- Page 1 ELECTRIC BIKES OWNER MANUAL DISCOVERY ROSEMONT LE1 DISCOVERY YORKVILLE LE1 DISCOVERY ROSEMOUNT LS1 DISCOVERY YORKVILLE LS1 OUTLAND CABOT RS1 OUTLAND SAWBACK RS1 OUTLAND TORNGAT RS1 RIDE THIS WAY...
- Page 2 DISCOVERY YORKVILLE LE1 DISCOVERY ROSEMONT LS1 ride for riding’s sake, you will do so in comfort and confidence on your new iGO electric bike. If you want to know more about your electric bike or discover tips and hints to get the most out of any ride, consult the ever expanding wealth of knowledge available at : assist.igoelectric.com...
-
Page 3: Table Of Contents
Installing The Handlebars (4 Bolt Stem) Rear Wheel Removal And Installation Tire Pressure Adjusting The Suspension Fork Quick Release, Q-Loc, And Thru Axel Fork For assistance setting up your new iGO eBike, a full assembly instruction video is available at : www.igoelectric.com/unboxing... -
Page 4: Igo Drive
Short press the PLUS (+) or MINUS (-) button to switch between PAS levels. When power is turned on, your iGO eBike will start in PAS ‘0’ as a safety precaution. In this state no power is provided to the throttle or to the pedal assist. -
Page 5: Display Settings
Short press the POWER BUTTON to select the hi-lighted option. Set displayed battery voltage values. The default value should be the correct value for your bike. If you are unsure the value set is correct contact iGO support. 1 : 31.6 SETTING 2 : 34.6... -
Page 6: Advanced Settings
ATTENTION : Riding an ebike in class 3 in an area prohibited by law is a punishable offence. It Back is the riders responsibility to familiarize themselves regarding these regulations and further Return to the previous menu. agrees to hold iGO/Fermetco harmless or responsible in any way in the operation of their ebike. -
Page 7: What Is Pedal Assistance
Pedal Assist System (PAS) level. These iGO eBikes have a 5 level PAS. As a rule, with the bike over any surface that may be difficult to pull/push the bike through (mud, snow, a lower PAS number will indicate the motor is providing less assistance (ideal for flat roads, sand, etc). -
Page 8: Removing The Throttle
BATTERY All iGO batteries are secured to the bike frame using a barrel lock mechanism. The battery can be removed from the frame for charging, storage, or when leaving the bike in a public area by using the keys provided with the bike. Keys should always be removed from the bike before riding. -
Page 9: Remove / Install Battery
DRIVE REMOVE / INSTALL BATTERY CHARGING THE BATTERY To remove the battery from the bike frame first remove the battery The battery can be charged both on and off of the bike. cover under the battery tube by pushing down on the top latch and It is important to follow these charging instructions in order : tipping the top edge down on an angle, then lift and remove. -
Page 10: Battery Range And Capacity
The battery is intended to be charged when the ambient temperature is between 0°C (32°F) allow sufficient range to sustain an active riding schedule between charges. -
Page 11: Electronics Access Port (Eap)
DRIVE MECHANICAL COMPONENTS for : DISCOVERY ROSEMONT LE1 | DISCOVERY YORKVILLE LE1 THE GROUPSET ELECTRONICS ACCESS PORT (EAP) A bike’s groupset refers to the mechanical parts that are involved in braking, changing gears, The Electronics Access Port gives easy access to the controller, wiring harness and sensor or powering the drivetrain. -
Page 12: Shimano Trigger Shifters
‘shift up’. This will move the chain to a smaller gear on the rear wheel, and the indicator will show a higher number. Pedaling will be harder. The hydraulic brake system on your iGO electric bike is self adjusting, and will not require manual adjustment during normal operation. -
Page 13: Adjustability And Igo Ergofit
The adjustable stem has an effective quick-release mechanism that will allow you to unlock, adjust and retighten the stem and handlebar position. iGO Bikes equipped with the Ergofit system have toolless adjustable reach, pitch and height allows riding posture to be adapted instantly at any time for : To use, find the lock button in the middle top of the stem and slide it forward to unlock the main lever. -
Page 14: Rear Wheel Removal And Installation
ADJUSTING THE SUSPENSION FORK Hub Motor equipped iGO electric bikes incorporate the drive motor, so Many iGO electric bikes are equipped with a suspension fork with a lockout. By turning removal and re-installation requires a few special considerations. the lever on the top of the right fork leg in the direction indicated, you are able to ‘lockout’, or stiffen up the fork for more efficient riding. - Page 15 MECHANICAL COMPONENTS PUSH PUSH for : OUTLAND CABOT RS1 | OUTLAND SAWBACK RS1 TURN TURN Q-LOC assembly Check the segmented flange is expanded before installation. Open the lever completely. 2. Slide in the axle until it “clicks”. Make sure the segmented flange is expanded. 3.
-
Page 16: Igo Assist
Description Suggested action phone support - iGO Assist can deliver everything you need to get on an electric bike for the first time; it will answer any questions you may have during your ride, and can share Synchronous motor signal overcurrent warning Check motor connections, unplug and ensure pins are expert tips and tricks to make sure you always get the most from your iGO electric bike. -
Page 17: Main Technical Parameters, Specifications, And Parts
ASSIST MAIN TECHNICAL PARAMETERS, SPECIFICATIONS, AND PARTS MAIN TECHNICAL PARAMETERS, SPECIFICATIONS, AND PARTS DISCOVERY ROSEMONT LE1 DISCOVERY YORKVILLE LE1 SKU : 100-211-001 SKU : 100-221-001 PART DESCRIPTION PART DESCRIPTION FRAME Hydroformed Aluminum Step Through 45.7cm (18”) ERGOFIT FRAME Hydroformed Aluminum Hybrid 48cm (19”) ERGOFIT... -
Page 18: Discovery Rosemont Ls1
ASSIST MAIN TECHNICAL PARAMETERS, SPECIFICATIONS, AND PARTS MAIN TECHNICAL PARAMETERS, SPECIFICATIONS, AND PARTS DISCOVERY ROSEMONT LS1 DISCOVERY YORKVILLE LS1 SKU : 100-212-001 SKU : 100-222-001 PART DESCRIPTION PART DESCRIPTION FRAME Hydroformed Aluminum Step Through 45cm (17.7”) FRAME Hydroformed Aluminum Hybrid 48cm (19”) -
Page 19: Outland Cabot Rs1
ASSIST MAIN TECHNICAL PARAMETERS, SPECIFICATIONS, AND PARTS MAIN TECHNICAL PARAMETERS, SPECIFICATIONS, AND PARTS OUTLAND CABOT RS1 OUTLAND SAWBACK RS1 SKU : 100-233-101 SKU : 100-322-201 PART DESCRIPTION PART DESCRIPTION FRAME Hydroformed Aluminum Trekking 49cm (19.3”) FRAME Hydroformed Aluminum Hardtail 27.5 MTB 49cm (19.3”) -
Page 20: Outland Torngat Rs1
ASSIST MAIN TECHNICAL PARAMETERS, SPECIFICATIONS, AND PARTS TORQUE TABLE OUTLAND TORNGAT RS1 SKU : 100-322-301 The following table provides the recommended torque values for components. Ensure all fasteners are tightened carefully and checked regularly. Use PART DESCRIPTION of a torque wrench is advised to check values are correct. -
Page 21: Servicing
ASSIST SERVICING IMPORTANT SAFETY INSTRUCTIONS Servicing your bike is very important. You can avoid unnecessary ALWAYS WEAR AN APPROVED BICYCLE HELMET WHEN RIDING AN ELECTRIC BIKE damage by servicing your bike regularly. ALWAYS OBEY THE BIKING RULES OF THE ROAD AND PRACTICE PROPER BIKING ETIQUETTE... -
Page 22: Warranty
In no event shall iGO be liable for any loss, inconvenience or damage, whether direct, incidental, consequential or otherwise, resulting from a breach of any express or •... -
Page 23: Warranty Terms
1.1 iGO Electric guarantees that the iGO product you have purchased 5.1 If it is determined by iGO that a bike/part is to be returned to iGO, it must be done in it’s is free from material and/or workmanship faults. -
Page 24: Register Your Ebike
Complete the required information and click SUBMIT at the bottom of the page. It is advisable to create a customer account on the iGO website. Once created you can add and view all eBikes registered to your account and track communication with iGO support. - Page 25 Established in 2006 i G O E L E C T R I C . C O M...
