Fluke 421D Technical Data Manual page 2

General specifications
Technical specifications
Range (for extended
distances, use a target plate)*
Measuring accuracy**
Laser class
Laser type
Automatic power off
Continuous measure ment
Addition/subtraction
Battery life
LCD illumination
Data locations
Min/Max
Audible feedback
Pythagoras (Indirect
measurement)
Room angle and stakeout
±45 ° Tilt sensor/
indirect measure
Ingress protection
Dimensions
Weight
Temperature range
Storage -25 °C to 70 °C (-13 °F to 158 °F)
Operation 0 °C to 40 °C (32 °F to 104 °F)
Operating altitude (ISO 9022)
Storage humidity (at 35 °C)
Batteries
Why use a distance meter?
Reduce measuring
time: Instant measure-
ments with the touch of
a button.
Quickly measure long
distances: Measure
up to 100 m (330 ft),
easier, and more accu-
rately than with a tape
measure.
Increase measuring
accuracy: Get accuracy
up to 1.5 mm (1/16 in),
eliminating any guesswork.
One-person measuring: With a laser, there is no need
for a second person.
One-handed operation: Laser measuring devices are
easily operated with one hand.
Safety: A laser measuring device allows you to measure
areas you may not be able to safely access.
Obtain difficult measurements: Easily measure inside
a false ceiling.
Determine square footage and volume: Automatic
calculation of area (square footage) and volume, with
the touch of a button.
For more information visit www.fluke.com/101uses
2 Fluke Corporation Fluke 421D, 416D and 411D Laser Distance Meters
Fluke 411D
0.1 m to 30 m
(0.33 ft to 100 ft)
± 3 mm (0.118 in)
II
635 nm, < 1 mW
after 180 seconds
•
•
up to 3,000 measurements
—
—
—
—
Simple
—
—
IP40
123 mm x 50 mm x 26 mm
(4.84 in x 1.97 in x 1.02 in)
150 g (5.29 oz)
-25 °C to 70 °C (-13 °F to 158 °F)
0 °C to 40 °C (32 °F to 104 °F)
up to 3500 m
maximum 85 % for 24 h
AAA (2)
Fluke 416D
0.05 m to 60 m
(0.16 ft to 200 ft)
± 1.5 mm (± 0.059 in)
II
635 nm, < 1 mW
after 180 seconds
•
•
up to 5,000 measurements
•
10
•
•
Full
—
—
IP54
135 mm x 46 mm x 31 mm
(5.31 in x 1.81 in x 1.22 in)
110 g (3.88 oz)
-25 °C to 70 °C (-13 °F to 158 °F)
0 °C to 40 °C (32 °F to 104 °F)
up to 3500 m
maximum 85 % for 24 h
AAA (2)
Ordering information
Fluke 421D
Fluke 416D
Fluke 411D
All models include: Laser Distance Meter, Two AAA
batteries, Users manual on CD, Quick Start Guide, Nylon
carrying case, and Two-year warranty
* In favorable condi-
Fluke 421D
tions (optimal target
0.05 m to 100 m
surface, room tem-
(0.16 ft to 330 ft)
perature) up to 10 m
(33 ft). In unfavorable
± 1.5 mm (± 0.059 in)
conditions, such as
II intensive sunshine,
very weakly reflecting
635 nm, < 1 mW
target surface, or large
temperature fluc-
After 180 seconds
tuations, measuring
•
accuracy may deterio-
rate to approx. ± 0.25
•
mm/m (± 0.003 in/ft)
for distances above
up to 5,000 measurements
10 m (33 ft).
•
** In favorable condi-
tions (optimal target
20
surface, room tem-
•
perature) up to 10 m
(33 ft). In unfavorable
•
conditions, such as
intensive sunshine,
Full
very weakly reflecting
target surface, or large
•
temperature fluc-
tuations, the deviation
•
over distances 10 m
(33 ft) can increase by
approx. ± 0.15 mm/m
IP54
(± 0.0018 in/ft).
127 mm x 52 mm x 29 mm
(5.00 in x 2.06 in x 1.13 in)
125 g (4.40 oz)
up to 3500 m
maximum 85 % for 24 h
AAA (2)
Laser Distance Meter
Laser Distance Meter
Laser Distance Meter
