- Page 1 HOME VENTILATION SYSTEMS SYN1015AD SYN2025AD SYN3035AD Installation Instructions The expert’s guide to installation for a healthier home...
-
Page 3: Table Of Contents
SMARTVENT SYNERGY3 SYSTEM Contents Definitions/Warning/Caution..............4 Kit Contents .................... 5 System Overview ..................6 Standard Systems ..................7 Installation ....................8 Preparation ................... 8 Sensors ....................9 Ceiling Controller ................11 Touch Screen Controller ..............12 Commissioning and Testing ..............13 Caution .................... -
Page 4: Definitions/Warning/Caution
DEFINITIONS Before use please read and understand these definitions. WARNING and/or the use of the symbol refers to conditions where the possibility of injury, or death, exists if the procedure is not followed. CAUTION CAUTION indicates the possibility of damage to the equipment, installation or premises if a procedure is not followed. -
Page 5: Kit Contents
KIT CONTENTS Item SYN1015AD SYN2025AD SYN3035AD Energy Recovery Ventilator F7 Filter G3 Filter 150mm x 6m Nude Duct 150mm x 6m Insulated Duct 200mm x 3m Insulated Duct 150mm x 6m Acoustic Duct 150mm Duct Joiner 150mm Low Profile Diffuser... -
Page 6: System Overview
SYSTEM OVERVIEW... -
Page 7: Standard Systems
STANDARD SYSTEMS SYN1015AD SV Synergy3 Sensor SYN2025AD SV Synergy3 Sensor SYN3035AD SV Synergy3 Sensor... -
Page 8: Installation
INSTALLATION Preparation Before commencing installation it is strongly recommended that planning is undertaken and completed to ensure that the best possible ventilation solution is achieved. Please use the checklist below for your installation planning and change as may be required. Planning Checklist Sensors Page 9... -
Page 9: Sensors
INSTALLATION Sensors DO NOT mount the sensors before reading all the instructions Locations DO NOT install sensors within a metre of diffusers. DO NOT install sensors close to localised sources of heat, draughts, moisture or odours. Install the outside sensor on the south side of the house shielded from rain and strong wind close to the supply grille. - Page 10 INSTALLATION The sensors must be paired in this order Roof, Bedroom, Lounge then Outside. Sensor - Pairing - Before starting the pairing process, ensure the touch screen is connected to the Ceiling Controller Box. - Power on the Ceiling Controller Box and press and hold the button within 10 seconds. Button - The controller will give a long beep and the sensors will be ready to pair.
-
Page 11: Ceiling Controller
INSTALLATION Ceiling Controller Locations - Mount the ceiling controller on the lower half of the roof cavity. Make sure mains supply has been isolated before making any electrical connection. Locate the ceiling controller central to planned sensor location - favouring any sensors that may have concrete or brick walls in the way. -
Page 12: Touch Screen Controller
INSTALLATION Touch Screen Controller Locations Install inside only. Mount on an inner wall at eye level. DO NOT install in wet/damp areas (i.e. laundry or bathrooms), on hot surfaces, in convection currents, or exposed to direct sunlight. Ensure at least 0.2m between TSC cable and mains wires to avoid signal interference. DO NOT install near any localised heat source. -
Page 13: Commissioning And Testing
COMMISSIONING AND TESTING Caution Ensure all connections are firmly in place and the ceiling controller’s lid is fastened before switching on the mains supply. Power on the system and navigate to the ADVANCED SETTINGS page. (refer to pages 14-16). Login as INSTALLER Password: freshair Check the KIT SETTINGS and modify as per the installation. -
Page 14: Screens And Navigation
COMMISSIONING AND TESTING Screens and Navigation GENERAL SETTINGS ADVANCED SETTINGS BRIGHTNESS AUTO LOCK TIME AUTO SCREEN LOCK V0.X.X CONTACT SMARTVENT CCB HW V0 ENQUIRY@SMARTVENT.CO.NZ CCB FW V0 0800 140 150 CCB M GENERAL SETTINGS ADVANCED SETTINGS LOGIN INSTALLER PASSWORD: freshair... - Page 15 COMMISSIONING AND TESTING Screens and Navigation STANDBY HOME SETTINGS DATE/TIME FILTER GENERAL VENTILATION HEAT TRANSFER HEATER SETTINGS...
- Page 16 F7 FILTER RESET GENERAL SETTINGS ADVANCED SETTINGS FILTER BRIGHTNESS AUTO LOCK TIME AUTO SCREEN LOCK V0.X.X CONTACT SMARTVENT CCB HW V0 ENQUIRY@SMARTVENT.CO.NZ CCB FW V0 0800 140 150 CCB M VENTILATION HEAT TRANSFER HEATER Only available if selected in ADVANCED SETTINGS...
-
Page 17: Maintenance
7. If the filters are unable to be cleaned correctly or are damaged, they should be replaced immediately and before the system is restarted (see order codes). 8. Turn your Synergy3 system back ON and reset the G3 filter timer. System Filter Order Code SYN1015AD FAN6017 SYN2025AD FAN6018 SYN3035AD FAN6019 DCT2093... -
Page 18: Replace Sensor Battery
MAINTENANCE F7 and HEPA Filters Filter Grade Order Code Typical Life FAN2093 12 months F7 Carbon FAN2277 6 months HEPA Carbon FAN2278 6 months Caution: When switching to a different grade of filter, remember to modify the KITS SETTINGS to get the correct filter change reminder. See the INSTALLATION INSTRUCTIONS / Commissioning and Testing for instructions Replace Sensor Battery... -
Page 19: Troubleshooting
TROUBLESHOOTING Refer to the User Manual’s Troubleshooting section for more information. Or contact SmartVent for support on 0800 140 150 if below does not resolve the issue. Sensor flashes less than 3 times when pairing Ensure ceiling controller is powered on. -
Page 20: Error Codes
Turn off the power to the ceiling controller E4002 Sensor Pairing Not Initiated for 30 seconds and begin sensor pairing process. Contact SmartVent for support on 0800 140 150 if you see error codes not listed above or the actions above do not clear the errors. -
Page 21: Technical Specifications
TECHNICAL SPECIFICATIONS Item Data Operating Voltage/Frequency 220-240V AC 50Hz Switching Voltage 240V AC max Switching Current 5A max resistive load Controller Operating Temperature 0 to 50ºC Controller Operating Humidity 5-90% non condensing Sensor Radio Frequency 868MHz Sensor Operating Temperature -20ºC to 70ºC Sensor Operating Humidity 5-90% non condensing Sensor Temperature Accuracy... - Page 22 Specifications are subject to change without notice. Distributed by Simx Limited PO Box 14347, Panmure, Auckland, New Zealand. Technical Support (09) 259 1662 | e: sales@simx.co.nz | w: www.simx.co.nz PUB1769 2302...
