- Page 1 IP816A-LPC-v2 License Plate Capturing Solution Highway & Street Installation Guide Rev. 1.0 Document part no.: 625041100G Ordering part no.: IP816A-LPC-v2 (Highway): 199002900G IP816A-LPC-v2 (Street): 199002800G IP Sur veillance...
-
Page 2: Specifications
CAUTION: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. UNPACKING: Unpack carefully. Electronic components can be damaged if improperly handled or dropped. If an item appears damaged in shipment, place it properly in its carton and notify the shipper. -
Page 3: Mounting Configuration & Dimensions
Mounting Configuration & Dimensions Swivel Positions and Directions 170 mm 502.8 mm 400 mm 255 mm 105 mm USABLE USABLE AREA AREA 502.8... -
Page 4: Component Description
Component Description Window frame heater Ventilation fan coil Camera Mounting Platform Power distribution M16 1/2" Waterproof cable gland board Installation Suggestions If you plan to install this camera enclosure into a tropical, sea coastal, or an environment where salt water or corrosive industrial waste water/moist are present, please seal each stainless steel screws and fittings with a silicon grease compounds. -
Page 5: Installation
Installation Install the wall-mount bracket to a preferred location at your installation site. Drill mounting holes and a cable routing hole (if preferred) on a wall. Install the bracket. Prepare and route the wiring, Ethernet and 24V power source. Install the IR illuminator to the bottom of the housing. Attach the included grip stricker to the U bracket. - Page 6 Secure the U bracket to the IR illuminator using the included wrench and hex screws. Flip the housing over and place it on a clean, stable surface. Secure the IR illuminator to the bottom of the housing using the included wrench and a hex socket screw.
- Page 7 You can turn the IR illuminator so that its flat side is parallel with the housing, and that you can turn the assembly over and work on the inside of the housing. Prepare power wires, a ground wire, and a CAT5e Ethernet cable. Pass them through the M16 waterproof connectors under the housing.
- Page 8 Assemble the camera components, e.g., the CS ring and lens module. Secure the mounting plate to the bottom of the camera (the label side) using the included screw. There is a plastic mount pad in the package. You do not need the mounting pad using the VIVOTEK camera.
- Page 9 Adjust the camera's position so that the lens module can flush align with the tempered glass. Secure the camera using the screws and washers to the bottom of the housing. Lens flush w/ edge of enclosure Connect 24V power source to the power input terminal. Connect power wires from the DC 12V output to the camera.
- Page 10 You should prepare a power adaptor of the sufficient capacity for supplying 24V input. Below are the requirements: Total consumption Power adaptor LPC Highway LPC Street Connect the Ethernet cable to the camera's RJ45 socket. Also pass the combo cable of the IR illuminator through a waterproof connector. Connect the day/night signal lines from the IR unit to the DI/DO connectors on the camera's terminal block.
- Page 11 A sample connection diagram consisting of CaMate's IR illuminators and the IP816A camera is shown below. Please refer to your camera's documentation if your camera comes with different pinouts. DC 12V AWG26 DI+: Green DI-: Yellow DO+: Purple DO-: Blue RS485+: Orange RS485-:...
- Page 12 Secure the intersection bracket to the bottom of the housing by driving two screws. Install the housing to the wall-mount bracket by aiming and pressing the spring mortise, and hook the bracket onto the groove in the spring mortise.
- Page 13 When mounting the housing, please carefully place the cable within the cutout on the bracket. There is a cutout for routing the cable. Secure the housing to the bracket by fasteninng 4 T30 screws. T30 x 4...
- Page 14 Adjust zoom and focus and open a web console with the camera to tune for the best image. When zoom and focus is done, Close the top cover and fasten the hex screws from below. Firmware configurable options: Make sure that the external IR is turned on in the night mode, and that the IR cut filter option is synchronized with the digital input you connected (default is DI3).
- Page 15 In the Configuration > Media > Image settings page, select an application scenario, LPC Highway, street, or parking lot mode. The related parameters, such as shutter time, will be automatically changed for the scenario. LPC-highway LPC-street LPC-parking lot If preferred, e.g., shooting fast moving vehicles, select the 60fps frame rate.
- Page 16 In the night mode, check if the input signals are correctly detected. You may simulate the night mode by blocking the IR unit's light sensor. Change the triggering parameters if necessary. If your target area is a stretched out field of view, such as shooting a part of a highway, finding the best focus can be a problem.
- Page 17 Operation Procedure: 1. Press the Snapshot Recording button, e.g., when a car is passing the field of view. A short, 2.5 seconds of video recording will be available (including 1 second of pre-recording and another second of post-recording). 2. The recording takes place on Stream 1 with a focusing result calculated from the full of the current field of view.
- Page 18 The parameters of IR illuminator can be controlled via the RS485 connection. You can enable the connection in Configuration > PTZ > Mechanical window. Select the defaults for the IR illuminator: Pelco D, baud rate - 38400, Data bits - 8, Stop bit - 1, Parity - none. Defaults for IR: Pelco D 38400...
- Page 19 Below is the table of configurable data bit (Data1 ~ Data4) values: bit 31 ~ 24 Device ID: 01 (default) ~ 127 bit 23 ~ 21 Baud rate (0)1200, (1)2400, (2)4800, (3)9600, (4)19200, (5)38400 (default), (6)57600, (7)115200 bps bit 20 ~ 16 Brightness: (0) ~ (31), brightness from 0 ~ 100% (default), increment unit is 2.5% bit 15 ~ 13 LED control mode: (0) DI, (1) Direct, (2) Timer, (3) Light sensor, (4) DI pulse, (5) LPR, (6)
- Page 20 Brightness 70% FF012101b40009E0 Brightness 60% FF012101b00009DC The customized buttons will appear on the main page for easy access to IR control.
