Escape Characters Flush Macro Buffer Abort Macro PDF Entry C-99...

  • Page 149: Ascii Character Sets

    Apendix ASCII Character Sets Full ASCII Code 39 Encode Char. Code Type Keystroke 1000 CTRL 2 1001 CTRL A 1002 CTRL B 1003 CTRL C 1004 CTRL D 1005 CTRL E 1006 CTRL F 1007 CTRL G 1008 CTRL H /BACKSPACE 1009 CTRL I / HORIZONTAL TAB 1010...
  • Page 150 Full ASCII Code 39 Encode Char. Keystroke 読取値 1025 CTRL Y 1026 CTRL Z 1027 CTRL [ CTRL \ (※¥) 1028 1029 CTRL ] 1030 CTRL 6 1031 CTRL - 1032 Space Space 1033 1034 ‘ 1035 1036 1037 1038 &...
  • Page 151 Full ASCII Code 39 Encode Char. ASCII Value Keystroke 1055 1056 1057 1058 1059 1060 < 1061 1062 > 1063 1064 1065 1066 1067 1068 1069 1070 1071 1072 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084...
  • Page 152 Full ASCII Code 39 Encode Char. ASCII Value Keystroke 1085 1086 1087 1088 1089 1090 1091 \ (※¥) 1092 1093 1094 1095 1096 ‘ 1097 1098 1099 1100 1101 1102 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114...
  • Page 153 Full ASCII Code 39 Encode Char. ASCII Value Keystroke 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124 1125 1126...

  • Page 154: Numeric Bar Codes

    Numeric Bar codes...
  • Page 155 Cansel To correct an error or change a selection, scan the bar code below.
  • Page 156 Symbol Code Identifiers Code Character Code Type JAN(UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13) Code 39, Code 32 NW7(Codabar) Code 128, ISBT 128, ISBT 128 Concatenated Code 93 Interleaved 2 of 5 Discrete 2 of 5, or Discrete 2 of 5 IATA Code 11 GS1-128 Bookland EAN...
  • Page 157 AIM Code Identifiers Each AIM Code Identifier contains the three-character string ]cm where: ] = Flag Character (ASCII 93) c = Code Character (See table below) m = Modifier Character (See table at next page) Code Character Code Type Code 39, Code 39 Full ASCII, Code 32 Code 128, ISBT 128, ISBT 128 Concatenated, GS1-128, Coupon (Code 128 portion) Data Matrix...
  • Page 158 Modifier Character The modifier character is the sum of the applicable option values based on the table below. Code Type Option Value Option Code 39 No check character or Full ASCII processing. Reader has checked one check character. Reader has checked and stripped check character. Reader has performed Full ASCII character conversion.
  • Page 159 Code Type Option Value Option Codabar No check digit processing. Reader has checked check digit. Reader has stripped check digit before transmission. Example: A Codabar bar code without check digit, 4123, is transmitted as ]F04123 Code 93 No options specified at this time. Always transmit 0.
 Example: Code code...
  • Page 160 ISSN EAN No options specified at this time. Always transmit 0. Example: ISSN code 123456789X transmitted as ]X0123456789X Code 11 Single check digit
 Two check digits
 Check characters validated but not transmitted. GS1 DataBar Family No option specified at this time. Always transmit 0. GS1 DataBar and GS1 DataBar Limited transmit with an Application Identifier “01”.
...
  • Page 161 symbology specifications. Note: When this option is transmitted, the receiver cannot reliably determine whether ECIs have been invoked or whether data byte 92 been doubled in transmission. Reader set to follow the ECI protocol (Extended Channel Interpretation). All data characters 92 DEC are doubled. Reader set for Basic Channel operation (no escape character transmission protocol).
  • Page 162 secondary message. QR Code Model 1 symbol. Model 2 / MicroQR symbol, ECI protocol not implemented. Model 2 symbol, ECI protocol implemented. Model 2 symbol, ECI protocol not implemented, FNC1 implied in first position. Model 2 symbol, ECI protocol implemented, FNC1 implied in first position.

This manual is also suitable for:

Asr-020d

Table of Contents
