- Page 2 Warning Before Installation Power off the Network Camera as Keep the Network Camera away soon as smoke or unusual odors are from water. If the Network Camera detected. becomes wet, power off immediately. Contact your distributor in the event of Contact your distributor in the event of occurrence.
- Page 3 Do not place the Network Camera on Do not touch the Network Camera unsteady surfaces. during a lightning storm. Do not disassemble the Network Do not drop the Network Camera. Camera. Do not insert sharp or tiny objects into the Network Camera. EN - 2...
-
Page 4: Package Contents
Package Contents IP8162/62P Power Adapter Camera Stand CS-mount Lens Software CD Quick Installation Guide Warranty Card L-type Hex Key Wrench EN - 3... -
Page 5: Physical Description
External/Internal NTSC/PAL Switch MIC Switch Power Cord Socket Ethernet 10/100 RJ45 Socket General I/O Terminal Block Recessed Reset Button Focus Assist Button DC-iris Control Cable Socket (IP8162) P-iris Control Cable Socket (IP8162P) Lens Focus Controller Zoom Controller EN - 4... -
Page 6: Mounting The Lens To The Camera
1. Mount the lens by turning it clockwise onto the camera mount until it stops. If necessary, turn the lens counterclockwise slowly until it gets the best attitude. 2. Connect the DC-iris control cable to the socket. (IP8162) Connect the P-iris control cable to the socket. (IP8162P) For further setup, please refer to the lens’... -
Page 7: Power Over Ethernet (Poe)
Power over Ethernet (PoE) When using a PoE-enabled switch The Network Camera is PoE-compliant, allowing transmission of power and data via a single Ethernet cable. Follow the below illustration to connect the Network Camera to a PoE-enabled switch via Ethernet cable. PoE Switch When using a non-PoE switch Use a PoE power injector (optional) to connect between the Network Camera and a... -
Page 8: Assigning An Ip Address
"Next" button to continue the program. Installation Wizard 2 3. The program will search for VIVOTEK Video Receivers, Video Servers, and Network Cameras on the same LAN. 4. After searching, the main installer window will pop up. Click on the MAC that matches the one labeled on the bottom of your device to connect to the Network Camera via Internet Explorer. -
Page 9: Ready To Use
Ready to Use 1. Access the Network Camera from the LAN. 2. Retrieve live video through a web browser or recording software. 3. Unscrew the zoom controller to adjust the zoom factor. Upon completion, tighten the zoom controller. 4. Unscrew the focus controller to adjust the focus range. Upon completion, tighten the focus controller. -
Page 10: Fine-Tune The Cs-Mount
Fine-tune the CS-Mount 1. Detach the CS-mount lens from the camera body. 2. Turn the right side of the camera body up. 3. Use the supplied L-type hex key wrench to loosen the lens mounting screw; the CS-mount ring becomes rotatable. 4. Use a coin to turn the CS-mount ring; fine-tune the distance between the sensor and the lens. - Page 11 NOTE When choosing the lens for your IP8162/62P, please notice the specifications as below. 1. Flange back length (distance A-B) must be longer than 12.5mm. If the flange back length is too short, the bottom of screw mount may hit the ICR, or result in out of focus when adjusting the focus controller.
