- Page 1 Fluke 43B Power Quality Analyzer Getting Started June 2005 © 2001-2005 Fluke Corporation, All rights reserved. Printed in The Netherlands. All product names are trademarks of their respective companies.
-
Page 2: Placing Orders And Getting Assistance
PLACING ORDERS AND GETTING ASSISTANCE To locate an authorized service center, visit us on the World Wide Web: http://www.fluke.com or call Fluke using any of the phone numbers listed below: +1-888-993-5853 in U.S.A. and Canada +31-40-2675200 in Europe +1-425-446-5500 from other countries... -
Page 3: Getting Started Unpacking
Getting Started Unpacking Unpacking The following items are included in your Fluke 43B kit:.. Figure 1. Carrying Case Contents Fluke 43B Power Quality Analyzer BP120MH Ni-MH Battery Pack (installed) PM8907/8xx Power Adapter/Battery Charger TL24 Test Leads, red and black Flat blade Test Pins, red and black... -
Page 4: Safety Information: Read First
A “Warning” identifies conditions and actions that pose hazard(s) to the user. A “Caution” identifies conditions and actions that may damage the Fluke 43B. The following international symbols are used on the Fluke 43B and in this manual: Read the safety information in Double Insulation... - Page 5 Getting Started Safety Information: Read First Warning Do the following to avoid electrical shock or fire if a Fluke 43B common input is connected to more than 42 V peak (30 V rms): Use only test leads and test lead adapters supplied with the Fluke 43B (or safety-designed equivalents as specified in the accessory list, see Users Manual.)
-
Page 6: Current Probe
Before using, inspect the test leads for mechanical damage and replace damaged test leads! If it is likely that safety has been impaired, turn the Fluke 43B off and disconnect it from the line power. The matter should then be referred to qualified personnel. - Page 7 Turn the Fluke 43B on. The opening screen will appear on the display (see Figure 3). Note If the Fluke 43B does not turn on, the batteries may be dead. Leave the Fluke 43B connected to the outlet for 15 minutes and try again.
- Page 8 Fluke 43B Getting Started Figure 3. Opening Screen The screen shows which test leads or probes you should use on the inputs. TEST Note that in the screen shown in Figure 3, for example, you should use for voltage measurements and a 1 mV/A current probe for current LEADS measurements.
- Page 9 Use the black test lead on the COM input ( Use these inputs for all voltage measurements, and for Ohm, continuity, diode capacitance and temperature measurements. The Fluke 43B common inputs (red INPUT 1 shield, gray INPUT 2 shield, and black COM input) are connected internally via self-recovering fault protection.
- Page 10 Fluke 43B Getting Started Main Menu All functions can be easily selected from the main menu. Open the main menu. VOLTS AMPS HERTZ (for example) INRUSH CURRENT OHMS CONTINUITY CAPACITANCE Measures inrush current and Measures resistance, diodes, inrush time (motor start-ups).
-
Page 11: Getting Started Main Menu
Getting Started Main Menu VOLTS AMPS HERTZ POWER Gives a fast overview of Volts, Amps Shows all power readings in one and Hertz. screen. & HARMONICS SAGS SWELLS Measures up to 51 harmonics. Shows dips and surges as short as one cycle. -
Page 12: Volts / Amps / Hertz
Fluke 43B can perform power measurements on balanced 3-phase, 3- conductor power systems. The load must be well balanced and have either a wye or delta configuration. This makes it possible to measure 3 phase power using single phase connections. -
Page 13: Inrush Current
Getting Started Main Menu Sags & Swells Sags and swells measures fast deviations (from one cycle to a few seconds) from the normal voltage signal, and displays current simultaneously. The results are plotted on the screen as a graph. The graph shows the minimum and maximum values at each point of the graph. -
Page 14: Selecting Probes
Fluke 43B Getting Started Selecting Probes For standard operation, use the red test lead on input , the black test lead on COM and the current clamp on input . If you are using other test leads or probes, you must change the probe settings accordingly. - Page 15 Getting Started Selecting Probes Move to the probe settings for input 2. (for the i400s current probe) Accept the probe settings for input 2. Note Select 1V/A when using testleads on input [2] in the Scope Mode. A reading of 1A then equals 1V.
-
Page 16: Selecting A Language
Fluke 43B Getting Started Selecting a Language You can choose between English and other languages. To change the language for example into Spanish, do the following: Note Combinations of languages (one or more) depend on the version ordered. Open the main... -
Page 17: Using Flukeview Software
Getting Started Using FlukeView Software Using FlukeView Software This section explains how to connect the Fluke 43B to a PC for use with the ® ® FlukeView Power Quality Analyzer software or to create reports in MS-Word Use the Optically Isolated USB Cable on the optical port to connect the Fluke 43B to a PC (see Figure 5). - Page 18 Getting Started Resetting the Fluke 43B To restore the Fluke 43B to its factory settings and return to the opening screen, reset the Fluke 43B. Resetting does not clear screen memories. Turn the Fluke 43B off and proceed as follows: Press and hold.
