- Page 1 FOLDING FAT ELECTRIC BIKE USER MANUAL PLEASE READ THIS MANUAL BEFORE OPERATING AND WATCH THE FULL ASSEMBLY INSTRUCTIONAL VIDEO AT: w w w . i g o e l e c t r i c . c o m / b u i l d m y m f a t...
- Page 2 Electric reserves the right to make changes without notice to design(s) and / prices listed in this manual. This manual has be compiled with great care. iGO can not be held responsible for any inaccuracies whatsoever. w w w . i g o e l e c t r i c . c o m...
- Page 3 Completely new way of cycling. Whether you use the ebike for commuting, shopping or just a leisurely ride, you will do so comfortably and confidently on your new iGO. Chances are that you have not previously owned an electric bike with pedal assistance.
-
Page 4: Table Of Contents
TABLE OF CONTENTS DISPLAY & FUNCTIONS BUTTONS INFORMATION ON THE SCREEN ERROR INDICATION CONTROLS PEDAL ASSISTANCE WHAT IS PEDAL ASSISTANCE? TURNING PEDAL ASSISTANCE ON/OFF DERAILLEUR FUNCTIONS MORE INFORMATION ON PEDAL ASSISTANCE BATTERY & CHARGING BATTERY RANGE DISCONNECTING AND REMOVING THE BATTERY CHARGING THE BATTERY WHAT YOU SHOULD KNOW ABOUT YOUR BATTERY HOW TO STORE YOUR BATTERY DURING NON USE... - Page 5 ADJUSTING YOUR EBIKE (Cont'd) GEARS TIRE PRESSURE MAINTENANCE SERVICING GENERAL MAINTENANCE CLEANING PARTS PARTS LIST WARRANTY INFORMATION WARRANTY WARRANTY LIMITATIONS WARRANTY TERMS WARRANTY CARD PLEASE READ IMPORTANT BATTERY STORAGE INFORMATION ON PAGE 16 IMPROPER STORAGE OF YOUR BATTERY COULD RESULT IN TOTAL BATTERY FAILURE w w w .
-
Page 6: Display & Functions
DISPLAY & FUNCTIONS Before using the functions of the handlebar mounted display, the main power to the bike must be turned on. Please locate the power key switch located on the left side top of the battery. You must turn the key to the on position and keep key locked into bike. To turn off main power simply turn the key to the off position and remove key. -
Page 7: Information On The Screen
DISPLAY & FUNCTIONS INFORMATION ON THE SCREEN SPEED Km/h (km/h or mph) ASSISTANCE LEVEL (1-5) BATTERY INDICATOR 6 Bars = Full Battery ENERGY CONSUMPTION INDICATOR Full bars = High battery consumption = Less range ODOMETER Total distance traveled TRIP TRIP ODOMETER Distance traveled since last reset TIMER Trip timer... -
Page 8: Error Indication
DISPLAY & FUNCTIONS ERROR INDICATION MOTOR FAILURE If error persists contact iGO Technical Support THROTTLE FAILURE If error persists contact iGO Technical Support CONTROLLER FAILURE If error persists contact iGO Technical Support BRAKE CUT OFF SWITCH Check brake lever for physical damage LOW VOLTAGE PROTECTION + –... -
Page 9: Controls
DISPLAY & FUNCTIONS CONTROLS Turning the ebike ON/OFF Press and hold the 'ON/OFF' Button for 2 seconds to turn the electric system on or off. The control panel can only be used when the battery is connected to the ebike and key switched to the 'on' position. If the system is not used for a duration of 5 minutes, it will shut itself off to conserve battery. -
Page 10: Pedal Assistance
PEDAL ASSISTANCE WHAT IS PEDAL ASSISTANCE? The bike is equipped with 5 levels of electronic pedal assistance. As you pedal, the motor will assist you and enhance your pedaling effort. This will allow you to pedal much further and faster but use much less energy and effort. It is also a great feature when climbing a hill, as the motor will help to make any climb easy. -
Page 11: More Information On Pedal Assistance
PEDAL ASSISTANCE SAFETY PRECAUTIONS WHILE USING THE PEDAL ASSIST & ON DEMAND THROTTLE • Since the motor is assisting you, you will easily reach higher speeds than you might be used to. We recommend that you ride the bike in a minimal traffic area at first to become more comfortable with it. -
Page 12: Battery & Charging
BATTERY & CHARGING BATTERY RANGE How far can I travel on my electric bike? The total distance you can travel on your electric bike is not an easy amount to specify. The range depends on many different factors including, but not limited to: •... -
Page 13: Disconnecting And Removing The Battery
BATTERY & CHARGING DISCONNECTING & REMOVING THE BATTERY Please note that the main power position of the battery lock must be in the "On" position before pressing the "Power On" button on the display To unlock battery for removal Key is locked into bike and cannot be removed when in the "off" or "on" position. To remove the battery from either of these positions: Turn key counter clockwise to the "unlock"... -
Page 14: Charging The Battery
BATTERY & CHARGING CHARGING THE BATTERY The battery can be charged both on and off of the bike. Please identify your charging port (figure 14.1). First plug the chargers male plug into the battery, then plug the chargers 110 volt plug into your wall outlet. (Do not use an extension for 110 volt.) The indicator on the charger will light green for a few seconds and if a charge is necessary, the LED will turn red. -
Page 15: What You Should Know About Your Battery
BATTERY & CHARGING WHAT YOU SHOULD KNOW ABOUT YOUR BATTERY • DO NOT connect the positive terminal of the battery to the negative terminal. • The battery is sealed and therefore is rain resistant, however, DO NOT expose your battery to water. •... -
Page 16: How To Store Your Battery During Non Use
BATTERY & CHARGING IMPORTANT BATTERY STORAGE INFORMATION When not using your bike for periods exceeding one month please charge as follows: 1. Before storage make sure that the battery is not charged more than 50% so that it will except a periodic charge. (You cannot periodically charge a fully charged battery) 2. -
Page 17: Folding/Unfolding Your Ergofit Ebike
FOLDING/UNFOLDING YOUR ERGOFIT EBIKE FOLDING / UNFOLDING Follow these simple steps to fold your electric bike STEP 1 (pedals) Push the outside edge of the pedal towards the frame and twist until the folding section is parallel to the frame. STEP 2 (handlebar and stem) Release the 'safety catch' mechanism on the stem by rotating clockwise. - Page 18 FOLDING/UNFOLDING YOUR ERGOFIT EBIKE FOLDING / UNFOLDING (Cont’d) STEP 4 (frame) Release the 'safety catch' mechanism located close to the bottom bracket by lifting. Pull on the quick release lever to unlock the frame hinge then push the lever back towards the frame to fully clear the latch from the locking mechanism.
- Page 19 FOLDING/UNFOLDING YOUR ERGOFIT EBIKE FOLDING / UNFOLDING (Cont’d) To unfold your electric bike repeat the steps in reverse order. ATTENTION! Always make sure all safety catches are fully engaged before riding your folding electric bike. STEM SAFETY CATCH The stem safety catch is fully engaged when turned anticlockwise and the release lever cannot be opened .
-
Page 20: Adjusting Your Ebike
ADJUSTING YOUR ERGOFIT EBIKE ADJUSTING YOUR SEAT HEIGHT Your seat height should be adjusted properly to ensure you get the most comfortable ride possible. The seat height is properly adjusted when your knee has a slight bend when sitting on the saddle with your foot on the pedal at its lowest position (figure 20.1). -
Page 21: Adjusting Your Saddle Position
ADJUSTING YOUR ERGOFIT EBIKE ADJUSTING YOUR SADDLE POSITION You can tilt the saddle to change the seating angle, as well as, slide it backward or forward (figure 21.1). To adjust the saddle, loosen the nut located on the underside of the saddle with a wrench (figure 21.2). -
Page 22: Aligning The Brakes
ADJUSTING YOUR ERGOFIT EBIKE ALIGNING THE BRAKES Your electric bike is equipped with a disc brake system. To properly adjust them you must first make sure that the brake disc is properly aligned within the brake. To do this, loosen the top and bottom hex bolts (figure 22.1) with an Allen key. -
Page 23: Gears
ADJUSTING YOUR ERGOFIT EBIKE GEARS Your eBike comes equipped with a Shimano 8-speed drivetrain. The trigger shifter mounted to your right handle will allow you to change gears. It is important that you only change gears while cycling as the chain must be in motion to properly shift gears. To shift up a gear, pull the trigger closest to your index finger. -
Page 24: Maintenance
MAINTENANCE SERVICING Servicing your bike is very important. You can avoid unnecessary damage by servicing your bike regularly. In the paragraphs to follow, there are some simple tips you can follow at home to keep the bike running at top performance. GENERAL MAINTENANCE •... -
Page 25: Cleaning
MAINTENANCE CLEANING Regular cleaning of your ebike will prolong its life and reduce the appearance of rust and corrosion build up. REMOVE THE BATTERY BEFORE CLEANING and use brushes and wet sponges to remove dirt. Finish by drying with paper cloths / towel. (Use of a mild soap solution, degreaser, chain lube and a chain cleaning device are recommended for a thorough cleaning.) When cleaning the ebike do not submerge parts or let water accumulate by the... -
Page 26: Parts
PARTS PARTS LIST PART NO. PART DESCRI PTIO N P RICE - $(CA D) P150 SEAT B LACK 39.95 P151 SUSP EN SION SEAT POST 18.95 P152 SEAT CLAM P BLACK 9. 95 P153 REA R LI GHT SE AT POST M OUNT ED 16.95 P154 REA R FENDE R... - Page 27 PARTS PART NO. PART DESCRI PTIO N P RICE - $(CA D) P189 FOLDING FR A M E SE CURI TY LO C K 12.95 P190 FOLDING FR A NE SEC URI TY LO CK BO LT 6. 50 P191 FRO NT LIGHT 24.95 P192...
-
Page 28: Warranty Information
In no event shall iGO be liable for any loss, inconvenience or damage, whether direct, incidental, consequential or otherwise,... -
Page 29: Warranty Terms
3.2 iGO Electric is free of any liabilities in regards to (parts of) the bike being damaged as a result of: a. Improper adjustment of the handlebar, stem, saddle, seatpost, gears, brakes, quick release axles of the wheels, and spoke tension. - Page 30 Article 5: Transport of Warranty Products. 5.1 If it is determined by iGO that a bike/part is to be returned to iGO, it must be done in it’s original packaging. If the original packaging is not available, an equivalent package must be used to ensure the product is well protected from any damages it may incur during transport.
-
Page 31: Warranty Card
WARRANTY INFORMATION WARRANTY CARD Please fill out this form and mail it to iGO so that we can register your serial number in our system. Also, retain your receipt as proof of purchase. iGO Electric Attn: Warranty Card 1340, 55th Ave. - Page 32 NOTES w w w . i g o e l e c t r i c . c o m...
- Page 33 NOTES w w w . i g o e l e c t r i c . c o m...
- Page 34 NOTES w w w . i g o e l e c t r i c . c o m...
- Page 35 NOTES w w w . i g o e l e c t r i c . c o m...
- Page 36 1340, 55 su ppo r t@i goe le ctr i c. co m LACHINE, QC, H8T 3J8 ww w.i go el ectr i c.com CANADA IG OF FOLDMA1 8 0515E N...
