MG6100 series
2. REPAIR
2-1. Major Replacement Parts and Adjustment
Recommended removal procedure
Service part
Logic board
(1) Cassette unit
ass'y
(2) Left and right side covers
(3) Document pressure plate unit
(4) Scanner unit
(5) Main case
(6) Rear cover
(7) Logic board ass'y
- Before replacement, check the ink absorber counter
value (by service test print or EEPROM
information print).
- Before removal of the logic board ass'y, remove the
power cord, and allow for approx. 1 minute (for
discharge of capacitor's accumulated charges), to
prevent damages to the logic board ass'y.
Absorber kit
(1) Cassette unit
(2) Left and right side covers
(3) Document pressure plate unit
(4) Scanner unit
(5) Main case
(6) Rear cover
(7) Print unit
(8) Ink absorber
- See
absorber replacement,
Carriage unit
(1) Cassette unit
(2) Left and right side covers
replacement
2-2. Part Replacement Procedures, (11) Ink
for details.
*1
Adjustment / settings / operation
/ Notes on
In the service mode:
1. Set the ink absorber counter
2. Set the destination.
3. Print the integrated inspection
4. Perform LF / Eject correction
5. Set the sensitivity of the
6. Print the EEPROM information.
In the user mode:
7. Set the language displayed on the
8. Reset the LAN settings.
9. Perform print head alignment.
10. Print via USB connection.
11. Copy.
12. Perform direct printing from a
In the service mode:
1. Reset the ink absorber counter.
1. Apply grease to the sliding
13 / 66
TABLE OF CONTENTS
check
value.
pattern.
(only when streaks or uneven
printing occurs).
capacitive sensors.
[See
3-3. Adjustment and
Settings in Service Mode, (7)
Capacitive sensor sensitivity
setting, for details.]
[See
3-3. Adjustment and
Settings in Service
Mode, for
details.]
LCD.
digital camera (PictBridge).
[See
3-3. Adjustment and
Settings in Service
Mode, for
details.]
After the ink absorber counter is
reset, the counter value is printed
automatically.
portions of the carriage rail.
