- Page 1 GVL 8408-M en Original instructions ..... . . Page ..2 99.824.66 1.6/03/16...
-
Page 2: Example For Application
Operating voltage 115 VAC! Connection has to be carried out only by an authorized electrical specialist. Mounting of the control panel should be carried out by a D+H distributor, whose qualification and experience is ensured by regular in-house training. All wiring must be installed by a qualified electrican according to e.g. National Electrical Codes, NFPA 70 and local codes. -
Page 3: Intended Use
Intended use Technical data - ventilation control for small to medium sized Type : GVL 8408-M building objects Nominal voltage : 115 V AC ± 10%, 60 Hz - for triggering of 24 V DC drives Rated power : 240 VA... - Page 4 (e.g. green / yellow) this must not be used! Line lenghts and cross sections total current total current type type 2x AWG 16 2x 1,5 mm² 1312 2x AWG 14 2x 2,5 mm² 2100 1050 2x AWG 12 2x 4 mm² GVL 8408-M English 99.824.66 1.6/03/16...
- Page 5 External contact (e.g. LT 84-U-SD) for central closing Mot.b (e.g. rain detector) Mot.a Mot.b Line lengths and cross sections see page 4 GVL 8408-M GVL 8408-M Ask your local D+H partner for further connection examples. 99.824.66 1.6/03/16 English GVL 8408-M...
- Page 6 Mot.b branch box Line lengths and cross sections insert bridge! see page 4 GVL 8408-M GVL 8408-M Connect lead directly when no automatic switch available. In this case the manual operation is out of function. GVL 8408-M English 99.824.66 1.6/03/16...
-
Page 7: Maintenance And Cleaning
Because of varied possiblilties for choosing drives, according to D+H maintenance notes. Only original Please take mounting informations from relevant D+H spare parts may be used. Repair is to be carried instructions for use of the respective drive. out exclusively by D+H. - Page 8 D+H Mechatronic AG Georg-Sasse-Str. 28-32 22949 Ammersbek , Germany Tel. : +49 40-605 65 : +49 40-605 65 254 E-Mail: info@dh-partner.com www.dh-partner.com © 2012 D+H Mechatronic AG, Ammersbek Technische Änderungen vorbehalten. / Rights to technical modifications reserved. 99.824.66 1.6/03/16...
